Поз.
Артикул
Описание
5
ACCELERATOR PEDAL
8
CLIP
11
LEVER ACCELERATOR PEDAL,B 838714,J 003392
35
BEARING ACCELERATOR PEDAL BEARING,B 838714,J 003392
36
BEARING ACCELERATOR PEDAL BEARING,B 838715,J 003393
41
LOCK RINGTO 000 553 37 01,000 553 39 01,
42
CLIP PEDAL LEVER TO BEARING,B 838715,J 003393
47
SCREW LICENSE PLATE TO BRACKET
48
COMBINATION BOLT BEARING TO FIRE WALL,B 838715,J 003393
51
SPRING WASHER LICENSE PLATE TO BRACKET
53
GASKET BEARING TO FIRE WALL
56
NUT RETAINER LICENSE PLATE TO BRACKET
59
LEVER ,B 838715,J 003393 TO BE ADAPTED DURING ASSEMBLY
62
SPRING ACCELERATOR PEDAL,B 838714,J 003392
62
SPRING ACCELERATOR PEDAL,B 838715,J 003393
71
SWITCH (KICK-DOWN SWITCH)
74
WIRE CABLE
74
WIRE CABLE
75
GUIDE
77
RUBBER BUFFER WIRE CABLE TO FIRE WALL, FROM IDENT NO. 941506, P 000001 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINE
80
CLIP
