Поз.
Артикул
Описание
2
STEERING BOX
3
SEAL RING
3
SEAL RING , Replaced By: A0139973648
4
NEEDLE BEARING , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
5
SEAL RING
6
SCREW PLUG MEASURING CONNECTION
7
SEAL RING SCREW PLUG
10
PISTON WITH WORM AND SLEEVE VALVE
11
STEERING BOX COVER
12
SEAL RINGTO 388 476 71 69
12
SEAL RING , Replaced By: A0149976148
13
GASKET
14
THRUST WASHER
15
LOCK
16
THRUST WASHER
17
ROLLER BEARING
18
NEEDLE BEARING
19
THREADED INSERT
20
SEAL RING STEERING NUT BEARING 12.4X1.78 MM
21
SEAL RING
22
SEAL RING
23
LOCK
24
NUT
25
CLAMP
26
SCREW BALL GUIDE TO PISTON
27
LOCK BALL GUIDE TO PISTON
28
PISTON , WITH L.H.D.,FROM STEERING 003126
29
LOCK
30
ANGULAR CONTACT BEARING
31
COVER
32
SCREW COLLAR
33
SEAL RING
34
SEAL RING
35
SPRING
36
THRUST WASHER 2,0 MM, TO BE ADAPTED DURING ASSEMBLY
38
LOCK
39
CLAMPING PIN
40
WASHER
41
SPRING
42
LOCK
43
SCREW END PIECE TO EXHAUST PIPE M 10X25
44
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
45
BLEEDER VALVE OIL DRAIN
46
PROTECTIVE CAP ,5 962906
46
PROTECTIVE CAP , Replaced By: A0004217187
48
COVER
49
COVER
51
FITTING , UP TO CHASSIS: 023 009058
52
SEAL RING
53
GASKET
54
FITTING
56
SEAL RING
57
STEERG. WORM SECTOR SHAFT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
58
STEERING BOX COVER
58
STEERING BOX COVER , Replaced By: A1094600215
59
SEAL RING , Replaced By: A0139973648
59
SEAL RING
60
NEEDLE BEARING
61
SEAL RING
62
SEAL RING
63
LOCK BELL HOUSING
64
SEAL RING STEERING NUT BEARING 75X3 MM
65
SEAL RING
66
SPRING
67
SCREW. CAP BOLT COVER TO CASE M8X25
67
SCREW , Replaced By: N000912008202
68
SPRING WASHER , Replaced By: N000137008212
69
NUT
70
SEAL RING
71
SEAL RING LINE CONNECTION
72
SEAL RING SCREW PLUG
73
NUT
74
CAP NUT
75
GASKET KIT
75
REPAIR KIT , Replaced By: A1094600261
999
PISTON , WITH R.H.D.,FROM STEERING 004251
999
PITMAN ARM
999
LOCK STEERING SHAFT BEARING
999
THRUST WASHER *** 1.0MM
999
THRUST WASHER 1,1 MM, AS REQUIRED
999
THRUST WASHER 1,2 MM, AS REQUIRED
999
THRUST WASHER 1,3 MM, AS REQUIRED
999
THRUST WASHER , Replaced By: A1124660962
999
THRUST WASHER 1,4 MM, AS REQUIRED
999
THRUST WASHER 1,6 MM, AS REQUIRED
999
THRUST WASHER 1,7 MM, AS REQUIRED
999
THRUST WASHER 1,8 MM, AS REQUIRED
999
THRUST WASHER 1,9 MM, AS REQUIRED
999
COVER
999
COVER , Replaced By: A1124661905
999
COVER , Replaced By: A1124661905
999
HOSE
999
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
LOCK WASHER 3/2-WAY SOLENOID VALVE TO BRACKET
999
NUT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
999
SCREW FROM BACK-UP LAMP TO REAR CROSS MEMBER
999
NUT TACHOGRAPH TO BRACKET
999
SCREW PLUG 4/2-WAY VALVE
999
CLAMP , Replaced By: N000000000667
999
ROLLER BEARING
999
ANGULAR CONTACT BEARING , Replaced By: A0009813927
999
ANGULAR CONTACT BEARING
999
ANGULAR CONTACT BEARING
999
NEEDLE BEARING
999
LOOM TIE , Replaced By: N916026020001
999
SEAL RING , Replaced By: A0059975846
999
HOSE
999
STEERING BOX COVER
999
STEERING BOX , Replaced By: A1094601101
999
STEERING BOX ASSEMBLY
999
SCREW , WITH L.H.D.,ON MODEL 113.044 FROM STEERING014191 WITH R.H.D.,ON MODEL 113.044 FROM STEERING014401
999
PITMAN ARM , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1124631501
999
NUT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
999
NUT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
999
LINE , Replaced By: A1144600324
999
LINE
999
STEERING BOX ASSEMBLY , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
STEERING BOX ASSEMBLY
999
STEERING BOX ASSEMBLY , Replaced By: A1094601001
999
STEERING BOX ASSEMBLY , Replaced By: A1094601101
999
BRACKET
999
STEERG. WORM SECTOR SHAFT
999
STEERING BOX COVER , Replaced By: A1094600315
999
STEERING BOX COVER , Replaced By: A1124602014
999
STEERING BOX , Replaced By: A1094600402, +001A1094600211, +001A1094620171, +001A1094660072, +001A0039811810
999
STEERING BOX , Replaced By: A1094600802, +001A1094600211, +001A1094620171, +001A1094660072, +001A0039811810
999
PISTON
999
STEERING BOX COVER
999
STEERING BOX ASSEMBLY , Replaced By: A1094601001
999
STEERING BOX ASSEMBLY
999
PISTON WITH STEERING WORM AND STEEVE VALVE
