Поз.
Артикул
Описание
8
BATTERY FILLED 12V/62 AH
8
BATTERY , Replaced By: A0035416601
8
BATTERY PARTS KIT,5 338284
14
BOOT , Replaced By: A0015460835
14
BOOT POS. POLE
17
POSITIVE CABLE FROM BATTERY TO STARTING MOTOR
20
BRACKET
23
PLUG HOUSING DOUBLE
26
COVERTO 007 545 00 28
29
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
32
PLUG HOUSING MAIN CABLE HARNESS
35
COVERTO 011 545 10 28
38
PLUG PIN
41
PLUG. PIN BUSHING HOUSING NTC FEELER
44
GROMMETTO 014 545 07 28
47
PIN BUSHING HOUSING UNIPOLAR, HEAT SENSOR CONNECTION
50
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
65
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
68
NUT
71
SCREW ELECTRIC CABLE TO HORN
74
MOUNTING BOW CABLE TO STARTING MOTOR,TERMINAL 50
92
BOOT CABLE TO STARTING MOTOR
95
COVERING STARTING CABLE TO UNIT PARTITION PANEL
98
RIVET
101
GROMMET STARTING CABLE THRU UNIT PARTITION PANEL, 201.A 248505 201.F 117576
104
NEG. CABLE FROM BATTERY NEG. POLE TO GROUND 220 MM
107
GROUND STRAP FROM ENGINE TO FRAME
110
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
110
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
110
SCREW , Replaced By: N304017008039
110
SCREW , Replaced By: N304017008016
113
SPRING WASHER , Replaced By: N000137008212
137
CABLE HARNESS FROM ALTERNATOR TO CABLE CONNECTOR
137
ELECTRIC CABLE FROM ALTERNATOR TO CABLE CONNECTOR, (A 548406) F 697647 TO BE ADAPTED DURING ASSEMBLY
140
NUT , Replaced By: N304032008006
140
NUT
140
NUT TACHOGRAPH TO BRACKET
143
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
143
LOCK WASHER T-FITTING TO BRACKET
146
SHEET METAL SCREW PRE-GLOW TIME RELAY TO STEERING COLUMN JACKET TUBE CONSOLE
149
BRACKET
152
SHEET METAL SCREW BRACKET TO CAB FLOOR
156
BOOT HEATER PLUGS
161
SOCKET-TERMINAL STRIP 3-POLE
164
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
164
SCREW , Replaced By: N007985004107
167
SCREW , Replaced By: N304017006034
167
SCREW COVER PLATE TO COVER PLATE M 6 X 10
170
LOCK WASHER T-FITTING TO BRACKET
173
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
176
SHEET METAL SCREW WINDOW SILL GIRDER LOWER PART,4 273689
179
GROMMET STARTING MOTOR BRANCH-OFF TO POS. CABLE
999
NEG. CABLE FROM SIDE MEMBER TO ENGINE
