Поз.
Артикул
Описание
10
BACKREST FRAME LEFT REAR BACKREST
20
BACKREST FRAME RIGHT
30
PAD REAR SEAT BACKREST LEFT
40
PAD REAR SEAT BACKREST RIGHT
50
SEAT HEATING REAR SEAT BENCH BACKREST LEFT AND RIGHT
70
COVER REAR SEAT BACKREST LEFT
70
COVER REAR SEAT BACKREST LEFT
70
COVER REAR SEAT BACKREST LEFT, 9E38QFT218A2125 BLACK
70
COVER REAR SEAT BACKREST LEFT, 9H04 701A QFT218A2000 BLACK
70
COVER REAR SEAT BACKREST LEFT, 9E43QFT218A2126 BLACK
70
COVER REAR SEAT BACKREST LEFT, 9E38QFT218A2125 BLACK
70
COVER REAR SEAT BACKREST LEFT
70
COVER REAR SEAT BACKREST LEFT
70
COVER REAR SEAT BACKREST LEFT, 9E43QFT218A2126 BLACK
70
COVER REAR SEAT BACKREST LEFT
70
COVER REAR SEAT BACKREST LEFT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER REAR SEAT BACKREST RIGHT, 9E43QFT218A2126 BLACK
80
COVER REAR SEAT BACKREST RIGHT, 9E43QFT218A2126 BLACK
80
COVER REAR SEAT BACKREST RIGHT, 9H04 701A QFT218A2000 BLACK
80
COVER REAR SEAT BACKREST RIGHT, 9E38QFT218A2125 BLACK
80
COVER REAR SEAT BACKREST RIGHT, 9E38QFT218A2125 BLACK
80
COVER REAR SEAT BACKREST RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER REAR SEAT BACKREST RIGHT
85
PLATE DESIGNO, 7K71QFT204A2185 CHROME
110
REAR SEAT BACKREST OUTSIDE RIGHT
110
REAR SEAT BACKREST OUTSIDE RIGHT, 3E06 967A/977A/987A/997AQFT218A2119 CLASSIC RED
110
REAR SEAT BACKREST OUTSIDE RIGHT, 9D88 701A QFT218A2001 BLACK
110
REAR SEAT BACKREST OUTSIDE RIGHT
110
REAR SEAT BACKREST OUTSIDE RIGHT
120
BRACKET
130
HEXALOBULAR BOLT TIME-LAG RELAY M5X12
140
REAR SEAT BACKREST OUTSIDE LEFT, 9D88 701A QFT218A2001 BLACK
140
REAR SEAT BACKREST OUTSIDE LEFT
140
REAR SEAT BACKREST OUTSIDE LEFT
140
REAR SEAT BACKREST OUTSIDE LEFT, 3E06 967A/977A/987A/997AQFT218A2119 CLASSIC RED
140
REAR SEAT BACKREST OUTSIDE LEFT
150
PANELING ARMREST SLOT
160
PANELING ARMREST SLOT
170
FOLDING ARMREST
170
FOLDING ARMREST
170
FOLDING ARMREST
170
FOLDING ARMREST
180
HEXALOBULAR BOLT TIME-LAG RELAY M5X12
190
DETENT ARMREST
200
PLATE ARMREST RETAINER
220
GUIDE WITHOUT RELEASE, LEFT SEAT
220
GUIDE WITH UNLOCKING MECHANISM
250
LINING LEFT REAR BACKREST, 9F08QFT204A2500 SINGLE TONE BLACK
260
LINING RIGHT REAR BACKREST, 9F08QFT204A2500 SINGLE TONE BLACK
270
PIN TO BACKREST FRAME, LEFT
280
BEARING CENTRAL
290
HEXALOBULAR BOLT HORN TO BRACKET M10X20,V 207570
300
HEXALOBULAR BOLT TIME-LAG RELAY M5X12
340
LOCK FOR SEAT CUSHION LEFT REAR BACKREST
345
LEVER LEFT RELEASE HANDLE, 9051QFT204A2420 BLACK
345
LEVER RELEASE HANDLE, RIGHT, 9051QFT204A2420 BLACK
350
HEXALOBULAR BOLT AIR CLEANER TO BRACKET
360
CLAMP
370
LIMIT SWITCH BACKREST LOCKING MECHANISM,RIGHT
380
RIVET SWITCH TO BEARING AT RIGHT
390
PIVOT BEARING OUTSIDE RIGHT
390
PIVOT BEARING OUTSIDE LEFT
400
HEXALOBULAR BOLT BRACKET TO BRACKET M 10X30
410
BEARING BOLT LEFT OUTSIDE
450
MOUNTING BRACKET ARMREST SLOT
460
MOUNTING BRACKET RIGHT BACKREST, OUTER
460
MOUNTING BRACKET LEFT, INNER RIGHT
470
CLIP
900
CONNECTOR HOUSING REAR LEFT DOOR SEPARATION POINT 2-PIN SLK2.8,X35/3
