Поз.
Артикул
Описание
62
CLAMP , 003 078976 086 003333 EXCEPT FOR 002924,002958,002959,002981,003004,003013,003017,003025,003114,003171,003282-003298,003300-003332.
65
SCREW VALVE TO BRACKET M 8X55
65
SCREW , Replaced By: N304017008043
68
WASHER BRACKET TO CROSS MEMBER
71
NUT
74
SCREW VALVE TO BRACKET M 8X55
74
SCREW , Replaced By: N304017008043
74
SCREW 3/2-WAY VALVE TO BRACKET
74
BOLT W FLANGE FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, ONLY APPLICABLE TO VEHICLES EQUIPPED WITH CATALYTIC CONVERTER
77
NUT POWER CYLINDER TO BRACKET
77
NUT , Replaced By: A0009903250
89
SEAL RING. PART NAME MISSING FRONT EXHAUST PIPE TO CENTRAL EXHAUST PIPE
119
CLAMPING BRACKET FRONT EXHAUST PIPE TO BRACKET
122
NUT POWER CYLINDER TO BRACKET
122
NUT , Replaced By: A0009903250
125
WASHER HIGH PRESSURE HOSE TO BRACKET
128
SCREWM 8X40
128
SCREW , Replaced By: N304017008021
128
SCREW PIPE CLAMP
131
DISC SPRING EXHAUST PIPE TO BRACKET
134
RUBBER RING BRACKET TO MOUNTING PLATE OR TO TRANSMISSION
137
NUT BRACKET TO MOUNTING PLATE OR TO TRANSMISSION
137
SPACER TUBE ,019699A 122676, Replaced By: A1264920172, +001N000933008147
149
SUSPENSION RING MAIN MUFFLER SUSPENSION
152
CLAMPING PIECE MAIN MUFFLER SUSPENSION
155
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
155
SCREW , Replaced By: N304017008016
158
WASHER , Replaced By: N000125008443
158
WASHER EXHAUST MUFFLER TO STRAP
161
DAMPING PAD , Replaced By: A1074920082
161
DAMPING PAD EXHAUST PIPE SUSPENSION
164
RUBBER BUFFER IN FRONT OF,AND BEHIND,POSTERIOR MUFFLER
167
PROTECTIVE PLATE , Replaced By: A1074901230
167
PROTECTIVE PLATE
170
SENDER UNIT OXYGEN SENSOR, ONLY APPLICABLE TO VEHICLES EQUIPPED WITH CATALYTIC CONVERTER NOT FOR SWEDEN,SWITZERLAND,AND NORWAYA 569482 F 745592
170
SENDER UNIT , Replaced By: A0095424117
999
CLAMP , Replaced By: A1074900041
999
CLAMP , Replaced By: A1074900141
999
EXHAUST PIPE , Replaced By: A2014906219
999
EXHAUST MUFFLER WITH PIPE , Replaced By: A2014902415
999
EXHAUST PIPE , Replaced By: A2014909719, +004A1299900410
