Поз.
Артикул
Описание
1
REAR LID SHELL WITHOUT FITTINGS
3
LOCK FOR REAR LID FROM CHASSIS 8510850
5
REAR LID HINGE, LEFT AND RIGHT, WITH PRESSURE SPRING
7
PIVOT PIN FOR REAR LID HINGE FROM CHASSIS
8
SUSPENSION LINK. THRUST ROD FOR PRESSURE SPRING GUIDE
9
PRESSURE SPRING FROM CHASSIS NO. 35 01478 EXCEPT FOR 35 01480, 01482, 01491, 01494, 01495, 01503, 01504, 01505, 01519, 01528, 01529, 015
10
PIVOT PIN. MOUNTING PIN
15
NUT RETAINER
16
LOCK FOR REAR LID SAME LOCK AS WITH DOOR HANDLE
17
LOCK
18
RUBBER WASHER BETWEEN LOCK AND REAR LID
19
COTTER. STRIKER FOR REAR LID
20
SHIM FOR STRIKER AT BODY REAR END
21
THREADED PLATE FOR STRIKER AT REAR PART, Replaced By: A101206470137
35
SEALING FRAME FOR REAR LID
36
RUBBER BUFFER , WITH MODEL 120.0 AS OF CHASSIS 014609 WITH MODEL 120.1 AS OF CHASSIS 012981
40
HANDLE
41
BASE. PAD FOR HANDLE AT REAR LID
45
MERCEDES STAR
46
RUBBER RING
47
WASHER MOUNTING PLATE TO BODY FLOOR
999
KEY (MARKED WITH THE LETTER "K"), STATE LETTER AND LOCK NO. WHEN ORDERING
999
RUBBER RING , Replaced By: A1109870741
999
CLEANER , Replaced By: A0009899271
999
CLEANER
999
NUT RETAINER , Replaced By: A0009903931
999
THREADED PLATE STRIKER AT BODY REAR END, Replaced By: A101206470037
999
BASE PLATE. REPLACED BY 120 758 0090
999
SEALING FRAME , Replaced By: A101207500077
999
WASHER
999
RUBBER BUFFER FOR ENGINE HOOD SUPPORT
999
LOCK WASHER 3/2-WAY SOLENOID VALVE TO BRACKET
999
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
999
LOCK RING
999
SCREW HEATER CASE TO WATER TANK
999
NUT BATTERY CASE
999
TOOTHED WASHER ENGINE HOOD CATCH LOWER PART TO COWL
999
SCREW , Replaced By: N007985005157
999
LENS HEAD COUNTERSUNK SCREW A M 6X8 DIN 7988 DBL 8451-21 LOCK AT REAR LID
999
SCREW LEFT WINDOW NO. 5, 000,001,004,010 UP TO CHASSIS 086601,100,101,104,110 UP TO CHASSIS 137704
999
WASHER , Replaced By: N009021006208
