Поз.
Артикул
Описание
11
SIGN BOX SIDE WINDOW, BUS
11
SIGN BOX SIDE WINDOW, BUS,230417, FACELIFT
11
SIGN BOX SIDE WINDOW, BUS
11
20
SIGN BOX SIDE WINDOW, BUS
20
SIGN BOX SIDE WINDOW, BUS
20
SIGN BOX SIDE WINDOW, BUS
20
SIGN BOX SIDE WINDOW, BUS
22
FLUORESCENT TUBE WHITE 30 W
22
FLUORESCENT TUBE WHITE 36 W
23
CRANK
23
CRANK
40
ELECTRIC CABLE
66
66
66
68
STAY
69
COVERING SIGN BOX
70
BRACKET BOX TO BODY,230417, FACELIFT
70
BRACKET BOX TO BODY,230417, FACELIFT
71
BRACKET TOP LEFT,230417, FACELIFT
71
BRACKET TOP RIGHT
74
BRACKET RIGHT SIDE MOUNTED SIGN BOX
74
BRACKET BOX TO BODY
74
BRACKET LEFT SIDE MOUNTED SIGN BOX
74
BRACKET BOX TO BODY
77
SCREW BOX TO BODY
80
RIVET NUT. RIVETED NUT FEED LINE TO TRANSMISSION
83
WASHER BRACKET TO AIR INTAKE SCOOP
86
SPRING WASHER BOX TO BODY
95
PAD INSERT TYPE SIGN
95
SPACER DESTINATION INDICATOR
98
SCREW
101
WASHER EXHAUST MUFFLER TO STRAP
104
FLAP SIGN BOX
104
FLAP SIGN BOX,230417, FACELIFT
104
FLAP ,230417, FACELIFT
104
FLAP , Replaced By: A6718100683
107
FASTENER
110
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
113
NUT MOUNTING FRAME TO SUPPORT M6
113
NUT SPRING-LOADED PUSH ROD
116
INSERT TYPE SIGN LATERAL
116
INSERT TYPE SIGN LATERAL
119
RETAINING ROPE169 MM, AS OF PRODUCTION BREAKPOINT DATE 03.05.01
122
COTTER PIN PUSH ROD TO BRAKE PEDAL
125
SCREW , Replaced By: N007985005157
125
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
125
SCREW RELAY TO BRACKET M 5X12
128
WASHER BOOT TO CAB FLOOR
131
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
134
NUT MOUNTING FRAME TO SUPPORT M6
134
NUT SPRING-LOADED PUSH ROD
137
RUBBER MOULDING , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
140
SEAL ,230417, FACELIFT ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
145
BUSHING SIGN BOX TO BODY,230417, FACELIFT
172
172
172
SIGN BOX REAR WINDOW PANE
202
220
220
286
SCREW BRACKET TO ORNAMENTAL GRILLE M 6X25
289
RIVET NUT. RIVETED NUT GRIP RAIL MOUNTING
999
999
999
999
999
999
999
SHEET BARS
999
SHEET BARS
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
SOCKET FLOURESCENT TUBES 24V / 36W
999
999
ELECTRIC CABLE DESTINATION SYSTEM XY5 / XY10
999
SIGN BOX LATERAL "LAWO" 16X112
999
999
999
ELECTRIC CABLE DESTINATION INDICATOR
999
SIGN BOX WINDSHIELD
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
PLATE 12-POLE
999
