Поз.
Артикул
Описание
5
PLASTIC PIPE RISING PIPE 4X6 MM
5
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
11
UNION NUT
14
SEAL CONE
14
GLAND , Replaced By: A0019901667
17
SLEEVE LEAK LINE
35
CONNECTOR HOSE WIDTH, 6 MM,TO M16
35
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
35
CONNECTOR , Replaced By: A0029905378
35
CONNECTOR , Replaced By: A0029905478
38
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
38
FITTING FROM PUMP TO CYLINDER
39
ELBOW FITTING
44
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
44
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
44
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
47
BRACKET DISTRIBUTOR TO CAB
50
SCREW COVER PLATE TO COVER PLATE M 6 X 10
50
SCREW , Replaced By: N304017006034
56
CONNECTOR DISTRIBUTOR OUTPUT, COMPRESSED AIR LINE PLUG CONNECTION
59
SEAL RING
65
SEAL RING , Replaced By: A0009940747
65
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
65
LOCK RING LINE CONNECTION
68
LOCK LINE CONNECTION
68
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
68
LOCK , Replaced By: A0009945448
71
REPAIR KIT , Replaced By: A0309971748
71
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
71
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
74
BRACKET SENSOR CABLE TO FRONT AXLE
77
LOOM TIE LINE MOUNTING
80
VALVE EXHAUST BRAKE 3/2-WAY VALVE BOSCH
80
VALVE EXHAUST BRAKE 3/2-WAY VALVE WABCO
83
CUP 3/2-WAY VALVE WABCO
86
REPAIR KIT 3/2-WAY VALVE WABCO
86
REPAIR KIT 3/2-WAY VALVE BOSCH
89
NUT SUCTION LINE TO OIL PUMP
92
SPRING WASHER AT CAB FLOOR
98
PIPE SOCKET 3/2-WAY VALVE,CONNECTION: "30"
107
SCREW. UNION SCREW LINE CONNECTION
107
SCREW. UNION SCREW , Replaced By: A0009973734
110
VALVE (3/2-WAY SOLENOID VALVE) EKS
111
SEAL RINGBOSCH
112
SEAL RINGBOSCH
113
FITTING LINE CONNECTION
116
SEAL RING LINE CONNECTION
119
BRACKET 3/2-WAY SOLENOID VALVE, TO BE ADAPTED DURING ASSEMBLY
119
BRACKET , Replaced By: A6734302110
122
REINFORCEMENT BRACKET TO CAB
125
SHIM BRACKET TO CAB
128
SHIM BRACKET TO CAB
131
SCREW VALVE TO BRACKET M 8X55
131
SCREW , Replaced By: N304017008043
134
SCREW COVER TO OIL PAN M8X20
137
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
137
SCREW , Replaced By: N304017008016
140
SCREW , Replaced By: N304017006016
140
SCREW PUMP TO BRACKET
143
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
143
NUT , Replaced By: N913004008001
143
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
