Поз.
Артикул
Описание
1
FOLDING SEAT LEFT, STATE COLOR NUMBER WHEN ORDERING
3
FOLDING SEAT RIGHT, STATE COLOR NUMBER WHEN ORDERING
6
SEAT CUSHION LEFT, STATE COLOR NUMBER WHEN ORDERING
10
BACKREST LEFT, STATE COLOR NUMBER WHEN ORDERING
15
BRACKET BACKREST TO SEAT FRAME
18
REINFORCEMENT LEFT
20
REINFORCEMENT RIGHT
22
SPRING BACKREST TO SEAT FRAME
30
BUSHING BACKREST TO SEAT FRAME
32
KNOB
999
CLIP CABLE TO BRACKET,5 318121
999
CLIP LEVER
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
WASHER HEAT SHIELD TO BRACKET
999
WASHER BACKREST TO SEAT FRAME
999
SEAT CUSHION RIGHT, STATE COLOR NUMBER WHEN ORDERING
999
FOLDING SEAT RIGHT, STATE COLOR NUMBER WHEN ORDERING
999
SEAT CUSHION LEFT, STATE COLOR NUMBER WHEN ORDERING
999
FOLDING SEAT LEFT, STATE COLOR NUMBER WHEN ORDERING
999
SEAT CUSHION RIGHT, STATE COLOR NUMBER WHEN ORDERING
999
BACKREST RIGHT, STATE COLOR NUMBER WHEN ORDERING
999
BACKREST LEFT, STATE COLOR NUMBER WHEN ORDERING
999
BACKREST RIGHT, STATE COLOR NUMBER WHEN ORDERING
