Поз.
Артикул
Описание
2
HITCH MECHAN. DELY. RANGE (PARTS KIT),REAR CROSS MEMBER LFR. ORIS, A 440505 X 002382
2
HITCH MECHAN. DELY. RANGE (PARTS KIT),REAR CROSS MEMBER LFR. WESTFALIA, A 440506 X 002383
3
CAP FOR CLOSING THE RECEPTACLE WITH REMOVED BALL HEAD, A 328811 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO A 328810 WITH CODE 807
5
STIFFENING LEFT FA. ORIS, A 440505 X 002382
5
STIFFENING LEFT FA. WESTFALIA, A 440506 X 002383
8
STIFFENING RIGHT
8
STIFFENING RIGHT FA. ORIS, A 440505 X 002382
11
SHACKLE
12
SCREW BRACKET TO SIDE MEMBER
13
WASHER , Replaced By: N007349010007
13
WASHER STRUT TO CROSS MEMBER
14
NUT , Replaced By: N910113010000
14
NUT STRAP TO BRACKET
17
SCREW
20
GUIDE SIGN TRAILER COUPLING
20
GUIDE SIGN FOR DETACHABLE BALL HEAD, ON REAR LID OUTSIDE LEFT EDGE
26
BALL HEAD TRAILER COUPLING, A 364221 F 341903
26
BALL HEAD , A 440506 X 002383
29
CAP
32
TANK. DASHPOT BALL HEAD
