Поз.
Артикул
Описание
10
EXHAUST GAS LINE LEFT, A 20140131
10
EXHAUST GAS LINE LEFT, A 20140131
15
HEXAGON HEAD BOLT AT BRACKET
20
EXHAUST GAS LINE RIGHT
25
HEXAGON HEAD BOLT AT BRACKET
30
BOLT AND WASHER ASSY. FRONT EXHAUST PIPE TO EXHAUST MANIFOLD M8X55
50
BOLT W FLANGE RIGHT EXHAUST LINE M8X45
60
BOLT W FLANGE RIGHT EXHAUST LINE M8X45
70
NUT W FLANGE, BINDING BRACKET MOUNTING M7
80
NUT W FLANGE, BINDING BRACKET MOUNTING M7
90
MULTI-HOLE SEAL LEFT
100
MULTI-HOLE SEAL RIGHT
110
STUD SPECIAL SHAPE TO EXHAUST GAS TURBOCHARGER, A 02672220101014
120
HEXAGON NUT W COLLAR EXHAUST SYSTEM TO TRANSMISSION M8
650
EXHAUST LINE LEFT, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
655
SCREW PIPE CLAMP
657
WASHER BRACKET TO CAB REAR PANEL
660
EXHAUST LINE RIGHT, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
675
BRACKET LEFT
680
BRACKET RIGHT
685
BASE PLATE BRACKET TO TRANSMISSION
690
PROTECTIVE PLATE AT ENGINE MOUNT CARRIER
692
SCREW CLAMP ON BRACKET
695
PLATE BRACKET TO EXHAUST PIPE
697
BASE PLATE BRACKET TO EXHAUST PIPE
700
HEXAGON NUT EXHAUST MANIFOLD TO CYLINDER HEAD M6
710
CLAMP FRONT EXHAUST PIPE TO REAR EXHAUST PIPE 81,5 MM
720
SEAL RING FRONT EXHAUST PIPE TO REAR EXH. PIPE (SLIP FIT)
810
BRACKET TO TRANSMISSION BELL LEFT
815
BRACKET SENSOR LINE FASTENING 18 X 24 MM, J 20121221 V 00000120130404
820
LAMBDA PROBE RIGHT CONTROL PROBE IN FRONT OF CATALYST, A 06254620120629803
820
LAMBDA PROBE RIGHT CONTROL PROBE IN FRONT OF CATALYST
820
LAMBDA PROBE RIGHT DIAGNOSIS PROBE BEHIND CATALYST
830
BRACKET TO TRANSMISSION BELL RIGHT
835
NUT , Replaced By: N913023006001
840
BRACKET LEFT
850
BRACKET SENSOR LINES OVER TRANSMISSION
855
BRACKET SENSOR LINE FASTENING 18 X 24 MM, J 20121221 V 00000120130404
860
SPRING CLAMP FOR SENSOR CONNECTOR 28X24 MM
865
SPRING CLAMP FOR 4-PIN SENSOR
