Поз.
Артикул
Описание
810
BEARING BRACKET REAR, 016 FROM CHASSIS 027622 ALSO INSTALLED ON, SEE FOOTN.11,018 FROM CHASSIS 028985 ALSO INSTALLED ON,SEE FOOTN.56,019 FROM CHASSIS 029326
811
NEEDLE BEARING
815
BEARING BRACKET , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
817
LEVER , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
818
NEEDLE BEARING
819
WASHER
820
LOCK PLATE INTERMEDIATE BEARING
821
SPRING WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
822
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
822
SPRING WASHER , Replaced By: N000137008212
823
NUT , Replaced By: N304032008006
823
NUT
824
SHIFTING TUBE , 016 FROM CHASSIS 054181, 018, 019 FROM CHASSIS 059142
826
PIN
827
SPRING
828
GUIDE PIVOT
829
SEAL RING
830
WASHER
831
LOCK
833
SHIFT LEVER , 019136
833
SHIFT LEVER , FROM CHASSIS: 000,002,010 056142 015 060262 100,102,103,110,112 139361 115 065086 UP TO CHASSIS: LESS POWER STEERING 000,002,010 12/52 086674 015 12/52 101861 100,102,103,110,112 12/52 220489 115 12/52 109121 UP TO CHASSIS: WITH POWER STEERING 000,002,010 12/52 083150 015 12/52 097114 100,102,103,110,112 12/52 211905 115 12/52 104333, Replaced By: A1152604439, +001A1152681442, +001A1152680172
833
SHIFT LEVER , FROM CHASSIS: 000,002,010 111660 015 143500 100,102,103,110,112 295223 115 150670 005,017,105,107,108,117,119 000001
836
KNOB , FROM CHASSIS: 000,002,010 007281 015 004404 100,102,103,110,112 017471 115 007979 UP TO CHASSIS: LESS POWER STEERING 000,002,010 12/52 086674 015 12/52 101861 100,102,103,110,112 12/52 220489 115 12/52 109121 UP TO CHASSIS: WITH POWER STEERING 000,002,010 12/52 083150 015 12/52 097114 100,102,103,110,112 12/52 211905 115 12/52 104333 UP TO CHASSIS: LESS POWER STEERING 000,002,010 22/62 087646 015 22/62 103161 100,102,103,110,112 22/62 222275 115 22/62 110304 UP TO CHASSIS: WITH POWER STEERING 000,002,010 22/62 086763 015 22/62 101811 100,102,103,110,112 22/62 220494 115 22/62 109109
840
SPRING SHIFTING TUBE
842
BUSHING , FROM CHASSIS: 000,002,010 056142 015 060262 100,102,103,110,112 139361 115 065086 UP TO CHASSIS: 000,002,010 095001 015 115530 100,102,103,110,112 244262 115 122227
844
SLEEVE BRACKET TO PEDAL BEARING BRACKET
846
CAP
847
BOOT
852
SCREW
854
NUT TACHOGRAPH TO BRACKET
855
GUIDE PIVOT
856
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
857
SCREW COVER PLATE TO BRACKET
858
SLOTTED GATE , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
860
WASHER COMPRESSED AIR LINE TO BRACKET
860
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
861
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
862
SCREW COVER PLATE TO BRACKET
863
LEVER , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
865
WASHER
867
BALL SOCKET
869
SECURING CLIP. CIRCLIP
870
FITTED WASHER
871
LOCK RING
872
NEEDLE BEARING
873
SPACER TUBE
874
LEVER , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
876
LEVER
877
SHAFT
878
BEARING
879
HOUSING
880
RUBBER RING
881
BALL
882
WASHER
883
SEAL RING
884
LOCK WASHER
885
NUT
887
SHIFTING ROD , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
890
BALL SOCKET
891
NUT
893
BUSHING GEAR SELECTOR LEVER
895
LOCK
896
BRACKET , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON , NO LONGER AVAILABLE
999
BUSHING , 114.005,007,015 037181 114.010 033492 114.021 001931 114.022 002382 115.000,002,010 037475 115.015 035971 115.100,102,110 085311 115.115 039087
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING LOCK-UP COUPLING 0.32X6.64X27 MM
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING , 053009
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING
999
SPRING ,024694
999
BOOT
999
WASHER
999
CLAMP OIL LINE TO CONVERTER HOUSING
999
LINE
999
PIN39,15
999
SPACER RING SUPPORT TO OIL PAN
999
SEAL RING OUTPUT SHAFT,FRONT 26 MM
999
SEAL RING
999
BOOT
999
SCREW CLAMP MOUNTING
999
SCREW STEERING COLUMN PANELLING M 5X12
999
SCREW
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
WASHER
999
LOCK WASHER
999
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
999
LOCK WASHER 3/2-WAY SOLENOID VALVE TO BRACKET
999
LOCK WASHER
999
LOCK WASHER TAIL LAMP TO BRACKET
999
SPRING WASHER , Replaced By: N000137004202
999
SPRING WASHER AT GENERATOR TERMINAL D+, 010,10/50 UP TO CHASSIS 066175,010,12/52 UP TO CHASSIS 067208 EXCEPT FOR 067205,010,20/60 UP TO CHASSIS 065672,010,22/62 UP TOCHASSIS 068683 012,10/50 UP TO CHASSIS 151591 EXCEPT FOR,SEE FOOTNOTE 074,012,12/52 UP TO CHASSIS 153776 EXCEPT FOR 153758,153760,153771 012,20/60 UP TO CHASSIS 148879 EXCEPT FOR 148827,148837,148844,148850,148852,012,22/62 UP TO CHASSIS 158113
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SPRING WASHER BRACKET TO PEDAL ASSEMBLY BEARING BRACKET, 000,001,004,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 2, 10/50, 20/60, 100,101,104,110 UP TO CHASSIS 099641 EXCEPT FOR , SEE FOOTNOTE 3, ALSO INSTALLED ON 099892
999
SPRING WASHER GROUND CABLE TO TRANSMISSION
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
SCREW
999
SCREW OIL LINES TO ENGINE,001498
999
SCREW
999
SCREW , Replaced By: N304017006012
999
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
999
SCREW , Replaced By: N304017010050
999
SCREW FLOOR TO FRAME M 6X16
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006018
999
SCREW , Replaced By: N304017006034
999
SCREW OIL LINE TO CRANKCASE
999
SCREW
999
SCREW
999
SCREW , Replaced By: N304017008016
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: A0089907401
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
NUT BALL PIVOT TO LEVER
999
NUT CYLINDER TO BRACKET TO0002902112
999
NUT , Replaced By: N304032008006
999
NUT
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
CLAMPING SLEEVE
999
BALL10 MM
999
TOOTHED WASHER ,026784
999
CLAMPING SLEEVE , Replaced By: N001481005017
999
SEAL RINGTO 001 431 72 14
999
LOCK WASHER FLEXIBLE SHAFT TO ANGLE DRIVE
999
BALL SOCKET
999
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
999
SCREW PUMP TO BRACKET
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW PIPE CLAMP
999
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW , Replaced By: N304017010055
999
NUT BATTERY MOUNTING
999
NUT BATTERY CABLE
999
THREADED INSERT
999
THREADED INSERT REPAIR SIZE
999
THREADED INSERT REPAIR SIZE
999
THREADED INSERT REPAIR SIZE
999
LOCK WASHER T-FITTING TO BRACKET
999
HOLLOW SCREW COMPRESSED AIR LINE TO OPERATING CYLINDER
999
VALVE PART
999
SCREW , TO 115 270 27 11, 115 270 30 11, 115 270 39 11
999
SHIFT VALVE
999
SHIFT VALVE , NO LONGER AVAILABLE
999
BRACKET , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
GASKET , Replaced By: A1152773280
999
SHIFT VALVE
999
VALVE PART
999
GASKET , Replaced By: A1152772980
999
INTERMEDIATE PLATE , TO 115 270 33 07
999
SHIFT VALVE
999
SHIFT VALVE
999
VALVE BODY ASSEMBLY
999
GASKET , Replaced By: A1152772880
999
COVER
999
HOUSING
999
SHIFT VALVE
999
SHIFT VALVE
999
PISTON
999
VALVE PART
999
PISTON
999
GASKET , 016, 018, 019 FROM TRANSMISSION 052411, 057, 058 FROM TRANSMISSION 025503
999
PISTON
999
GASKET
999
SHIFT VALVE
999
PIN40,15
999
SHIFT VALVE
999
GASKET
999
BUSHING
999
PISTON
