Mercedes A2203200314 - БАЧОК

S 55 AMG KOMPRESSOR 220.174

32 SPRINGS, SUSPENSION AND HYDRAULIC SYSTEM - 235 OIL TANK & VALVES USED FOR "ABC" HYDRAULIC SYSTEM IL. 1

Поз.
Артикул
Описание
5
A2203200314
DASHPOT (OIL RESERVOIR)
10
A2103270021
COVER SUPPLY TANK
15
A0021845501
OIL FILTER
17
A2109973581
GROMMET ABC RESERVOIR
20
A0031846101
OIL FILTER ABC RESERVOIR
20
A0031845101
LONGLIFE OIL FILTER
30
A2103270060
SEAL RING
35
A1233270160
SEAL RING , 116.020 092526 024,025 099723 028,029 043105 032,033 072837
40
A2103270072
NUT
45
A2203200259
OIL DIPSTICK ABC RESERVOIR
50
A1233270059
PROTECTIVE CAP
55
A2203200159
OIL DIPSTICK POWER STEERING RESERVOIR
57
A1233270059
PROTECTIVE CAP
60
A1239931101
SPRING , 116.020 092526 024,025 099723 028,029 043105 032,033 072837
65
A2209930401
SPRING ABC RESERVOIR
67
A2015040112
RUBBER MOUNTING EXPANSION TANK TO WHEELHOUSE
75
N913023006001
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
80
A2203270086
SCREENING OIL RESERVOIR
85
A1299971681
GROMMET UNDER OIL RESERVOIR, TO BE ADAPTED DURING ASSEMBLY
90
N913023006001
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
95
N910105005000
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
100
N910112005000
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
