Поз.
Артикул
Описание
3
DOOR SHELL RIGHT
6
HINGE TOP RIGHT, 000,001,004,010 FROM CHASSIS 026626 ALSO INSTALLED ON,SEE FOOTNOTE 002,100,101,104,110 FROM CHASSIS 036695 ALSO INSTALLED ON,S EE FOOTNOTE 003
9
HINGE BOTTOM RIGHT
11
GREASE NIPPLE
14
SCREW INTERMEDIATE BEARING TO CAB FLOOR
17
DOOR CHECK
21
EDGING
23
BUFFER
25
RUBBER BUFFER AS REQUIRED,5.5 MM, 000,001,002,003,004,005,010,011 FROM CHASSIS 066085,100,101,104,110 FROM CHASSIS 102826
27
DOOR LOCK RIGHT
29
EDGING RIGHT
31
ROD
34
LOCK PULL ROD TO DOOR LOCK
35
CLIP
35
CLIP , Replaced By: A0069886378
37
DOOR LOCKING DEVICE
41
LOCKING EYE RIGHT
45
PLATE 2.0 MM 2.0 MM, TO BE ADAPTED DURING ASSEMBLY
45
PLATE , Replaced By: A1007230211
49
INTERIOR HANDLE ASSEMBLY RIGHT, 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
51
ESCUTCHEON RIGHT, 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
53
INSERT , 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
56
KNOB , 023 116973 033 048510 123 097280 130 120563
61
DOOR HANDLE OUTSIDE LEFT
68
PIN
71
KEY WITH LETTER "T", STATE LETTER AND NUMBER OF LOCK WHEN ORDERING
75
PAD
79
PAD
79
PAD , Replaced By: A1207660005
81
SCREW , Replaced By: N000912006095
81
SCREW DOOR HANDLE TO DOOR
83
PIN DOOR CHECK
85
LOCK DOOR CHECK TO FRONT PANEL PILLAR
86
VENTILATOR WINDOW RIGHT
89
SEAL RIGHT
91
VENTILATOR WINDOW RIGHT, 000,001,004,010 UP TO CHASSIS 123344,100,101,104,110 UP TO CHASSIS 204483,UPPER PIVOT PIN TO BE SHORTENED BY 3 MM
98
FASTENER RIGHT, 000,001,004,010 UP TO CHASSIS 188163,100,101,104,110 UP TO CHASSIS 352145,002,003,005,011 UP TO CHASSIS 031993
101
KNOB , 000,001,004,010 UP TO CHASSIS 188163,100,101,104,110 UP TO CHASSIS 352145,002,003,005,011 UP TO CHASSIS 031993
101
KNOB , Replaced By: A0008331213
103
CAP , 000,001,004,010 UP TO CHASSIS 188163,100,101,104,110 UP TO CHASSIS 352145,002,003,005,011 UP TO CHASSIS 031993
104
GUIDE RAIL RIGHT
106
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
111
SEALING SECTION 2040 MM, ORDER BY THE METER
113
CLIP
115
CAP , 000,001,004,010 FROM CHASSIS 125855-158417,100,101,104,110 FROM CHASSIS 213806-280560,002,003,005,011 UP TO CHASSIS 015311
119
SEAL , FROM CHASSIS: 010 076074 110 193042 017,117 000001
119
SEAL , Replaced By: A1167250198
119
SEAL , Replaced By: A1157251298
121
WINDOW REGULATOR RIGHT, FROM CHASSIS 041712
124
SPRING
124
SPRING , Replaced By: A0007680734
127
WINDOW REGULATOR RAIL
129
REPAIR KIT
129
REPAIR KIT , Replaced By: A1237200114
131
REPAIR KIT , Replaced By: A1237200114
131
REPAIR KIT
134
REPAIR KIT
134
REPAIR KIT , Replaced By: A1237200114
137
GLASS PANE
141
RETAINING RAIL
142
RUBBER MOULDING 290 MM, 100001
146
CRANK , 000,001,004,010 UP TO CHASSIS 188465,100,101,104,110 UP TO CHASSIS 352550,002,003,005,011 UP TO CHASSIS 032300 EXCEPT FOR SEE FOOTN.25
148
COVERING , STATE COLOR NUMBER WHEN ORDERING
148
COVERING , Replaced By: A1237600120
148
PAD , Replaced By: A1237600020
152
WASHER
156
SEALING SECTION , Replaced By: A1157250965
158
CLIP DOOR OUTSIDE
161
CLIP , 008309
164
PANELLING BOTTOM RIGHT, 000,001,004,010 BROWN AND GREY FINISH FROM CHASSIS 023787,BLUE FINISH FROM CHASSIS 025263 ALSO INSTALLED ON,SEE FOOTNOTE 033
168
CLIP
168
CLIP , Replaced By: A0029884578
171
INSULATION
171
INSULATION , Replaced By: A1107270390
171
INSULATION , Replaced By: A1237270090
171
INSULATION , Replaced By: A2106820008
171
INSULATION
174
WEATHERSTRIP RIGHT
178
CLIP SEAL TO REAR DOOR
180
EDGE GUARD SECTION RIGHT
181
COVERING , Replaced By: A1107270288
185
SEAL RIGHT,CENTRAL PILLAR
195
GARNISH MOULDING REAR RIGHT
198
SEAL
201
GARNISH MOULDING RIGHT, 000,001,004,010 FROM CHASSIS 017591,100,101,104,110 FROM CHASSIS 024477
203
BRACKET , 000,001,004,010 UP TO CHASSIS 017590,100,101,104,110 UP TO CHASSIS 024476
205
GROMMET , 000,001,004,010 FROM CHASSIS 098313,100,101,104,110 FROM CHASSIS 160718
209
FASTENER BUTTON
209
GROMMET , Replaced By: A0019882081
209
FASTENER BUTTON , Replaced By: A0089970381
209
FASTENER BUTTON. GROMMET , Replaced By: A0019882081
211
FASTENER BUTTON UPPER PART
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
NUT BATTERY MOUNTING
999
SCREW PIPE CLAMP
999
SCREW PUMP TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
SCREW
999
SCREW
999
SCREW
999
SCREW
999
SCREW
999
SCREW APPARATUS PLATE TO CAB,K 062140
999
SCREW , Replaced By: N000000001145
999
SCREW ,K 062140, Replaced By: N007985006580
999
SCREW
999
SCREW
999
SCREW
999
SHEET METAL SCREW , Replaced By: N000000002062
999
TOOTHED WASHER MASKED STOP LAMP
999
TOOTHED WASHER CABLE TO FUSE BOX
999
CONICAL SPRING WASHER
999
NUT CYLINDER TO BRACKET TO0002902112
999
NUT BALL PIVOT TO LEVER
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SCREW , Replaced By: N304017008021
999
SCREW COVER PLATE TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
LOCK WASHER TAIL LAMP TO BRACKET
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
SCREW
999
SCREW BRACKET TO COVERING
999
RUBBER RING EMERGENCY LANTERN TO CAB
999
WASHER
999
WASHER , Replaced By: A1809900640
999
SEAL RING , Replaced By: A2019870241
999
CRANK
999
SEAL INSIDE 4000 MM
999
MOLDED PIECE , Replaced By: A0029888378
999
SLIDE , Replaced By: A1155860072
999
SEALING RAIL 2200 MM
999
WINDOW REGULATOR LEFT
999
REPAIR KIT , Replaced By: A1237200114
999
DISC SPRING
999
RUBBER BUFFER 8.5 MM AS REQUIRED, 000,001,002,003,004,005,010,011 FROM CHASSIS 066085,100,101,104,110 FROM CHASSIS 102826
999
RUBBER BUFFER 7.5 MM AS REQUIRED, 000,001,002,003,004,005,010,011 FROM CHASSIS 066085,100,101,104,110 FROM CHASSIS 102826
999
RUBBER BUFFER PIN BUSHING
999
PANELLING BOTTOM LEFT, 000,001,004,010 BROWN AND GREY FINISH FROM CHASSIS 023787,BLUE FINISH FROM CHASSIS 025263 ALSO INSTALLED ON,SEE FOOTNOTE 033
999
NUT , ON SPECIAL REQUEST,FOR ELECTRICALLY OPERATED WINDOW REGULATORS
999
PAD , Replaced By: A1087680095
999
WASHER , Replaced By: A1087680113
999
DOOR HANDLE OUTSIDE RIGHT
999
ESCUTCHEON LEFT, 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
999
INTERIOR HANDLE ASSEMBLY LEFT FRONT DOOR, 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
999
KNOB , 000,001,004,010 FROM CHASSIS 188164,100,101,104,110 FROM CHASSIS 352146,002,003,005,011 FROM CHASSIS 031994
999
CAP
999
DOOR LOCK LEFT
999
GARNISH MOULDING LEFT, 000,001,004,010 FROM CHASSIS 017591,100,101,104,110 FROM CHASSIS 024477
999
SEAL LEFT,CENTRAL PILLAR
999
COVERING FRONT PANEL PILLAR
999
WINDOW REGULATOR ELECTRIC,RIGHT, ON SPECIAL REQUEST,FOR ELECTRICALLY OPERATED WINDOW REGULATORS
999
WINDOW REGULATOR ELECTRIC,LEFT, ON SPECIAL REQUEST,FOR ELECTRICALLY OPERATED WINDOW REGULATORS
999
PANELLING , Replaced By: A1117201651
999
PANELLING , Replaced By: A1117201551
999
GLASS PANE FRONT DOOR CRANK OPERATED WINDOW
999
WINDOW REGULATOR , Replaced By: A1157251002, +001A1237600102, +001A1237600020, +001A1087680113
999
SEAL LEFT
999
WINDOW REGULATOR , Replaced By: A1157250902, +001A1237600102, +001A1237600020, +001A1087680113
999
EDGING , Replaced By: A1087230224
999
EDGING , Replaced By: A1087230124
999
PLATE 2.6 MM
999
CAP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1107230824
999
LOCK RIGHT
999
VENTILATOR WINDOW LEFT, 000,001,004,010 UP TO CHASSIS 123344,100,101,104,110 UP TO CHASSIS 204483,UPPER PIVOT PIN TO BE SHORTENED BY 3 MM
999
LOCK LEFT
999
VENTILATOR WINDOW LEFT
999
LOCKING EYE LEFT
999
VENTILATOR WINDOW RIGHT FRONT DOOR
999
VENTILATOR WINDOW LEFT FRONT DOOR
999
VENTILATOR WINDOW RIGHT FRONT DOOR
999
VENTILATOR WINDOW LEFT FRONT DOOR
999
GUIDE RAIL LEFT
999
DOOR SHELL LEFT
999
FASTENER RIGHT, 000,001,004,010 FROM CHASSIS 188164,100,101,104,110 FROM CHASSIS 352146,002,003,005,011 FROM CHASSIS 031994
999
GARNISH MOULDING REAR LEFT
999
FASTENER LEFT, 000,001,004,010 FROM CHASSIS 188164,100,101,104,110 FROM CHASSIS 352146,002,003,005,011 FROM CHASSIS 031994
999
HINGE TOP LEFT, 000,001,004,010 FROM CHASSIS 026626 ALSO INSTALLED ON,SEE FOOTNOTE 002,100,101,104,110 FROM CHASSIS 036695 ALSO INSTALLED ON,S EE FOOTNOTE 003
999
DOOR CHECK , Replaced By: A1107200816
999
ROD RIGHT FRONT DOOR, ON SPECIAL REQUEST, PULL ROD WITH ADDIT. LOCKING MECHANISM
999
EDGE GUARD SECTION LEFT
999
ROD LEFT FRONT DOOR
999
WEATHERSTRIP LEFT
999
FASTENER LEFT, 000,001,004,010 UP TO CHASSIS 188163,100,101,104,110 UP TO CHASSIS 352145,002,003,005,011 UP TO CHASSIS 031993
999
HINGE BOTTOM LEFT
999
ESCUTCHEON RIGHT
999
ESCUTCHEON LEFT
999
INSERT RIGHT
999
INSERT LEFT
999
INTERIOR HANDLE ASSEMBLY RIGHT
999
INTERIOR HANDLE ASSEMBLY LEFT, 000,001,004,010 FROM CHASSIS 188150,100,101,104,110 FROM CHASSIS 352119,002,003,005,011 FROM CHASSIS 031990
999
CRANK , 000,001,004,010 FROM CHASSIS 188466,100,101,104,110 FROM CHASSIS 352551,002,003,005,011 FROM CHASSIS 032301 ALSO INSTALLED ON SEE FOOTN.25, Replaced By: A1237600102, +001A1237600020
999
EDGING
999
ADHESIVE TAPE , Replaced By: A0019875646
999
SEALING CORD PAINT RUN-OFF HOLE IN REAR WINDOW OPENING, ORDER BY THE METER
999
LOCK. SHEET METAL NUT PLATE TO FRAME,V 202043
999
LOCK LEATHER & IMITATION LEATHER
999
LOCK , Replaced By: A1155860072
