Поз.
Артикул
Описание
5
PARKING BRAKE
8
DAMPING RING
11
PAD
14
SPRING
17
HOSE25 MM, ORDER BY THE METER
20
NUT CLAMP TO BRACKET
20
NUT , Replaced By: N913019006000
20
NUT , Replaced By: N913012006001
23
RUBBER RING SIGNAL LAMP TO ROOF
26
SCREW PUMP TO BRACKET
26
SCREW COVER PLATE TO BRACKET
29
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
32
WASHER COMPRESSED AIR LINE TO BRACKET
32
WASHER , Replaced By: N009021006208
35
BRAKE CABLE , 000 187917 003 092126 007 075162 086 005715 093 006694 102,103 190454 105 198857 183 011677 190 017807 193 000010 200 000153 283 000217
35
BRAKE CABLE , 000 187917 003 092126 007 075162 086 005715 093 006694 102,103 190454 105 198857 183 011677 190 017807 193 000010 200 000153 283 000217
35
BRAKE CABLE , 000 187916 003 092125 007 075161 086 005714 093 006693 102,103 190453 105 198856 183 011676 190 017806 193 000009 200 000152 283 000216
35
BRAKE CABLE , 000 187916 003 092125 007 075161 086 005714 093 006693 102,103 190453 105 198856 183 011676 190 017806 193 000009 200 000152 283 000216
38
SCREW , 000 068692 003 033262 102,103 049343 105 063025
41
NUT , 000 068692 003 033262 102,103 049343 105 063025
128
BRAKE CABLE FRONT
134
CUP
137
SPRING
143
BRAKE LEVER
146
SHACKLE
149
SCREW
152
SPRING
158
BRACKET
161
ROD
164
PIN BRAKE CABLE TO INTERMEDIATE LEVER
167
COTTER PIN BRACKET TO BATTERY CASE, 415 5 014668 416 5 000515 417 4 972023
167
COTTER PIN ROLLER TO LEVER
170
SPRING
173
PROTECTIVE CAP BRAKE CABLE TO REAR FLOOR
176
CLAMP BRAKE CABLE TO REAR FLOOR
179
SHEET METAL SCREW VALVE TO WINDOW SILL
182
BRAKE CABLE REAR LEFT
185
BRAKE CABLE REAR RIGHT
188
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
188
SCREW , Replaced By: N000933010162
191
SPRING WASHER SHIFTING ROD TO BRACKET
194
GROMMET BRAKE CABLE TO REAR AXLE
