Поз.
Артикул
Описание
10
FOOT PARKING BRAKE , ATTN.: REPLACE FASTENERS/NOTE WORKSHOP LITERATURE
10
FOOT PARKING BRAKE , ATTN.: REPLACE FASTENERS/NOTE WORKSHOP LITERATURE
10
PARKING BRAKE , ATTN.: REPLACE FASTENERS/NOTE WORKSHOP LITERATURE IMPORTANT: ALSO ORDER BRAKE PEDAL COVER, Replaced By: A2044201284
20
PAD PEDAL
20
PAD FOOT OPERATED PARKING BRAKE
40
DETENT GREY, COMPARE NEW PART WITH REMOVED PART
50
PIN , FROM MODEL YEAR'96
60
STOP , A 290167 EXCEPT CODE 805 ALSO INSTALLED IN VEHICLE TO A 290166 WITH CODE 806
70
SCREW W SOCKET DRIVE FASTENING, FOOT-OPERATED PARKING BRAKE M8X35
70
HEXAGON HEAD BOLT FASTENING, FOOT-OPERATED PARKING BRAKE M8X25
80
GUIDE
90
STOP ARMREST
100
TAPPING SCREW INSTRUMENT PANEL ON WAIST RAIL 4.2X19
110
HANDLE RELEASE HANDLE
120
CLIP FASTENER MOUNTING, FOOTWELL COVER DRIVER SIDE 4,2
150
BRAKE CABLE FRONT
150
BRAKE CABLE FRONT
160
CLAMP FRONT BRAKE CABLE TO TUNNEL
170
CLAMP
180
CONNECTION PIECE
200
BRAKE CABLE REAR
210
CONNECTION PIECE
220
BRAKE CABLE LEFT AND RIGHT, Replaced By: A2044202585
220
BRAKE CABLE LEFT AND RIGHT
220
BRAKE CABLE REAR LEFT
230
HEXALOBULAR BOLT TORSION BAR TO CARRIER M8X16
250
SUPPORT ON REAR SUBFRAME
260
SCREW BRACKET TO SIDE MEMBER M8X20
270
NUT BRACKET TO BATTERY IMPLEMENT CARRIER M8
300
BRACKET RIGHT, G 07831620130108 A 83849920130108 L 06638520121231 V 00516720121231 L 26231720130428
