Поз.
Артикул
Описание
5
SEAT ADJUSTER
5
SEAT ADJUSTER LEFT, WITH HEIGHT ADJUSTMENT
5
SEAT ADJUSTER , Replaced By: A1249402764, +001A2019192720
5
SEAT ADJUSTER , Replaced By: A1249402864, +001A2019192820
5
SEAT ADJUSTER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.F 010519, Replaced By: A1249104777
5
SEAT ADJUSTER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.F 010519, Replaced By: A1249104877
8
HANDLE RIGHT SEAT HEIGHT ADJUSTMENT
8
HANDLE LEFT SEAT HEIGHT ADJUSTMENT
11
RIVET
14
BRACKET
17
BUSHING
20
SHAFT RAKE ADJUSTMENT
23
HANDWHEEL RAKE ADJUSTMENT
23
HANDWHEEL , Replaced By: A2029190088
26
SPRING RAKE ADJUSTMENT
29
SPRING RIGHT
29
SPRING LEFT
32
RIVET
35
GUIDE RAIL LESS HEIGHT ADJUSTMENT,LEFT
35
GUIDE RAIL , Replaced By: A1249102589
35
GUIDE RAIL LESS HEIGHT ADJUSTMENT,LEFT,F 047279
38
GUIDE RAIL LESS HEIGHT ADJUSTMENT,RIGHT,F 047279
38
GUIDE RAIL , Replaced By: A1249102689
38
GUIDE RAIL LESS HEIGHT ADJUSTMENT,RIGHT
41
BUSHING ,F 047279
44
ADJUSTER RIGHT FRONT SEAT
47
BRACKET
50
BUSHING
53
SCREW
56
SCREW HORN TO BRACKET
59
SCREW
65
SCREW
65
SCREW , Replaced By: A1249900222
65
SCREW , Replaced By: A1409901122
68
SOCKET NUT. NUT RETAINER EXHAUST MUFFLER TO SUPPORT
71
SCREW COVER PLATE TO BRACKET
74
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
77
WASHER COMPRESSED AIR LINE TO BRACKET
77
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
80
NUT RETAINER USED WITH IMITATION LEATHER TRIM, 123 297291 ALSO INSTALLED ON 306113-347407 133 002318 ALSO INSTALLED ON 004116-012658
83
SPRING , Replaced By: A2019100128
83
SPRING HEIGHT ADJUSTMENT
