Поз.
Артикул
Описание
59
HOSE FROM HYDRAUL.CYLINDER TO TRANSMISSIONSHIFTING-ROD PAWL
59
HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 599799, Replaced By: A6565500259
59
HOSE FROM HYDRAUL.CYLINDER TO TRANSMISSIONSHIFTING-ROD PAWL
59
HOSE , Replaced By: A6565500159
62
UNION NUT
65
SEAL CONE
65
GLAND , Replaced By: A0019901667
68
FITTING FROM PUMP TO CYLINDER
68
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
68
FITTING FROM PUMP TO CYLINDER
68
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
71
T-FITTING. FITTING AT INJECTION PUMP
74
FITTING 3/2-WAY VALVE,CONNECTION: "30"
74
SCREW-IN FITTING , Replaced By: A0029978472
77
SEAL RING LINE CONNECTION
80
GROMMET LINE THRU FRAME
80
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
83
RUBBER BUFFER TO PLUG THE FREE CONNECTIONS
89
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
104
LOOM TIE LINE MOUNTING
104
LOOM TIE LINE MOUNTING 280 MM
108
WASHER EXHAUST MUFFLER TO STRAP
108
WASHER , Replaced By: N000125008443
