Mercedes
›
TRUCK
›
3331 A - 3340 A
›
950.183
›
54 ELECTRICAL EQUIPMENT AND INSTRUMENTS
›
001 ROOF MOUNTED FLAP IL.2
Mercedes N000125010532 - Диск
3331 A - 3340 A 950.183
54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 001 ROOF MOUNTED FLAP IL.2
Поз.
Артикул
Описание
8
A4257500408
ROOF MOUNTED FLAP
11
A3817500054
PANELLING
14
A4259880078
CLIP
17
A3817511198
SEAL
20
A3817500384
FASTENER LEFT
23
A3817500284
FASTENER RIGHT
26
A3819910001
PIN
29
N912007005000
CLIP LEVER
32
A3817520424
SPRING
35
A3817520324
SPRING
38
N001481005030
CLAMPING SLEEVE
41
A3817520311
PLATE LEFT
44
A3817520411
PLATE RIGHT
47
A0019900091
NUT RETAINER
50
A3817500620
MOUNTING LEFT, TO BE ADAPTED DURING ASSEMBLY
53
A3817520198
SEAL
56
A4257521122
MOUNTING LEFT
59
N001850032001
BUSHING
62
A4257520628
LEVER LEFT
65
N000471032002
LOCK RING
68
A4257500156
ARM LEFT
71
N001444010216
PIN
74
A4257520424
SPRING
77
A4259905002
SCREW
80
N000125010532
WASHER RADIATOR TO RUBBER MOUNTING
83
N001481004036
CLAMPING SLEEVE
86
N001444010103
PIN
89
N912010010001
LOCK PLATE
92
A4257520324
SPRING
95
A4259905012
SCREW
98
A4257500090
LEVER LEFT
101
N912010008002
CIRCLIP. LOCK PLATE , Replaced By: N912010008001
101
N912010008001
LOCK PLATE ,5 0994165 387552
104
N001444010101
PIN AT SUPPORT
107
N912010010001
LOCK PLATE
110
A4257520821
COVERING
113
A4259870140
RUBBER BUFFER LADDER TO SIDE MEMBER
116
A4259870340
RUBBER BUFFER
