Поз.
Артикул
Описание
3
BATTERY , Replaced By: A0035411801
3
BATTERY , Replaced By: A0025412301
3
BATTERY12 V/135 AH
3
BATTERY , Replaced By: A0045415101
3
BATTERY12 V/165 AH
4
BOOT , Replaced By: A0005464335
4
BOOT , Replaced By: A0005464635
4
BOOT POS. POLE
5
VENT BATTERY, UP TO CHASSIS 022725 EXCEPT FOR SEE FOOTN.67,ALSO INSTALLED ON 022728,022734,022744,022746,022749,022752
14
POSITIVE CABLE. POS.CABLE , Replaced By: N072551095880, +001N046234010006, +001N072332015100
16
ELECTRIC CABLE , Replaced By: N922002095000
16
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO CABLE CONNECTOR
16
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO CABLE CONNECTOR
16
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO CABLE CONNECTOR
16
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO CABLE CONNECTOR
16
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO CABLE CONNECTOR
17
SOLDERING TERMINAL POS. POLE
17
SOLDERING TERMINAL NEG.POLE
18
CABLE SHOE FROM BATTERY MASTER SWITCH TO FRAME
19
NEG. CABLE , Replaced By: N922002095000, +001N046234010006, +001N072332015200
19
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO CABLE CONNECTOR
22
NEG. CABLE ,023588, Replaced By: N072551095880, +002N046234010006
24
CABLE SHOE FROM BATTERY MASTER SWITCH TO FRAME
25
POSITIVE CABLE , FOR THE NEW PART NO.,SEE STANDARD VERSION, Replaced By: N072551095880, +001N046234010006, +001N072332015100
25
POSITIVE CABLE , FOR THE NEW PART NO.,SEE STANDARD VERSION, Replaced By: N072551095880, +001N046234010006, +001N072332015100
26
SOLDERING TERMINAL POS. POLE
30
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
30
LOCK WASHER FITTING TO BRACKET
30
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
31
NUT BALL PIVOT TO LEVER
31
NUT STRAP TO SUPPORT,5 149419
31
NUT BRACKET TO SUPPORT AND TO END PIECE
37
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
38
SCREW BRACKET MOUNTING
40
CLAMPING PIECE CABLE CONNECTOR
40
CLAMPING PIECE FROM THERMOSTAT OIL LINE TO TRANSMISSION OUTLET OIL LINE 900 MM
40
CLAMPING PIECE BATTERY CABLE
41
SCREW , Replaced By: N304014006004
41
SCREW BRACKET TO CROSS MEMBER
43
NUT BALL PIVOT TO LEVER
44
CLAMP BRAKE HOSE BRACKET
44
CLAMP PIPE ON FAN SHROUD
44
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
49
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
50
NUT BALL PIVOT TO LEVER
51
LOOM TIE LINE MOUNTING 150 X 3,6 MM
51
LOOM TIE LINE MOUNTING 280 MM
55
GROUND CABLE , FROM IDENT NO. 018695 ALSO INSTALLED ON 018411,018469,018489,018529,018549,018589,018610. EXCEOT FOR 018709,018713,018731,018735,018752,018756,018777,018784,018805,018817,018839,018843,018859,018871, 018874,018883,018892,018901,018907,018911,018917,019001,019023,019044,019064,019085,019135,019157, 019180,019221,019243,019276,019319,019361,019403,019424,019488,019530.
305
SWITCH ELECTRO-MAGNETIC
305
RELAY (BATTERY MASTER SWITCH)
306
SCREW CLAMP TO BRACKET AND TO PIPE
306
SCREW , Replaced By: N304017008034
306
SCREW BRACKET TO CROSS CONNECTION STRUT
307
SPRING WASHER , Replaced By: N000137008212
999
FUSEA8
999
FUSE , Replaced By: A0015457534
999
BULB TELL-TALE LAMP
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
SCREW BRACKET TO SIDE MEMBER
999
CABLE SHOE
999
LOCK WASHER T-FITTING TO BRACKET
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
999
LOCK WASHER CAB TO FRONT CONSOLE,4 444945
999
SCREW-AND-WASHER ASSEMBLY. COMBINATION BOLT BATTERY CABLE THRU PARTITION PANEL
999
COMBINATION BOLT CABLE CONNECTOR
999
COMBINATION BOLT STEERING COLUMN MOUNTED SWITCH
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
CLAMP FRAME MOUNTED CABLE HARNESS AND BATTERY CABLE TO BRACKET
999
CLAMP LINE MOUNTING
999
CLAMP , Replaced By: N000000000673
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
NUT TACHOGRAPH TO BRACKET
999
NUT , Replaced By: N304032008006
999
SCREW FUSE BOX TO BRACKET
999
DISC SPRING
999
TOOTHED WASHER COVER TO COVERING,K 093739
999
WASHER FUSE
999
RIVET MAIN CABLE,FRONT END
999
SEAL RING LINE CONNECTION
999
SHEET METAL SCREW SETSCREW LEAD-SEALING IN TACHOGRAPH
999
SHEET METAL SCREW
999
SHEET METAL SCREW , Replaced By: N007981004339
999
SHEET METAL SCREW , Replaced By: N000000000459
999
SHEET METAL SCREW BOOT TO CAB FLOOR
999
SHEET METAL SCREW , UP TO CHASSIS 150881
999
SCREW , Replaced By: N007985004136
999
SCREW ADDITIONAL WORK ON FRAME MOUNTED CABLE HARNESS
999
SCREW ELECTRIC CABLE TO FUSE BOX
999
SCREW , Replaced By: N000000001933
999
SCREW T-FITTING TO BRACKET M4X25
999
SCREW CABLE CONNECTOR, UP TO CHASSIS 818714 EXCEPT FOR:500000-599999
999
SCREW HOOK TO BRACKET
999
SCREW STEP SWITCH AM 5X10
999
SCREW CONTROL UNIT TO CAB
999
SCREW , Replaced By: N000000001145
999
SCREW , Replaced By: N000000001146
999
SCREW COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
INSULATING HOSE (SHRINK HOSE), ORDER BY THE METER
999
CABLE SHOE BATTERY CABLE 12-70 MM
999
MOUNTING CLAMP. CLAMP OIL LINE TO BRACKET, AND BRACKET TO OIL TANK BRACKET, 738939 WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938
999
SCREW , Replaced By: N304017016011
999
SCREW OIL LINE TO CRANKCASE
999
SCREW SOLENOID VALVE TO BRACKET
999
SCREW BRACKET TO EXHAUST MUFFLER BRACKET
999
SCREW , Replaced By: N304017010002
999
SCREW , Replaced By: N304017008027
999
SCREW , Replaced By: N304017006018
999
SCREW COVER PLATE TO BRACKET
999
SCREW RADIATOR M 10X45
999
WASHER BOOT TO CAB FLOOR
999
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
WASHER BRACKET TO FRAME
999
WASHER , Replaced By: N000125017016
999
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
999
WASHER , Replaced By: N000125015019
999
WASHER
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000433005304
999
WASHER REFLECTOR TO BRACKET
999
SCREW PROTECTION PLATE TO BRACKET
999
SCREW
999
SCREW BOOT TO AIR DUCT AND TO AIR CLEANER,5 946572
999
SCREW ,374026
999
SCREW FUSE BOX TO SIDE MEMBER,5 097182
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
SCREW CLAMP MOUNTING M 6X16
999
SCREW BRACKET TO COVERING
999
CLAMP HOSE TO RETARDER 60-80X13 MM
999
SHEET METAL SCREW FUEL STRAINER SCREEN TO FUEL TANK
999
PIN BUSHING HOUSING 8-POLE
999
ADAPTER FRAME
999
GROMMET , Replaced By: A3819970881
999
GROMMET
999
BOOT PRESSURE SWITCH SCREW-CONNECTION TO M 27X1
999
CONTACT RAIL AUTOMATIC CUT-OUT CONNECTION
999
999
LOCK INSULATING HOSE 23 MM
999
LOCK
999
LOCK INSULATING HOSE 12 MM
999
LOCK INSULATING HOSE
999
GROMMET TEMPERATURE GAUGE SENDER UNIT
999
WASHER PRESSURE SWITCH SCREW-CONNECTION TO M 27X1,5 129167
999
GROMMET ,5 180265
999
BOOT CABLE HARNESS EXTENSION
999
BOOT PRESSURE SWITCH SCREW-CONNECTION TO M 27X1, M 24X1
999
GROMMET CABLE CONNECTOR
999
PLUG SOCKET A B S SENSOR CABLE SCREW-CONNECTION
999
PLUG SOCKET PRESSURE SWITCH SCREW-CONNECTION TO M 24X1
999
PLUG SOCKET (PARTS KIT),BIPOLAR SCREW CONNECTION, FOR CORRUGATED TUBE M 27X1
999
PLUG SOCKET (PARTS KIT),BIPOLAR SCREW CONNECTION, FOR CORRUGATED TUBE M 24X1
999
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 27X1
999
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 24X1
999
PLUG SOCKET , Replaced By: A3805402281
999
PLUG SOCKET , Replaced By: A3805402181
999
PLUG HOUSING 8-POLE
999
PROTECTIVE TUBE
999
FUSE BOX QUADRUPLE, UP TO CHASSIS 150881
999
GROMMET
999
GROMMET
999
CABLE HARNESS ENGINE,043105
999
GROMMET HEADLAMP
999
GROMMETD6/32
999
999
GROMMET MAIN CABLE,FRONT END
999
GROMMET
999
APPARATUS PANEL , FROM IDENT NO. 040926 ALSO INSTALLED ON 038379,038620.047168
999
999
LENS BLACK
999
LENS COLORLESS
999
999
BULB TELL-TALE LAMP 24 V/1,2 W
999
999
999
ELECTRIC CABLE ELECTRICAL COMPARTMENT,FRONT/REAR-END CONNECTION,WEBASTO HEATER BRANCH-OFF
999
999
999
999
999
999
999
999
999
PROTECTIVE TUBE , Replaced By: A3575400285
999
999
999
BRACKET CABLE HARNESS MOUNTING
999
BOOT
999
BOOT ADDITIONAL WORK ON REAR END MAIN CABLE HARNESS,033006
999
BRACKET PLUG CONNECTION
999
CONTACT RAIL , Replaced By: A6005450202
999
CONTACT RAIL , Replaced By: A3055450602
