Поз.
Артикул
Описание
5
AXLE HOUSING , 000,001,010 FROM CHASSIS 016332, 100,101,110 FROM CHASSIS 022884 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
9
SCREW PLUG , Replaced By: A0009972632
11
DIFFERENTIAL GEAR
15
RING , 000,001,010 FROM REAR AXLE 088703, 100,101,110 FROM REAR AXLE 037328
17
THRUST WASHER AS REQUIRED 1,3 MM
19
SIDE GEAR LEFT
21
DIFFERENTIAL PINION RIGHT
25
DIFFERENTIAL PINION
29
SPHERICAL WASHER
35
PIN
37
PIN
39
RING GEAR AND PINION RATIO: 1:4.08
41
REPAIR KIT
42
SCREW
45
TAPERED ROLLER BEARING DRIVE SHAFT
47
SPACER WASHER 1.8 MM
51
SCREW COLLAR
53
LOCK
57
LOCK
61
SCREW , Replaced By: N304017006018
61
SCREW COVER PLATE TO COVER PLATE M 6 X 12
65
TAPERED ROLLER BEARING
69
SPACER BUSHING
72
TAPERED ROLLER BEARING
75
SPACER WASHER 0.80 MM
79
COVER , 000,001,100,101 FROM REAR AXLE 000287, 010 FROM REAR AXLE 129303, 110 FROM REAR AXLE 087840
81
SCREW , 000,001,100,101 FROM REAR AXLE 000287, 010 FROM REAR AXLE 129303, 110 FROM REAR AXLE 087840
85
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
87
SEAL RING
89
GROOVED NUT
90
LOCK
95
SCREW CABLE HARNESS MOUNTING
99
LOCK WASHER TAIL LAMP TO BRACKET
130
JOINT
132
SPACER WASHER
135
LOCK
139
SLEEVE , ON TYPE 200 FROM CHASSIS 146362, ON TYPE 200 D FROM CHASSIS 254146, ON TYPE 230 FROM CHASSIS 007970
142
ROLLERTO 387 460 14 09
147
SPACER WASHER
151
LOCK RING AS REQUIRED 1.75 MM
165
UNIVERSAL JOINT , 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
169
SNAP RING 2.15 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
172
SCREW PLUG
175
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
179
SPACER WASHER 1.0 MM
195
REAR AXLE SHAFT LEFT, 000,001,100,101 FROM REAR AXLE, 010 FROM REAR AXLE 169909, 110 FROM REAR AXLE 165459
205
LOCK
207
GROOVED NUT
215
BRAKE DRUM
217
REPAIR KIT
999
TAPERED ROLLER BEARING
999
TAPERED ROLLER BEARING
999
BARREL-TYPE BEARING
999
SEAL RING
999
BRACKET LEFT
999
BRACKET RIGHT
999
DIFFERENTIAL PINION , NO LONGER AVAILABLE
999
FLANGE
999
THRUST WASHER , 000 AMBULANCE 001 SPECIAL BODIES UP TO CHASSIS 077733
999
AXLE HOUSING , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
JOINT , Replaced By: A1103500413, +001A1109970032
999
THRUST ARM RIGHT
999
SPACER RING REAR SUBFRAME MOUNTING, 004976
999
RUBBER MOUNTING
999
SIDE GEAR , NO LONGER AVAILABLE
999
DIFFERENTIAL CASE , NO LONGER AVAILABLE
999
REAR AXLE SHAFT RIGHT, 000,001,100,101 FROM REAR AXLE 002173, 010 FROM REAR AXLE 216044, 110 FROM REAR AXLE 252542
999
JOINT , ON TYPE 200 UP TO CHASSIS 146361, ON TYPE 200 D UP TO CHASSIS 254145, ON TYPE 230 UP TO CHASSIS 007969
999
REAR AXLE , Replaced By: A1103500203
999
LOCK
999
SCREW
999
UNIVERSAL JOINT , 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640, Replaced By: A1123500128, +001A1109970032
999
RUBBER MOUNTING
999
PAD
999
THRUST WASHER 1.7 MM
999
THRUST WASHER AS REQUIRED 1.6 MM
999
THRUST WASHER AS REQUIRED 1,5 MM
999
THRUST WASHER AS REQUIRED 1,4 MM
999
SPACER WASHER 1.9 MM
999
SPACER WASHER 2.0 MM
999
SPACER WASHER 2.1 MM
999
SPACER WASHER 2.2 MM
999
SPACER WASHER 0.90 MM
999
SPACER WASHER 1.00 MM
999
SPACER WASHER 1.10 MM
999
SPACER WASHER 1.20 MM
999
SPACER WASHER 1.30 MM
999
SPACER WASHER 1.40 MM
999
SPACER WASHER 1.50 MM
999
SPACER WASHER 1.7 MM
999
SPACER WASHER 2.0 MM
999
SPACER WASHER 2.1 MM
999
SPACER WASHER 2.2 MM
999
SPACER WASHER 2.3 MM
999
SPACER WASHER 2.4 MM
999
SPACER WASHER 2.5 MM
999
SPACER WASHER 3.0 MM
999
LOCK
999
LOCK
999
LOCK
999
LOCK
999
THRUST WASHER , Replaced By: A1153531062
999
THRUST WASHER , Replaced By: A1153530962
999
THRUST WASHER , Replaced By: A1153530862
999
SPACER WASHER 1.1 MM
999
SPACER WASHER 1.2 MM
999
SPACER WASHER 1.3 MM
999
SPACER WASHER 1.4 MM
999
SPACER WASHER 1.5 MM
999
SPACER WASHER 1.6 MM
999
SPACER WASHER 1.7 MM
999
SPACER WASHER 1.8 MM
999
SPACER WASHER 1.9 MM
999
SPACER WASHER 2.0 MM
999
SNAP RING 2.25 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.35 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.45 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.55 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
WASHER MOUNTING PLATE TO BODY FLOOR
999
LOCK RING SHACKLE TO BEARING BRACKET,965965
999
SCREW , Replaced By: N304017008021
999
NUT , Replaced By: N304032008006
999
SCREW PISTON ON TRAILING AXLE
999
SCREW AIR CLEANER SUPPORT TO SIDE MEMBER, FRONT,K 000844
999
SCREW PIPE CLAMP
999
NUT
999
CLAMP REAR AXLE TUBE
999
CLAMP REAR AXLE HOUSING
