Поз.
Артикул
Описание
923
BRAKE CYLINDER SPRING LOAD ACCUMULATOR CYLINDER, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
924
SEAL RING
925
SEAL RINGTO 001 431 43 05,002 431 05 05
926
CUPTO 001 431 65 14
927
SWITCH LIMITATION OF ENGINE SPEED
927
SWITCH , Replaced By: A0015452809
927
SWITCH , Replaced By: A0015451209
927
SWITCH , Replaced By: A0005459109
927
SWITCH , Replaced By: A0005458009
928
REPAIR KITTO 001 431 65 14,000 431 24 14
929
T-FITTING RIGHT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
929
T-FITTING DIAPHRAGM CYLINDER
929
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
930
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
931
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
932
SEAL RING
932
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
933
T-FITTING. FITTING AT INJECTION PUMP
934
FITTING RELAY VALVE,CONNECTION "20",LEFT
935
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
936
BANJO UNION BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
937
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
938
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
938
TEST CONNECTION
938
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
938
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
939
PLUG
941
SWITCH SUPPLY PRESSURE,5 966147
942
BRACKET AT CROSS MEMBER
943
SCREW BRACKET TO SIDE MEMBER
944
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
945
SCREW BRACKET TO FRAME
946
NUT END PIECE TO EXHAUST PIPE
947
BRAKE INTERMEDIATE SHAFT AT BEARING BRACKET
948
BEARING BRACKET BRAKE INTERMEDIATE SHAFT
949
EXPANSION PLUG
950
BALL CUP BRAKE INTERMEDIATE SHAFT BEARING
951
SEAL RING BEARING BRACKET
951
SEAL RING
952
SEAL HOLDER
953
SCREW BRACKET TO SIDE MEMBER
954
WASHER , Replaced By: N000125010532
954
WASHER RADIATOR TO RUBBER MOUNTING
955
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
956
YOKE INTERMEDIATE SHAFT
957
PULL ROD LEVER TO BRAKE PEDAL
958
YOKE , Replaced By: A0009961501
958
YOKE PULL ROD TO LEVER
959
NUT L.H. THREAD
959
NUT BRACKET TO SUPPORT AND TO END PIECE
960
PIN DOUBLE LEVER TO PUSH ROD
961
WASHER , Replaced By: N000125010532
961
WASHER RADIATOR TO RUBBER MOUNTING
962
COTTER PIN STRAP TO BRACKET
962
COTTER PIN STRAP TO CONSOLE
963
SPRING WASHER , Replaced By: N000137010205
964
PIN , Replaced By: A3529910007
964
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
965
COTTER PIN STRAP TO BRACKET
965
COTTER PIN STRAP TO CONSOLE
966
SPRING (RELEASE SPRING)
999
SCREW COVERING TO RAIL
999
CLAMP , Replaced By: N916016008200
999
BASE STRAP
999
REPAIR KIT , Replaced By: A3534200167
999
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 2200 MM,4 478329
999
LINE FROM BRAKE MASTER CYLINDER TO LEFT FRONT WHEEL 1550 MM
999
HOSE BRAKE CABLE TO FORK 45 MM,556500 ALSO INSTALLED ON 553210,556146 ORDER BY THE METER
999
SPRING ,556500 ALSO INSTALLED ON 553210,556146
999
HOSE BRAKE LINE TO REAR AXLE,4 644238
999
CLAMP BRAKE LINE MOUNTING
999
DAMPING RING
999
CONNECTOR HAND BRAKE LEVER,556500 ALSO INSTALLED ON 553210,556146
999
BEARING BODY ,556500 ALSO INSTALLED ON 553210,556146
999
SPHERICAL PIECE ,556500 ALSO INSTALLED ON 553210,556146
999
NUT , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
ROD ,556500 ALSO INSTALLED ON 553210,556146
999
ROD , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
ROD , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
LEVER INTERMEDIATE LEVER, FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
SUPPORT ,556500 ALSO INSTALLED ON 553210,556146
999
SUPPORT UPPER PART
999
BUSHING , Replaced By: A0009973481
999
LINE WITH BEAD,10 MM
999
GASKET BRACKET TO FIRE WALL,707221
999
GASKET BRACKET TO FIRE WALL,707221
999
BRACKET BRAKE BOOSTER BRACING
999
BRACKET BRAKE BOOSTER ASSEMBLY
999
GROMMET , Replaced By: A0019877625
999
BRACKET RIGHT
999
BRACKET LEFT
999
HANDLETO 341 420 00 88
999
BRAKE LEVER
999
BEARING BRACKET HAND BRAKE LEVER, UP TO CHASSIS 556499 EXCEPT FOR 553795,555902,556120
999
RATCHET ROD
999
PROTECTIVE PLATE
999
PROTECTIVE PLATE ,544549
999
SPHERICAL PIECE , Replaced By: A3025860242
999
PIN BRAKE PEDAL TO BRAKE BOOSTER
999
GASKET
999
CLAMP , Replaced By: A0004760436
999
SEAL RING42.52X2.62 MM,WABCO
999
SEAL RING , Replaced By: A0179979048
999
HOSE FROM RESERVOIR TO MASTER CYLINDER
999
BRAKE MASTER CYLINDER
999
BRAKE MASTER CYLINDER , 10/50 FROM CHAS.145737-162733 ALSO INSTALLED ON 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660, 145697,145701 CONTINUED SEE FOOTNOTE 20
999
THRUST RINGVOSS,707221
999
REPAIR KIT , Replaced By: A0034201724
999
HOSE
999
SEAL RING , Replaced By: A0009971548
999
BRAKE BOOSTER ASSEMBLY , UP TO IDENT NO. 352290 EXCEPT FOR 350368,350793,350843,350954,351074,351169,351284,351434,351903,352001,352271,352272. ALSO INSTALLED ON 352332,352759,353163,353868,354161.
999
BRAKE BOOSTER ASSEMBLY , FROM CHASSIS 018154 ALSO INSTALLED ON 017661,017829 EXCEPT FOR 018155,018156,018159,018308,018310,018315,018317,018318,018327,018350,018355. EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 533350, Replaced By: A0024305630, +001A1262920074, +001N912011008000
999
VALVE PARKING BRAKE KNORR
999
VALVE PARKING BRAKE WITH EMERGENCY RELEASE DEVICE AND TRAILER CONTROL KNORR
999
HOSE FROM PARKING BRAKE VALVE TO ELBOW FITTING
999
SPRING , Replaced By: A0009935205
999
BUSHING , Replaced By: N915062004000
999
ELBOW FITTING , Replaced By: A0019904371
999
BANJO UNION , Replaced By: N915052006005
999
OUTER RACETO 003 429 11 44,VOSS,707221
999
HOSE , Replaced By: A0004358382
999
PISTONVOSS
999
RESERVOIR , 10/50 FROM CHAS.145737-162733 ALSO INSTALLED ON 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660, 145697,145701 CONTINUED SEE FOOTNOTE 20
999
CUP , Replaced By: A0015864342
999
FILLER CAP , Replaced By: A0004317633
999
FILLER CAP , Replaced By: A0004316533
999
VALVE (CHECK VALVE)
999
FILTER BOTTOMTO 000 431 24 14
999
REPAIR KITTO 001 430 18 81/78 81
999
HANDLETO 001 430 17 81,KNORR
999
CONNECTOR OIL DELIVERY LINE
