Поз.
Артикул
Описание
5
HOUSING
6
BUSHING
8
SEAL RING
9
INTERMEDIATE PLATE
10
SEAL RING
11
SCREW SUPPORT TO FENDER
11
SCREW , Replaced By: N304017008018
12
SPRING WASHER , Replaced By: N000137008212
12
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
13
GROOVED BALL BEARING
17
BUSHING
17
BUSHING , UP TO TRANSMISSION 000,002,010,015 012077 100,102,103,110,112,115 009785, Replaced By: A1152702150, +001A1152704120, +001A1152721407, +001A1092720326, +002A1092722326
17
BUSHING , UP TO TRANSMISSION 000,002,010,015 012077 100,102,103,110,112,115 009785, Replaced By: A1152702150, +001A1152704120, +001A1152721407, +001A1092720326, +002A1092722326
18
SEAL RING , Replaced By: A3162720455
18
SEAL RING
19
BOOT OIL FEED
24
FLANGE , WITH 108 270 13 01: FROM TRANSMISSION 011097
25
BALL
26
PISTON
28
BOOT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3162720792
28
BOOT
29
BOOT
31
SPRING
32
BRACKET
33
SNAP RING
35
SNAP RING
36
NEEDLE BEARING
37
INNER DISC
39
OUTER DISC 2.0 MM
45
OUTER DISC , WITH 108 270 09 01: FROM TRANSMISSION 025698-033564 ALSO INSTALLED ON 020066-023715, WITH 108 270 13 01: FROM TRANSMISSION 000 001
47
OUTER DISC , WITH 108 270 09 01: FROM TRANSMISSION 025698-033564 ALSO INSTALLED ON 020066-023715, WITH 108 270 13 01: FROM TRANSMISSION 000 001
48
LOCK
49
GUARD PLATE 0.6 MM
53
PLANETARY CARRIER
60
NEEDLE BEARING , Replaced By: A0009811411
61
GUARD PLATE , 013131 EXCEPT FOR 010364-010763
65
LOCK
66
GUARD PLATE
67
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.10 MM
69
SPACER WASHER AS REQUIRED 0.1 MM
72
PLANETARY CARRIER , 053009
72
PLANETARY CARRIER , 013131 EXCEPT FOR 010364-010763
72
PLANETARY CARRIER , FROM TRANSMISSION: 115.000,002,010,015 015645-043913 115.100,102,103,110,112,115 013132-031415, Replaced By: A1152705643, +001A1152721155
72
PLANETARY CARRIER , FROM TRANSMISSION: 115.000,002,010,015 015645-043913 115.100,102,103,110,112,115 013132-031415, Replaced By: A1152705643, +001A1152721155
78
DRIVE SHAFT , FROM TRANSMISSION: 115.000,002,010,015 015645-043913 115.100,102,103,110,112,115 013132-031415, Replaced By: A1152705925, +001A1152721155
78
DRIVE SHAFT , 053009
79
SEAL RING , 053009
81
LOCK
136
GUARD PLATE , FROM TRANSMISSION 019700 ALSO INSTALLED ON 009817-010986
138
SEAL RING OUTPUT SHAFT,FRONT 26 MM
139
FLANGE
140
SCREW
143
SPACER WASHER AS REQUIRED 0.1 MM
850
GASKET KIT
850
GASKET KIT , Replaced By: A1152702201
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING LOCK-UP COUPLING 0.32X6.64X27 MM
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
SHIFT VALVE
999
PIN40,15
999
SHIFT VALVE
999
GASKET
999
PISTON
999
SHIFT VALVE
999
PISTON
999
SHIFT VALVE
999
VALVE PART
999
PISTON
999
SHIFT VALVE
999
SHIFT VALVE
999
SHIFT VALVE
999
SHIFT VALVE
999
INTERMEDIATE PLATE , TO 115 270 33 07
999
GASKET , Replaced By: A1152772980
999
VALVE PART
999
SHIFT VALVE
999
SHIFT VALVE
999
SCREW , TO 115 270 27 11, 115 270 30 11, 115 270 39 11
999
VALVE PART
999
SHIFT VALVE
999
SCREW , TO 115 270 12 11, 115 270 17 11
999
INTERMEDIATE PLATE ,024694
999
LOCKING SHEET ,019885
999
DETENT
999
INTERMEDIATE PLATE ,024694
999
SPACER WASHER
999
GUIDE
999
TUBE ,000029
999
DRIVE GEAR , FROM TRANSMISSION: 115.000,002,010,015 018035-026754 115.100,102,103,110,112,115 015266-020935 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1152741030, +001A1152700327
999
DRIVE GEAR ,015265
999
CASE ,026754
999
SEAL RING , Replaced By: A0119976447
999
GUARD PLATE
999
GUARD PLATE
999
DISC SUPPORT ,017085
999
FLANGE
999
BOOT
999
SUN GEAR , NO LONGER AVAILABLE INDIVIDUALLY
999
BOOT
999
PIN
999
ANNULUS , NO LONGER AVAILABLE INDIVIDUALLY
999
PISTON
999
OUTER DISC , Replaced By: A1092722026
999
PLANET GEAR
999
PLANET GEAR
999
ANNULUS , NO LONGER AVAILABLE INDIVIDUALLY
999
SPACER WASHER 0.5 MM,AS REQUIRED
999
SPACER WASHER AS REQUIRED 0.2 MM
999
SPACER WASHER 0.5 MM,AS REQUIRED
999
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.20 MM
999
SPACER WASHER AS REQUIRED 0.5 MM
999
SPACER WASHER AS REQUIRED 0.2 MM
999
PLANETARY CARRIER , UP TO CHASSIS: 010 036484 015 034954 110 084330 115 038326
999
DRIVE SHAFT ,031316
999
SOLENOID
999
NEEDLE
999
SEAL RING ,000029
999
NEEDLE BEARING ,011777
999
LOCK ,022986
999
NEEDLE BEARING ,043589
999
SEAL RING ,031534
999
HOSE ,049665
999
SEAL RING
999
HOSE FROM TRANSMISSION TO OIL COOLER
999
HOSE , FROM CHASSIS: 010 043070 015 042951 110 101088 115 046326
999
OUTER DISC , Replaced By: A1092721826
999
LOCK ,020254
999
GASKET , NO LONGER AVAILABLE INDIVIDUALLY
999
BOOT
999
BOOT , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
OUTER DISC
999
OUTER DISC
999
OUTER DISC , 017664 EXCEPT FOR 015709-017194
999
OUTER DISC , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
PIN AS REQUIRED 23 MM
999
PIN AS REQUIRED 24 MM
999
PIN 25 MM,AS REQUIRED
999
PIN 26 MM,AS REQUIRED
999
GROMMET OIL LINE TO CONVERTER HOUSING
999
CLAMP
999
VALVE BODY ASSEMBLY , 001189, Replaced By: A1142701707, +001A1152701068
999
GASKET KIT , Replaced By: A1142703301
999
VALVE BODY ASSEMBLY , 001189, Replaced By: A1142701707, +001A1152701068
999
OIL FILLER PIPE
999
VALVE BODY ASSEMBLY
999
LINE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1232701347, +001A1162700241, +001A1232700079, +001A1129970381, +001A1159975082
999
AUTOMATIC TRANSMISSION , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE BODY ASSEMBLY , Replaced By: A1142702307
999
VALVE BODY ASSEMBLY
999
VALVE BODY ASSEMBLY ,001190-046645 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE BODY ASSEMBLY
999
GASKET KIT , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
PISTON , UNTIL PRODUCTION STOP, Replaced By: A1142770431, +001A1149931101
999
PISTON
999
SPRING
999
THRUST PIN
999
REGULATOR VALVE
999
THRUST PIN
999
VALVE BODY ASSEMBLY ,000029, Replaced By: A1152701607, +002A1152701068
999
VALVE ,024694
999
PIN
999
VALVE , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365
999
VALVE ,019885
999
GOVERNOR ,024694
999
VALVE BODY ASSEMBLY
999
VALVE BODY ASSEMBLY
