Поз.
Артикул
Описание
5
TANK , FROM CHASSIS: 010 060996 110 152519
5
TANK , Replaced By: A1158000519
5
TANK , FROM CHASSIS:114.005,007,008,015,017 120954 114.011 014765 114.060 001693 114.062 001710, Replaced By: A1158000419
10
TANK
10
TANK , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 116.020 072528 116.024,025 068900 116.028,029 036006 115.032,033 055205 116.036 001346, Replaced By: A1168000219
10
TANK
12
TANK
12
TANK , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 123.003,026,028 102823 123.007,033 085173 123.130 256166 123.053 024128, Replaced By: A1238001419
14
TANK
15
SEAL , Replaced By: A1238050298
15
SEAL
15
SEAL VACUUM SUPPLY TANK
20
NUT BALL PIVOT TO LEVER
25
TOOTHED WASHER MASKED STOP LAMP
30
SEAL RING
31
FOAM PLASTICS FRONT ROOF RAIL
32
RIVET , Replaced By: A0009904892
32
RIVET , Replaced By: A0009904292
32
RIVET
35
BRACKET
40
SPACER TUBE
45
SCREW APPARATUS PLATE M 6X45
45
SCREW , Replaced By: N304017006027
47
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
50
NUT OIL TANK TO BRACKET
50
NUT , Replaced By: N913002006009
55
SCREW , Replaced By: N304017006018
55
SCREW COVER PLATE TO COVER PLATE M 6 X 12
58
SPRING WASHER LICENSE PLATE TO BRACKET
61
NUT BALL PIVOT TO LEVER
66
GROMMET FOR PASSAGE OF LINE, UP TO IDENT NO. 5 033766,ALSO INSTALLED ON 5 039977
101
HOSE GREY-YELLOW,FROM VACUUM DISTRIBUTOR IN ENGINE COMPARTMENT TO SUPPLY TANK, ORDER BY THE METER
101
HOSE , Replaced By: A0019973952
122
INSULATING HOSE5 X 0.6 MM, ORDER BY THE METER
135
HOSE FROM CHECK VALVE TO SUPPLY TANK 1300 MM, ORDER BY THE METER
999
TANK SUBSEQUENT INSTALLATION
999
CLIP
