Поз.
Артикул
Описание
3
LINE EXHAUST BRAKE, LENGTH AVAILABLE: 3000 MM
3
LINE EXHAUST BRAKE, LENGTH AVAILABLE: 3000 MM
6
UNION NUT
9
GLAND , Replaced By: A0019901667
12
TS DOUBLE FITTING SOLENOID VALVE
12
TS DOUBLE FITTING SOLENOID VALVE
12
FITTING , Replaced By: A0029906071
12
FITTING , Replaced By: A0039979072
14
FITTING FROM PUMP TO CYLINDER
14
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
15
BRAKE HOSE AT CYLINDER, TO BE ADAPTED DURING ASSEMBLY
15
HOSE , Replaced By: A3074290035, +001A0019909871, +001A0029906071
18
VALVE (3/2-WAY SOLENOID VALVE)
21
VALVE PARTTO 004 997 00 36,5 757289 AUSSERDEM EINGEBAUT IN 5 759173
24
SEAL RING24X2 MM
24
SEAL RINGWABCO
30
SEAL RING VALVE TO VALVE
33
SEAL RING LINE CONNECTION
34
PROTECTIVE CAPWABCO
36
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
39
TS DOUBLE FITTING SOLENOID VALVE
39
FITTING , Replaced By: A0029906071
39
FITTING , Replaced By: A0039979072
42
SEAL RING LINE CONNECTION
45
CLAMP SENSOR CABLE TO BRACKET
45
CLAMP SENSOR CABLE TO BRACKET
48
SCREW CAB FLOOR COVERING M 6X25
48
SCREW CAB FLOOR COVERING M 6X25
51
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
51
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
51
NUT , Replaced By: N910113006001
54
WASHER COMPRESSED AIR LINE TO BRACKET
54
WASHER , Replaced By: N009021006208
57
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
63
VALVE BODYTO 002 429 95 44
63
VALVE , Replaced By: A0004291182
63
VALVE , Replaced By: A0004290782
70
FITTING SHUTTLE VALVE
75
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236
75
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
78
SEAL RING LINE CONNECTION
81
BRACKET TWO-WAY VALVE
84
SCREW BRACKET TO EXHAUST MUFFLER BRACKET
87
LOCK WASHER FITTING TO BRACKET
90
NUT BRACKET TO SIDE MEMBER
93
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "2"
96
UNION NUT LINE CONNECTION
96
UNION NUT LINE CONNECTION, Replaced By: N000000006239
99
SEAL CONE LINE CONNECTION
99
GLAND , Replaced By: A0019901967
999
GASKETTO 003 429 22 44
999
VALVE PART , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004311668
999
VALVE PART
999
VALVETO 003 997 11 36/12 36
999
BALLTO 003 429 22 44
999
