Поз.
Артикул
Описание
2
AXLE HOUSING , 309.370-391 FROM CHASSIS 012169,309.4 FROM CHASSIS 085136
2
AXLE HOUSING , 309.370-391 UP TO CHASSIS 012168,309.4 UP TO CHASSIS 085135
4
SCREW SUPPORTING ARM TO ENGINE M 16X65
5
PIN
6
PLUG
7
THRUST RING LEFT
10
OIL COLLECTOR
12
SPACER WASHER
13
GROOVED NUT
13
NUT , Replaced By: A6743560126
14
LOCK PLATE
18
DRUM HUB
18
DRUM HUB , Replaced By: A3103560002, +006A3094020271, +008A3149900105
19
STUD
20
WHEEL MOUNTING BOLT
21
OIL COLLECTOR
21
OIL COLLECTOR , Replaced By: A3163560082
25
SEAL RING , Replaced By: A0179970147
25
SEAL RING
26
SPACER RING , ELIMINATED,NO LONGER REQUIRED
27
TAPERED ROLLER BEARING
27
TAPERED ROLLER BEARING
27
TAPERED ROLLER BEARING
28
LOCK RING
29
TAPERED ROLLER BEARING
29
TAPERED ROLLER BEARING
29
TAPERED ROLLER BEARING
33
REAR AXLE SHAFT , 309.370-391 UP TO CHASSIS 012168,309.4 UP TO CHASSIS 085135
33
REAR AXLE SHAFT , 309.370-391 FROM CHASSIS 012169,309.4 FROM CHASSIS 085136
33
REAR AXLE SHAFT , Replaced By: A3103570601
35
SCREW COLLAR
36
LOCK
38
SET SCREW
38
SET SCREW , Replaced By: A3143530176
39
SLIDE
40
HEX. NUT. NUT
42
GASKET REAR A 324 350 01 21,318 350 00 21
42
GASKET REAR TO 670 350 00 21
43
COVER REAR
43
COVER , Replaced By: A6703510208
44
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
45
SCREW COVER TO REAR AXLE HOUSING TO 615 350 04 21,615 351 07 08
45
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
45
SCREW , Replaced By: N304017010028
65
CYLINDR. ROLLER BEARING , 309.370-391 UP TO CHASSIS 012168,309.4 UP TO CHASSIS 085135
65
CYLINDR. ROLLER BEARING , 309.370-391 FROM CHASSIS 012169,309.4 FROM CHASSIS 085136
65
CYLINDR. ROLLER BEARING , 309.370-391 FROM CHASSIS 012169,309.4 FROM CHASSIS 085136
65
CYLINDR. ROLLER BEARING , 309.370-391 UP TO CHASSIS 012168,309.4 UP TO CHASSIS 085135
65
CYLINDR. ROLLER BEARING
65
CYLINDR. ROLLER BEARING , 309.370-391 FROM CHASSIS 012169,309.4 FROM CHASSIS 085136
66
LOCK RING
66
LOCK RING BEARING BRACKET,4 972621
67
SNAP RING
68
SPACER WASHER0.20 MM
68
SPACER WASHER0.10 MM
68
SPACER WASHER0.50 MM
68
SPACER WASHER , Replaced By: A3143536652
70
TAPERED ROLLER BEARING
71
SPACER RING
72
SPACER RING9.22 MM
72
SPACER RING9.48 MM
72
SPACER RING9.00 MM
72
SPACER RING9.16 MM
72
SPACER RING9.20 MM
72
SPACER RING9.36 MM
72
SPACER RING9.44 MM
72
SPACER RING8.96 MM
72
SPACER RING9.50 MM
72
SPACER RING9.08 MM
72
SPACER RING9.32 MM
72
SPACER RING9.54 MM
72
SPACER RING9.28 MM
72
SPACER RING9.12 MM
72
SPACER RING9.40 MM
72
SPACER RING9.04 MM
72
SPACER RING9.52 MM
72
SPACER RING9.56 MM
72
SPACER WASHER , Replaced By: A6733533251
72
SPACER WASHER , Replaced By: A6733533451
72
SPACER WASHER , Replaced By: A6733533651
72
SPACER WASHER , Replaced By: A6733533851
72
SPACER WASHER , Replaced By: A6733534051
72
SPACER WASHER , Replaced By: A6733534251
72
SPACER WASHER , Replaced By: A6733534451
72
SPACER WASHER , Replaced By: A6733534551
72
SPACER WASHER , Replaced By: A6733534651
72
SPACER WASHER , Replaced By: A6733534851
72
SPACER WASHER , Replaced By: A6733535051
72
SPACER WASHER , Replaced By: A6733535251
72
SPACER WASHER , Replaced By: A6733535451
72
SPACER WASHER , Replaced By: A6733535651
72
SPACER WASHER , Replaced By: A6733535851
72
SPACER WASHER , Replaced By: A6733535951
72
SPACER WASHER , Replaced By: A6733536051
72
SPACER WASHER , Replaced By: A6733536151
72
SPACER WASHER , Replaced By: A6733536251
72
SPACER RING9.24 MM
76
SPACER RING
77
SCREW COLLAR , Replaced By: A3163530025
77
SCREW COLLAR
78
SEAL RING
78
SEAL RING
78
SEAL RING , Replaced By: A0019973247
78
SEAL RING , Replaced By: A0119977447
78
SEAL RING
79
SEAL RING , Replaced By: A0019973247
79
LOCK
80
FLANGE
80
FLANGE , Replaced By: A3163500045
81
PROTECTIVE PLATE
82
NUT
82
NUT , Replaced By: A3853510372
999
TAPERED ROLLER BEARING DRIVE PINION BEARING
999
SPACER RING AS REQUIRED 12.60 MM,001448,309.0, 019706,309.1 UP TO IDENT NO.180280,FROM IDENT NO.180281,SEE UNIT MICROFICHE,MODEL:741.0
999
AXLE HOUSING , Replaced By: A3103502420
999
THRUST RING RIGHT
999
DIFFERENTIAL SPIDER , Replaced By: A3093530020
999
NUT , Replaced By: N308673012002
999
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
