Поз.
Артикул
Описание
5
ACCELERATOR PEDAL (PARTS KIT), RANGE OF DELIVERY INCLUDES: 1X 655 301 00 93, 3X 000965 006077
8
PAD ACCELERATOR PEDAL
11
SCREW ACCELERATOR PEDAL
14
SHIM ACCELERATOR PEDAL
17
SCREW ACCELERATOR PEDAL TO CAB M 6X20
20
BOOT ACCELERATOR PEDAL
23
SCREW ACCELERATOR PEDAL TO CAB M 6X25
32
STOP ACCELERATOR PEDAL
35
SCREW VALVE TO BRACKET
35
SCREW VALVE TO BRACKET, Replaced By: N304014008002
38
NUT
41
BALL PIVOT LOAD SENSOR
44
NUT PUMP TO BRACKET
44
NUT , Replaced By: N913004006001
80
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
86
BALL SOCKET PULL ROD TO LEVER
89
NUT BALL PIVOT TO LEVER
92
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
113
BEARING BRACKET INTERMEDIATE BEARING
131
SCREW BRACKET TO CROSS CONNECTION STRUT
131
SCREW , Replaced By: N304017008034
140
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
140
NUT , Replaced By: N913004008001
140
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
143
LEVER INTERMEDIATE BEARING
146
LEVER (INTERMEDIATE LEVER)
158
BALL STUD. BALL PIVOT TOP B10X4,5 MM
161
BALL PIVOT BOTTOM B13X5 MM
167
COVERING INTERMEDIATE BEARING
170
LOCK PLATE INTERMEDIATE BEARING
173
PULL ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
176
ROD FROM INTERMEDIATE LEVER TO ENGINE CONTROL SHAFT,K 093739
179
YOKE SHIFTING ROD TO INTERMEDIATE LEVER
182
PIN ROD TO LEVER
185
WASHER BRACKET TO CROSS MEMBER
188
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
188
SPRING WASHER , Replaced By: N000137008212
191
COTTER PIN ROD TO INTERMEDIATE LEVER
191
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
194
BALL SOCKET ROD TO BALL PIVOT
197
BALL SOCKET ROD TO BALL PIVOT
200
NUT
203
SECURING CLIP. CIRCLIP
