Поз.
Артикул
Описание
1
SWITCH
1
SWITCH , Replaced By: A1088210751
3
PIN BUSHING HOUSING , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
3
PLUG , Replaced By: A0085453728, +002A0035452626, +001A0085453828
5
PLUG
5
PLUG
5
PIN BUSHING HOUSING UNIPOLAR, FROM CHASSIS:107.023 000429 107.043 006834 107.044 004104
7
PLUG HOUSING
7
PLUG , Replaced By: A0095454028, +002A0015453826, +001A0095454128
9
CLIP ATTACHMENT,BRANCH-OFFS
11
LOOM TIE
13
CLIP PLUG TO REAR PILLAR
16
PLUG STOP LIGHT SWITCH,BIPOLAR
22
SCREW REAR PANEL,BELOW REAR SEAT
24
COVERING LEFT
25
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
29
CABLE GROMMET
31
KNOB BLOWER SWITCH
31
KNOB , Replaced By: A1158200392
39
ELECTRIC CABLE , Replaced By: A1078200117
39
ELECTRIC CABLE , 027312
42
ELECTRIC MOTOR , Replaced By: A1158201642
44
ELECTRIC MOTOR WITH INTERMITTENT ACTION, 100000
48
CARBON BRUSH SET
51
CRANK
53
SWITCH BOSCH, 100000
55
RIVET BRACKET TO CAB
55
RIVET , Replaced By: N007340003124
57
NUT CYLINDER TO BRACKET TO0002902112
57
NUT BATTERY MOUNTING
59
TOOTHED WASHER MASKED STOP LAMP
60
RUBBER RING SIGNAL LAMP TO ROOF
62
LINKAGE
64
ROD
65
SCREW COVER PLATE TO COVER PLATE M 6 X 12
65
SCREW , Replaced By: N304017006018
66
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
67
CONTACTOR
68
WASHER COMPRESSED AIR LINE TO BRACKET
68
WASHER , Replaced By: N009021006208
69
SCREW COVER PLATE TO BRACKET
70
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
71
PAD
73
WASHER
75
RUBBER RING
86
WIPER RUBBER
86
WIPER BLADE
88
WIPER RUBBER
89
WIPER ARM RIGHT, 013525
89
WIPER ARM , Replaced By: A1158201444
90
WASHER WIPER BEARING
92
NUT WIPER BEARING
94
CAPSULE
96
NUT , 000,001,004,010 FROM CHASSIS 061444,100,101,104,110 FROM CHASSIS 094839
98
WASHER
99
CIGAR LIGHTER
102
ELEMENT
104
INCANDESCENT SPIRAL , Replaced By: A0008250252
104
INCANDESCENT SPIRAL , FROM CHASSIS:114.005,007,008,015,017 028985 114.010 027703 115.000,002,010 030096 115.015 027738 115.100,102,103,110,112 066741 115.115 030607
107
CIGAR LIGHTER , FROM CHASSIS: 034089, ALSO INSTALLED ON: 033673,033706,033709,033716,033736,033765,033914,033922,033926,033930,033931,033934,033936,033938, 033939,033941-033951,033953,033955,033956,033959,033960,033962,033964,033966,033967,033969-033998, 034000-034010,034012-034022,034024-034087.
112
ELEMENT CIGAR LIGHTER
113
INCANDESCENT SPIRAL , FROM CHASSIS:114.005,007,008,015,017 028985 114.010 027703 115.000,002,010 030096 115.015 027738 115.100,102,103,110,112 066741 115.115 030607
113
INCANDESCENT SPIRAL , Replaced By: A0008250252
114
LOCK
117
DOME LAMP FRONT
119
INTERIOR LAMP
119
DOME LAMP , Replaced By: A1238200501
120
BULB INTERIOR LAMP K-12V 10W
121
CONTACTOR , 100000
121
CONTACTOR , UP TO CHASSIS: 114.011,060,062 100000 114.015 200000 115.015,115 200000 115.110 400000 114.010,115.010 UNTIL PRODUCTION STOP,TYPES 108,109,110,111 UNTIL PRODUCTION STOP
124
SWITCH DOOR CONTACT
124
SWITCH , Replaced By: A2018202110
124
CONTACTOR , Replaced By: A2018201110
124
CONTACTOR , Replaced By: A0008213252
124
CONTACTOR , Replaced By: A0008213152
127
BULB2W
128
SWITCH
135
INTERIOR LAMP
138
BULB5 W
138
BULB5 W, Replaced By: N072601012703
139
SHEET METAL SCREW BRACKET TO CAB FLOOR
140
INTERIOR LAMP GLOVE COMPARTMENT
140
INTERIOR LAMP , Replaced By: A1268201301
140
LAMP , Replaced By: A1238200101
142
BULB12V/5W
144
CONTACTOR
146
NUT
146
NUT , 100000
226
PULSE SENDER UNIT HAZARD WARNING LIGHT SENDER UNIT, FROM CHASSIS: 000,002,010 030096 015 027774 100,102,103,110,112 170998 115 081981
226
SENDER UNIT , FROM CHASSIS: 034089, ALSO INSTALLED ON: 033673,033706,033709,033716,033736,033765,033914,033922,033926,033930,033931,033934,033936,033938, 033939,033941-033951,033953,033955,033956,033959,033960,033962,033964,033966,033967,033969-033998, 034000-034010,034012-034022,034024-034087.
226
PULSE SENDER UNIT. SENDER UNIT , FROM CHASSIS: 023 007245 ALSO INSTALLED ON 007095,007113,007119,007120,007156,007228,007231,007238,007240,007242,007243.
226
SENDER UNIT ELECTRONIC MAKE, INAPPLICABLE TO U.S. VEHICLES
227
BULB , Replaced By: A6885447093
229
KNOB , Replaced By: A1158201792
229
KNOB
231
ESCUTCHEON
999
NUT
999
BULB12 V
999
BULB5 W, Replaced By: N072601012703
999
BULB35 W,5 223777
999
BULB12 V
999
BULB12 V 18 W, 846814
999
BULB , ON CAB 344
999
WASHER , Replaced By: N009021006208
999
SHEET METAL SCREW COVERING TO HOUSING
999
SHEET METAL SCREW BRACKET TO WINDOW SILL
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
LENS RIGHT, UP TO CHASSIS: 015,115 200000 110 400000 FROM CHASSIS: 010 079808 015 092257 110 203813 112 204779 115 099682
999
SEAL , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0008260967
999
SEAL , Replaced By: A1158260258
999
SEAL , Replaced By: A1158260158
999
REFLECTOR RIGHT, UP TO CHASSIS: 015,115 200000 110 400000 FROM CHASSIS: 010 079808 015 092257 110 203813 112 204779 115 099682
999
REFLECTOR RIGHT, UP TO CHASSIS: 010 079807 015 092256 110 203812 112 204778 115 099681
999
RIM RIGHT, UP TO CHASSIS: 015,115 200000 110 400000
999
SEAL RIGHT, UP TO CHASSIS: 015,115 200000 110 400000
999
LENS , Replaced By: A1158261456
999
LENS , Replaced By: A1158261356
999
LAMP , Replaced By: A1238200101
999
CIGAR LIGHTER , Replaced By: A1158250153
999
ELECTRIC CABLE , Replaced By: A1158211810
999
ELECTRIC CABLE , Replaced By: A1158212010
999
ELECTRIC CABLE , Replaced By: A1158211810
999
ELECTRIC CABLE , Replaced By: A1158211810
999
CABLE GROMMET RIGHT
999
COVERING , Replaced By: A1158210336
999
COVERING IN LUGGAGE COMPARTMENT, FRONT RIGHT
999
ELECTRIC CABLE , Replaced By: A1158211810
999
COVERING , Replaced By: A1158210336
999
TAIL LAMP RIGHT, UP TO CHASSIS: 015,115 200000 110 400000 FROM CHASSIS: 010 079808 015 092257 110 203813 112 204779 115 099682
999
WIPER ARM , Replaced By: A1158201344
999
TAIL LAMP RIGHT
999
WIPER ARM LEFT, 005446
999
WIPER ARM , Replaced By: A1158200244
999
LIGHTING UNIT
999
WIPER ARM , Replaced By: A1158200144
999
TAIL LAMP RIGHT
999
WIPER ARM , Replaced By: A1158201444
999
WIPER ARM , Replaced By: A1158201344
999
LINKAGE , Replaced By: A1158200443
999
APPARATUS PANEL , Replaced By: A1158200443
999
ELECTRIC MOTOR , Replaced By: A1158200142
999
NUT TAIL LAMP SHELL TO TAIL
999
CIGAR LIGHTER , Replaced By: A1158250253
999
ELEMENT , Replaced By: A0008250551
999
ESCUTCHEON
999
KNOB
999
ELECTRIC CABLE , 027312
999
LENS
999
SWITCH
999
CARDBOARD3 MM, ORDER BY THE METER
999
SEAL
999
SEAL , Replaced By: A0008267680
999
SEAL
999
LAMP SOCKET , Replaced By: A0008264082
999
LAMP SOCKET HEADLAMP
999
REFLECTOR BLINKER LIGHT
999
REFLECTOR
999
REFLECTOR HEADLAMP
999
LAMP SOCKET , Replaced By: A0008262582
999
LENS
999
LENS
999
PLATE FOGLAMP, FROM CHASSIS: 005415, ALSO INSTALLED ON: 005408,005410,005412,005413.
999
LENS BLINKER LIGHT
999
BUSHING , Replaced By: A0008260094
999
SHACKLE
999
PLATE FOGLAMP
999
SHACKLE
999
BUSHING
999
DOME LAMP
999
DOME LAMP , Replaced By: A0008252301
999
DOME LAMP , Replaced By: A0008252401
999
DOME LAMP , Replaced By: A0008252301
999
ELEMENT , Replaced By: A0008250751
999
ELEMENT , Replaced By: A0008250751
999
CRANK , Replaced By: A1088240010
999
CARBON BRUSH SET , Replaced By: A0008242275
999
CARBON BRUSH SET , Replaced By: A0008243075
999
ROD , Replaced By: A0008240906
999
CONTACTOR , Replaced By: A0008213152
999
CONTACTOR , Replaced By: A0008211552
999
COVER TO PLUG THE DOOR CONTACT HOLES
999
SWITCH MAKE S.W.F.
999
SWITCH , Replaced By: A0008201510
