Поз.
Артикул
Описание
1
BEARING
2
LOCK STOP TO BEARING BRACKET
2
LOCK RING , Replaced By: A0079942041
3
PEDAL
4
BUSHING BRAKE PEDAL
4
BUSHING , Replaced By: A1242920050
6
PEDAL
7
BUSHING
8
BUSHING BRAKE PEDAL
8
BUSHING , Replaced By: A1242920050
10
PAD BRAKE
15
MASTER CYLINDER , 077222
16
MASTER CYLINDER , FROM CHASSIS: 007,008,015,017 227754 011 105483 060 111610 062 105439
17
BOOT
18
BOOT
19
SNAP RING
20
LOCK RING19 MM
22
BLEEDER VALVE
23
PROTECTIVE CAP , Replaced By: A0004217187
23
PROTECTIVE CAP ,5 962906
24
PLUG
26
REPAIR KIT MASTER CYLINDER, 000,003,007,102,103,105,200 A 091118 083,086,093,183,190,193,280,283 F 015866
30
BRACKET , 021245
39
BUSHING , 021245
40
WASHER , 021245
41
LOCK , 021245
42
SCREW BRACKET TO CROSS MEMBER
42
SCREW , Replaced By: N304014006004
43
SPRING WASHER LICENSE PLATE TO BRACKET
44
NUT BATTERY MOUNTING
44
NUT CYLINDER TO BRACKET TO0002902112
48
ROD
49
BUSHING
50
SCREW , UP TO CHASSIS: 023 101126 072 103733 073 106943, Replaced By: A1152950172, +001N000137008202, +001N000933008131
51
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
52
NUT COVER PLATE
53
LOCK AT WATER EXPANSION TANK
57
STOP
58
GUIDE , 000159
65
SWITCH STOP LIGHT
66
NUT SWITCH
67
TOOTHED WASHER , 027703
68
SPRING
69
WASHER PEDALS TO PIVOT PINS
70
STOP , 077222
71
BRACKET , UP TO CHASSIS: 114569 ALSO INSTALLED ON 115036 EXCEPT FOR: 114138,114139,114215,114398,114423,114472,114476-114478,114480-114482,114484,114486,114487,114489, 114492,114493,114495,114498,114500,114501,114503,114506,114512,114514,114515,114517,114519,114521, 114523,114525,114527,114529-114534,114536-114540,114543,114544,114546-114551,114553,114556,114558- 114567.
72
SCREW , Replaced By: N304017006027
72
SCREW APPARATUS PLATE M 6X45
73
SPRING WASHER LICENSE PLATE TO BRACKET
74
NUT BATTERY MOUNTING
74
NUT CYLINDER TO BRACKET TO0002902112
75
ROD
76
BUSHING
77
SPRING
78
SPRING RETAINER SPRING TO PUSH ROD
79
NUT
82
NUT
83
WASHER EXHAUST MUFFLER TO STRAP
83
WASHER , Replaced By: N000125008443
84
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
85
SPRING RETAINER , Replaced By: A3092910091
87
SPRING RETAINER , Replaced By: A3092910091
89
GASKET
92
BRACKET
94
SHIM
95
SCREW APPARATUS PLATE M 6X45
95
SCREW , Replaced By: N304017006027
96
SPRING WASHER LICENSE PLATE TO BRACKET
97
NUT BATTERY MOUNTING
97
NUT CYLINDER TO BRACKET TO0002902112
98
GASKET
99
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
100
NUT
103
STOP CLUTCH PEDAL
106
RESERVOIR , UP TO CHASSIS: 023 100513 072 102501 073 103666
107
FILLER CAP BUTTRESS THREAD
107
SCREW PLUG , Replaced By: A0004315433
108
SEAL RING , UP TO CHASSIS: 023 100513 072 102501 073 103666
110
STRAINER
112
BRACKET , 001616
113
SHEET METAL SCREW ALARM UNIT TO STRUT
114
WASHER , FROM CHASSIS: 005,007,008,015,017 10/50,12/52 009573, ALSO INSTALLED ON: 009319,009323,009404,009444,009449,009450,009454-009456,009458,009459,009461-009472,009475-009477, 009479-009494,009496-009571. 010 10/50,12/52 013397, ALSO INSTALLED ON: 013289,013348,013354,013356,013358,013361-013367,013370-013381,013384-013388,013390-013395. 005,007,008,015,017 20/60,22/62 012727 010 20/60,22/62 015672
115
CLAMPING SCREW ,114.005,007,008,015,017 012727 114.010 015672 EXCEPT FOR: 015728 115.000,001,002,010 013352 EXCEPT FOR: 013355,013825 115.015 010341 EXCEPT FOR: 010347,010405,010406 115.110,102,103,110,112 029021 115.115 013141 114.005,007,008,015,017 039769 114.010 035804
116
NUT BALL PIVOT TO LEVER
117
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
120
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
122
INTERMEDIATE PIECE , Replaced By: A0002950036
128
LINE , TO BE ADAPTED DURING ASSEMBLY
128
LINE , Replaced By: A1003203953
130
PIPE , UP TO CHASSIS: 007,008,015,017 227753 011 105482 060 111609 062 105438
131
BOOT FROM CLUTCH MASTER CYLINDER LINE TO SLAVE CYLINDER
135
HOSE
138
LOCK HYDRAULIC LINE TO CAB
139
CLAMP
140
HOSE30 MM, ORDER BY THE METER
142
SCREW
150
SLAVE CYLINDER , Replaced By: A0012956807
150
SLAVE CYLINDERTEVES
153
BOOT KUGELFISCHER
155
SNAP RING , TO 000 295 40 07
157
BLEEDER VALVE
158
PROTECTIVE CAP , Replaced By: A0004217187
158
PROTECTIVE CAP ,5 962906
162
REPAIR KITTEVES,TO 0002954007, UP TO CHASSIS: 005,007,008,015,017 207581 011 101771 060 102445 062 101972
164
GASKET
166
BRACKET , 071354
167
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
167
SCREW , Replaced By: N304017008027
168
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
170
LINE , 071355
175
BRACKET PIPE LINE TO BELL HOUSING, 071355
178
HOSE30 MM, ORDER BY THE METER
179
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
179
SCREW , Replaced By: N304017008016
180
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
REPAIR KIT SLAVE CYLINDER TO 2012900311,0002958207
999
SLAVE CYLINDER SLAVE CYLINDER TO 000 295 65 07,001 295 30 07,
999
INTERMEDIATE PIECE
999
LOCK
999
LOCK
999
BOOT
999
BOOT
999
MASTER CYLINDER , 000,002,010,100,102,103,112 UNTIL PRODUCTION STOP UP TO CHASSIS: 005,017 024922 015,235020 105,107,108,117,119 054273 110 428722 114 000072 115 243643, Replaced By: A0002958506, +001A0009970886
999
MASTER CYLINDER , 021245
999
SLAVE CYLINDER , Replaced By: A0002956507
999
SWITCH , Replaced By: A0005453509, +002A0009909251, +001N006797012250
999
REPAIR KIT , UP TO CHASSIS: TO 000 295 51 06 021: 10/50 007951 022: 10/50 019872
999
REPAIR KITKUGELFISCHER,TO 0002954107, UP TO CHASSIS: TO 000 295 41 07 021: 10/50,20/60 008293 022: 10/50,20/60 020490
999
REPAIR KIT , Replaced By: A0002902111
999
REPAIR KIT TO 000 295 85 06
999
PLUG
999
HOSE , ORDER BY THE METER 107.022 005201 ALSO INSTALLED ON 005190-005192,005194-005199. 107.023 012497 107.024 021804 ALSO INSTALLED ON 021794,021804
999
SPACER TUBE
999
EXPANSION PLUG AT BRACKET
999
LINE FROM CLUTCH HOSE TO CLUTCH SLAVE CYLINDER, FROM CHASSIS: 000,002,010 089164 015 105337 100,102,103,110,112 262248 115 112353 005,017,105,107,108,117,119 000001 UP TO CHASSIS: 005,017 003779 105,107,108,117,119 004645
999
BRACKET , FROM CHASSIS: 000,002,010 089164 015 105337 100,102,103,110,112 262248 115 112353 005,017,105,107,108,117,119 000001 UP TO CHASSIS: 005,017 003779 105,107,108,117,119 004645 FROM CHASSIS: 005,017 024965 105,107,108,117,119 054001
999
CLAMP FORKED SUPPORT,TOP
999
EXPANSION PLUG VENTILATION BORE IN WHEELHOUSE, ONLY FOR REPAIR PURPOSES
999
GROMMET
999
PEDAL
999
BRACKET
999
LINE , UP TO CHASSIS: 000,002,010 089163 015 105336 100,102,103,110,112 226247 115 112352, Replaced By: A1072900013, +001A1072950340
999
PEDAL
999
LINE FROM CLUTCH MASTER CYLINDER TO CLUTCH HOSE
999
PEDAL , Replaced By: A1152902318
999
LINE , UP TO CHASSIS: 000,002,010 089163 015 105336 100,102,103,110,112 226247 115 112352, Replaced By: A1082901213, +001A1082950440
999
BEARING
999
ROD
999
PEDAL
999
STOP , UP TO CHASSIS: 000,002,010 005190 015 002585 100,102,103,110,112 013094 115 005644
999
NUT ROD TO LEVER,526440
999
BRACKET , 10/50 FROM CHASSIS 094171, 20/60 FROM CHASSIS 093900
999
BRACKET , 018770
999
BRACKET , UP TO CHASSIS: 005,017 003779 105,107,108,117,119 004645 FROM CHASSIS: 005,017 024965 105,107,108,117,119 054001
999
BRACKET , UP TO CHASSIS: 000,002,010 089163 015 105336 100,102,103,110,112 226247 115 112352
999
RUBBER BUFFER
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
SCREW DELIVERY AND SUCTION HOSES TO COUPLING MOUTH CROSS MEMBER,5 598039
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
SHEET METAL SCREW HEATING PIPE
