Поз.
Артикул
Описание
5
STEERING BOX ASSEMBLY WITH PITMAN ARM, INAPPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
STEERING BOX ASSEMBLY WITH PITMAN ARM, INAPPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
STEERING BOX ASSEMBLY WITH PITMAN ARM, ONLY APPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
STEERING BOX ASSEMBLY , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 552116 F 708504 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A2014608701
5
STEERING BOX ASSEMBLY , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 552116 F 708504 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A2014608801
5
STEERING BOX ASSEMBLY , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A2014600051
5
STEERING BOX ASSEMBLY WITH PITMAN ARM, ONLY APPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
SCREW , Replaced By: N308676010017
8
SCREW CLAMP, ONE-HOLE
11
HEXAGON NUT
11
NUT , Replaced By: N910113010002
14
LOCK RING
15
SPRING CONTROL VALVE
17
SEAL RING , 023 10/50,12/52 056284 023 20/60,22/62 057848 033 10/50,12/52 027436 033 20/60,22/62 028023 123 10/50,12/52 029863 123 20/60,12/52 041002 130 10/50,12/52 051238 130 20/60,22/62 052678
20
LOCK CONTROL VALVE
23
STEERING BOX COVER
23
STEERING BOX COVER
26
SEAL RING
26
SEAL RING , Replaced By: A0199975147
29
LOCK
32
SEAL RING STEERING NUT BEARING 75X3 MM
35
THRUST WASHER
38
ROLLER BEARING
41
THREADED INSERT
44
WASHER
47
SEAL RING , 023 10/50,12/52 056284 023 20/60,22/62 057848 033 10/50,12/52 027436 033 20/60,22/62 028023 123 10/50,12/52 029863 123 20/60,12/52 041002 130 10/50,12/52 051238 130 20/60,22/62 052678
50
SEAL RING , 023 10/50,12/52 056284 023 20/60,22/62 057848 033 10/50,12/52 027436 033 20/60,22/62 028023 123 10/50,12/52 029863 123 20/60,12/52 041002 130 10/50,12/52 051238 130 20/60,22/62 052678
53
PISTON
53
PISTON
56
WASHER
59
ROLLER BEARING
62
ANGULAR CONTACT BEARING
65
LOCK , 023 10/50,12/52 056283 023 20/60,22/62 057847 033 10/50,12/52 027435 033 20/60,22/62 028022 123 10/50,12/52 029862 123 20/60,12/52 041001 130 10/50,12/52 051237 130 20/60,22/62 052677
68
SCREW FEED LINE AND RETURN LINE
71
SEAL RING
74
SEAL RING
77
SEAL RING VALVE
80
SCREW. CAP BOLT COVER TO CASE M8X25
80
SCREW , Replaced By: N000912008202
83
WASHER BRACKET TO CROSS MEMBER
86
SEAL RING
89
SCREW
92
THRUST WASHER2.95 MM
92
THRUST WASHER3.05 MM
92
THRUST WASHER3.00 MM
92
THRUST WASHER2.75 MM
92
THRUST WASHER2.85M
92
THRUST WASHER2.80 MM, TO BE ADAPTED DURING ASSEMBLY
92
THRUST WASHER2.70 MM
92
THRUST WASHER3.10 MM
92
THRUST WASHER2.80 MM, Replaced By: A1074620262
92
THRUST WASHER2.65 MM
95
LOCK
98
THRUST WASHER SHOCK ABSORBER TO TOP BRACKET
101
LOCK RINGTO 000 553 37 01,000 553 39 01,
104
NUT
104
NUT , Replaced By: A0009904050
107
STEERING BOX COVER , Replaced By: A2014600315
107
STEERING BOX COVER , Replaced By: A2014600415
107
STEERING BOX COVER
110
SEAL RING
113
SEAL RING
113
SEAL RING
113
SEAL RING
116
LOCK
119
SEAL RING
122
SEAL RING VALVE
125
SCREW
125
SCREW , Replaced By: A1249900912
128
WASHER BRACKET TO CROSS MEMBER
131
SCREW PLUG MID-POSITION BORE
134
SEAL RING , Replaced By: N007603010110
134
SEAL RING PNEUMATIC VALVE
137
BUSHING
140
PIN
143
SPRING , 1F 058035 2F 052098
146
SCREW PLUG
149
BUSHING
152
RING
155
FITTING HIGH PRESSURE
158
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
161
FITTING LOW PRESSURE
164
SEAL RINGTO 000 553 03 05,000 553 18 05,
167
STEERING COUPLING
170
SCREW
170
SCREW , Replaced By: A2029902101
173
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
176
REPAIR KIT
179
GASKET KIT
