Поз.
Артикул
Описание
6
VALVE DRAIN, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
6
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004295444
12
REPAIR KIT DRAIN VALVE
17
BRACKET
24
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
24
SCREW , Replaced By: N304017008016
29
NUT , Replaced By: N913004008001
35
LINE FROM FITTING TO VALVE 6X1 MM, LENGTH AVAILABLE 3000 MM
40
UNION NUT
46
GLAND , Replaced By: A0019901667
51
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236
51
FITTING , Replaced By: A0039972072
51
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
57
CONNECTION FITTING , Replaced By: A0039979172
57
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
62
SEAL RING LINE CONNECTION
68
SEAL RING LINE CONNECTION
73
LINE FROM EXPANSION TANK TO HEATING PIPE 8X1 MM, ORDER BY THE METER
79
UNION NUT LINE CONNECTION
84
GLAND LINE CONNECTION
89
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
94
FITTING LINE CONNECTION
94
SCREW-IN FITTING LINE CONNECTION
94
FITTING LINE CONNECTION, Replaced By: N000000006446
100
SEAL RING LINE CONNECTION
999
VALVE , Replaced By: A0004320807
999
SEALING CORD9.2X3.5,TO A 003 429 35 44, NOT USED
999
REPAIR KITTO 003 429 35 44, NOT USED
999
SEAL RING17X3.5,TO A 003 429 35 44, NOT USED
999
SEAL RINGWABCO
999
SEAL RING22.3X2.4,TO A 003 429 35 44, NOT USED
999
FITTING , Replaced By: A0009970171
