Поз.
Артикул
Описание
10
STAY ON MAIN FLOOR,UNDER FRONT FLOOR MAT, LEFT
10
STAY ON MAIN FLOOR,UNDER FRONT FLOOR MAT, RIGHT, TO BE ADAPTED DURING ASSEMBLY
20
NUT COVERING TO CAB FIRE WALL
30
BRACKET
40
PAD
50
PANELLING. PANELING FRONT PANEL, LATERAL LEFT
50
PANELLING FRONT PANEL, LATERAL LEFT,NO.9B51I NO.5076I NO.8F20I NO.8F30I .......I NO.7101I NO.9B51I NO.9B51I NO.9B51I IIIIIIIII
60
PANELLING FRONT PANEL,LATERAL RIGHT,NO.9B51I NO.5076I NO.8F20I NO.8F30I .......I NO.7101I NO.9B51I NO.9B51I NO.9B51I IIIIIIIII
60
PANELLING FRONT PANEL,LATERAL RIGHT,NO.9B51I NO.5076I NO.8F20I NO.8F30I .......I NO.7101I NO.9B51I NO.9B51I NO.9B51I IIIIIIIII
70
SPRING PANELLING TO FRONT PANEL
80
TAPPING SCREW. SHEET METAL SCREW BRACKET TO CAB
90
COVER CAP LEFT AND RIGHT
100
FOOTREST FRONT FLOOR,LEFT,A 767433, X 15492
110
FASTENER BUTTON COVERING TO PARTITION PANEL,LEFT AND RIGHT
120
LINING FRONT FLOOR,LEFT VELOURS
120
LINING FRONT FLOOR,LEFT VELOURS
120
LINING FRONT FLOOR,LEFT
120
LINING FRONT FLOOR,LEFT
130
LINING DRIVER FLOOR, RIGHT
130
LINING DRIVER FLOOR, RIGHT
130
LINING DRIVER FLOOR, RIGHT VELOURS
130
LINING DRIVER FLOOR, RIGHT VELOURS
133
LUGGAGE NET , F 758208 EXCEPT CODE 808 ALSO INSTALLED IN VEHICLE TO F 758207 WITH CODE 809 NO.9B00 INO.5B12 INO.8F17 INO.8F31 I....... INO.7C47 INO.9B00 INO.9B00 INO.9B00 I
136
BRACKET FOR LUGGAGE NET, 9051QFT246A0370 BLACK
140
LINING REAR FLOOR, REAR VELOURS
140
LINING REAR FLOOR, REAR VELOURS, Replaced By: A2106800541
250
FRAME CROSS MEMBER BELOW REAR SEAT,RIGHT
260
COVERING ON CROSS MEMBER COVERING,NO.9B51I NO.5076I NO.8F20I NO.8F30I .......I NO.7101I NO.9B51I NO.9B51I NO.9B51I IIIIIIIII
280
RAIL FRONT ENTRANCE,INSIDE RIGHT
280
RAIL FRONT ENTRANCE,INSIDE LEFT
290
CLIP ENTRANCE
300
RAIL FRONT ENTRANCE, OUTSIDE RIGHT
300
RAIL FRONT ENTRANCE, OUTSIDE RIGHT
300
RAIL FRONT ENTRANCE, OUTSIDE LEFT
300
RAIL FRONT ENTRANCE, OUTSIDE
310
RAIL REAR DOOR ENTRANCE
310
RAIL REAR DOOR ENTRANCE
310
RAIL REAR DOOR ENTRANCE,LEFT
310
RAIL REAR DOOR ENTRANCE,RIGHT
315
FASTENER BUTTON
320
PUSH BUTTON RIGHT FRONT UPPER PART
330
RAIL REAR ENTRANCE,INSIDE RIGHT
330
RAIL REAR ENTRANCE,INSIDE LEFT
340
CLIP ENTRANCE
400
LININGDESIGNO
400
LININGDESIGNO
450
PLATE DOOR
470
SHEET METAL SCREW CONSOLE TO TUNNEL PANELLING,FRONT
480
PLATE DOOR
490
SCREW SWITCH TO INSTRUMENT PANEL
