Поз.
Артикул
Описание
234
SWITCH
240
SWITCH LIQUID TANK, 023 060687 033 029142 123 043368 130 055526
250
SWITCH LIQUID TANK, 023 060688 033 029143 123 043369 130 055527
260
SEAL RING FROM EXPANSION VALVE TO COMPRESSOR
270
SEAL
550
CONDENSER , 023 016992 033 012221 123 009144 130 014496
555
COMBINATION BOLT INSTRUMENT PANEL TO COWL,BOTTOM
561
TANK , RANGE OF DELIVERY INCLUDES:1 SEAL RING 000 835 05 98
567
SHEET METAL SCREW BRACKET TO CAB FLOOR
612
PIPE LINE FROM COMPRESSOR TO CONDENSER
612
PIPE LINE
612
PIPE LINE FROM COMPRESSOR TO CONDENSER
612
PIPE LINE FROM COMPRESSOR TO CONDENSER, 023 016992 033 012221 123 009144 130 014496
612
PIPE LINE FROM COMPRESSOR TO CONDENSER
612
PIPE LINE FROM COMPRESSOR TO CONDENSER
612
PIPE LINE FROM COMPRESSOR TO CONDENSER
612
PIPE LINE FROM COMPRESSOR TO CONDENSER
613
CAP (PARTS KIT),CAP
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
658
PIPE LINE , ONLY FOR MODELS 123.020,023,043,083
658
PIPE LINE EXPANSION-VALVE-TO-COMPRESSOR REFRIGERANT LINE
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR, ONLY FOR MODELS 123.220,223,243,280,283
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR, ONLY FOR 123.220,223,243,283
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
658
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
685
RUBBER RING EXPANSION-VALVE-TO-COMPRESSOR REFRIGERANT LINE
685
SEAL RING HOSE TO RESERVOIR 10.6 MM
692
SPRING WASHER LICENSE PLATE TO BRACKET
695
PIPE LINE FROM CONDENSER TO LIQUID TANK
697
PIPE LINE FROM LIQUID TANK TO EXPANSION VALVE
697
PIPE LINE FROM LIQUID TANK TO EXPANSION VALVE
700
SEAL RING HOSE TO EXPANSION VALVE 7.5 MM
712
SCREW COVER PLATE TO COVER PLATE M 6 X 12
718
NUT BALL PIVOT TO LEVER
724
SPRING WASHER LICENSE PLATE TO BRACKET
730
SHEET METAL SCREW BRACKET TO CAB FLOOR
732
SHEET METAL SCREW
734
WASHER BOOT TO CAB FLOOR
736
BRACKET
742
CLAMP TO MOUNT MAIN CABLE HARNESS
744
SHEET METAL SCREW BRACKET TO CAB FLOOR
748
SCREW COVER PLATE TO COVER PLATE M 6 X 12
754
NUT BALL PIVOT TO LEVER
760
SPRING WASHER LICENSE PLATE TO BRACKET
780
SHEET METAL SCREW BRACKET TO CAB FLOOR
782
LOOM TIE
782
LOOM TIE TO MOUNT PLASTIC PIPING
782
LOOM TIE
782
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
820
BRACKET , ONLY FOR MODELS 123.220,223,243,280,283
832
BRACKET ,123.026 024883
836
BRACKET , ONLY FOR MODELS 123.220,223,243,280,283
837
BRACKET FROM COMPRESSOR TO CONDENSER
838
BUFFER FROM EXPANSION VALVE TO COMPRESSOR
841
HEXAGON HEAD BOLT
843
SCREW CONNECTOR TO CAB M6X8
843
COMBINATION BOLT BATTERY FRAME TO CONSOLE, TOP
843
COMBINATION BOLT
845
NUT CLAMP TO BRACKET
845
NUT BALL PIVOT TO LEVER
860
CLAMP
864
CLAMP , Replaced By: A0005465143
904
GROMMET
999
AIR CONDITIONER RANGE OF DELIVERY FOR SUBSEQUENT INSTALLATION
999
AIR CONDITIONER RANGE OF DELIVERY FOR SUBSEQUENT INSTALLATION
999
AIR CONDITIONER RANGE OF DELIVERY FOR SUBSEQUENT INSTALLATION
