Поз.
Артикул
Описание
71
BEARING BODY FAN DRIVE
71
BEARING BODY , Replaced By: A3732057205
80
FAN SHAFT
80
FAN SHAFT , Replaced By: A3732057202, +002N913004016005
84
CYLINDR. ROLLER BEARING ON RADIATOR SIDE
84
CYLINDR. ROLLER BEARING FAN DRIVE
84
ANG. CONTACT BALL BEARING
86
LOCK RING52X2 MM
88
GROOVED BALL BEARING BELT TIGHTENER PULLEY TO BELT TIGHTENER SPINDLE
91
SEAL RING CASE COVER
94
PULLEY FAN DRIVE, FROM IDENT NO. 004703 ALSO INSTALLED ON 004316,004586,004634,004640,004650,004662,004673
94
PULLEY FAN DRIVE, UP TO IDENT NO. 004702 EXCEPT FOR 004316,004586,004634,004640,004650,004662,004673
97
LOCK WASHERROCKINGER TYP 59 G140,59 G150
99
NUT WEAR INDICATOR
100
SCREW PLUG 4/2-WAY VALVE
102
SEAL RING , Replaced By: N007603010110
102
SEAL RING PNEUMATIC VALVE
104
SCREW , Replaced By: N304017008053
104
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
106
WASHER EXHAUST MUFFLER TO STRAP
106
WASHER , Replaced By: N000125008443
108
NUT , Replaced By: N913004008001
144
LEVER BELT TIGHTENER,042507
144
LEVER ,042506, Replaced By: A3072000573, +001A0119975447
144
LEVER TIGHTENER PULLEY
146
PULLEY 204 MM, FROM IDENT NO. 004703 ALSO INSTALLED ON 004316,004586,004634,004640,004650,004662,004673
146
PULLEY180 MM,000475
148
HUB
150
SPACER RING DELIVERY AND SUCTION LINES TO BRACKET
152
SCREWM 8X40
154
NUT , Replaced By: N913004008001
156
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
156
SCREW , Replaced By: N308676012011
156
SCREW , Replaced By: N308676012031
158
TIGHTENER PULLEY , UP TO IDENT NO. 004702 EXCEPT FOR 004316,004586,004634,004640,004650,004662,004673
160
SPACER WASHER BELT TIGHTENER 1.00 MM
160
SPACER WASHER BELT TIGHTENER 0.50 MM
160
SPACER WASHER BELT TIGHTENER 0.20 MM
162
GROOVED BALL BEARING BELT TIGHTENER PULLEY TO BELT TIGHTENER SPINDLE
164
SPACER TUBE
164
SPACER TUBE
166
EXPANSION PLUG
168
NUT TIGHTENER PULLEY
170
LOCK RING52X2 MM
172
RADIAL SEAL RING
174
SEAL RING BATTERY MASTER SWITCH
174
SEAL RING
174
SEAL RING TIGHTENER PULLEY, UP TO IDENT NO.035608 ALSO INSTALLED ON 035610,035643,035659,035698,035709,035728,036213
176
LOCK RING
178
EXPANSION PLUG
180
GASKET COVER TO TIGHTENER PULLEY
184
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
186
SCREW COVER PLATE TO COVER PLATE M 6 X 10
186
SCREW , Replaced By: N304017006034
188
SEAL RING PNEUMATIC VALVE
188
SEAL RING , Replaced By: N007603010110
190
SCREW PLUG 4/2-WAY VALVE
192
SUPPORT CLAMPING LEVER
192
SUPPORT CLAMPING LEVER
194
STUD SUPPORT TO FAN SUPPORT
194
STUD
196
SCREW RADIATOR M 10X45
198
WASHER RADIATOR TO RUBBER MOUNTING
198
WASHER , Replaced By: N000125010532
200
WASHER BRACKET TO COVERING
200
WASHER , Replaced By: N009021010209
202
NUT AIR CLEANER ELEMENT
204
NUT STRAP TO SUPPORT
206
V-BELT , Replaced By: A0069972092
206
V-BELT TOOTHED,SET2 PIECES
206
V-BELT12.5X1110
206
V-BELT TOOTHED,SET2 PIECES 12.5X1693 MM
206
V-BELT TOOTHED,LOW TENSIBILITY 12.5X1718 MM
206
V-BELT , Replaced By: A0099976892
206
V-BELT FROM VIBRATION DAMPER TO TIGHTENER PULLEY 12.5X1700 MM, UP TO IDENT NO. 004702 EXCEPT FOR 004316,004586,004634,004640,004650,004662,004673
206
V-BELT12.5X1100 MM
206
V-BELT12.5X1100 MM
206
V-BELT , Replaced By: A0059971392
206
V-BELT , Replaced By: A0079974992
206
V-BELT ALTERNATOR 12.5X1000 MM
206
V-BELT ALTERNATOR 12.5X1000 MM
206
V-BELT , Replaced By: A0039975092
206
V-BELT , Replaced By: A0059972992
206
V-BELT , Replaced By: A0059973192
206
V-BELT , Replaced By: A0079975792
206
V-BELT LOW TENSIBILITY 12.5X1800 MM
206
V-BELT LOW TENSIBILITY 12.5X1800 MM
206
V-BELT , Replaced By: A0059973692
206
V-BELT , Replaced By: A0079976192
206
NARROW V-BELT FROM VIBRATION DAMPER TO TIGHTENER PULLEY 12.5X1725 MM, UP TO IDENT NO. 004702 EXCEPT FOR 004316,004586,004634,004640,004650,004662,004673
206
V-BELT FROM VIBRATION DAMPER TO TIGHTENER PULLEY 12.5X1700 MM, UP TO IDENT NO. 004702 EXCEPT FOR 004316,004586,004634,004640,004650,004662,004673
206
NARROW V-BELT , Replaced By: A0039970492
999
RECEPTACLE , Replaced By: A0005831835
999
RECEPTACLE SILICONE GREASE, FILLING QUANTITY: 70 CCM,TO 002 205 65 06
999
SLEEVE
999
MOUNTING
999
