Поз.
Артикул
Описание
113
BRACKET FRAME MOUNTED CABLE HARNESS TO CAB
116
RIVET BRACKET TO CAB
119
BRACKET BREATHER LINE TO SIDE MEMBER
122
SCREW BRACKET TO CROSS CONNECTION STRUT
122
SCREW , Replaced By: N304017008034
123
WASHER BRACKET TO CAB REAR PANEL
123
WASHER BRACKET TO LEFT SIDE MEMBER
123
WASHER , Replaced By: N009021008213
125
NUT , Replaced By: N913004008001
128
BRACKET FRAME MOUNTED CABLE HARNESS
131
SCREW CONSOLE TO SIDE MEMBER
134
NUT SUPPORT TO SIDE MEMBER
137
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
137
SPRING WASHER , Replaced By: N000137008212
137
SPRING WASHER , Replaced By: N000137008204
137
SPRING WASHER ALTERNATOR CONNECTION D+
137
SPRING WASHER HEATER PLUG CABLE HARNESS
137
SPRING WASHER ELECTRIC CABLE TO ALTERNATOR
140
NUT
140
NUT TACHOGRAPH TO BRACKET
140
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
143
WASHER EXHAUST MUFFLER TO STRAP
143
WASHER , Replaced By: N000125008443
146
BRACKET LINE MOUNTING
149
BRACKET CABLE HARNESS
152
SCREW END PIECE TO EXHAUST PIPE M 10X25
155
NUT STRAP TO BRACKET
155
NUT , Replaced By: N910113010000
161
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
164
BRACKET , Replaced By: A6735460443
165
BRACKET BATTERY CABLE TO CROSS MEMBER
167
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
167
SCREW , Replaced By: N308676012012
167
SCREW BRACKET TO SIDE MEMBER
168
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
168
SCREW , Replaced By: N304017008027
173
NUT SUPPORT TO SIDE MEMBER
173
NUT STRAP TO BRACKET
173
NUT , Replaced By: N910113010000
175
NUT STRAP TO BRACKET
179
CLAMP CABLE HARNESS TO BRACKET
179
CLAMP CABLE HARNESS TO BRACKET
182
SCREW , Replaced By: N304017006026
182
SCREW , Replaced By: N304017006026
182
SCREW , Replaced By: N304017006026
188
WASHER COMPRESSED AIR LINE TO BRACKET
188
WASHER COMPRESSED AIR LINE TO BRACKET
188
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
191
NUT PUMP TO BRACKET
191
NUT PUMP TO BRACKET
191
NUT , Replaced By: N913004006001
197
SCREW PIPE CLAMP
197
SCREW , Replaced By: N304017008021
200
WASHER BRACKET TO CAB REAR PANEL
200
WASHER BRACKET TO LEFT SIDE MEMBER
200
WASHER , Replaced By: N009021008213
203
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
203
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
203
NUT , Replaced By: N913004008001
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
BRACKET
