Поз.
Артикул
Описание
10
EXHAUST PIPE FRONT
20
FLANGE GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, UP TO CHASSIS 4 409726,FROM CHASSIS,NO LONGER REQUIRED
20
FLANGE GASKET , Replaced By: A4424920280
25
SCREW FRONT EXHAUST PIPE TO EXHAUST MANIFOLD M 10X50
28
NUT EXHAUST PIPE TO SIDE MEMBER
35
CLAMP FRONT EXHAUST PIPE TO MUFFLER
38
CLAMP REAR EXHAUST PIPE TO MUFFLER
38
CLAMP REAR EXHAUST PIPE TO MUFFLER
38
CLAMP END PIECE TO EXHAUST PIPE 63.5 MM
40
SCREW SUPPORT TO FENDER
40
SCREW SUPPORT TO FENDER
40
SCREW , Replaced By: N304017008018
44
HEXAGON NUT SCREENING PLATE,5 163561
44
HEXAGON NUT SCREENING PLATE,5 163561
44
NUT , Replaced By: A1201420072
48
CONNECTOR BEHIND EXHAUST MUFFLER
50
EXHAUST MUFFLER
55
SUPPORT RIGHT AIR RESERVOIR
60
SCREW END PIECE TO EXHAUST PIPE M 10X25
64
WASHER RADIATOR TO RUBBER MOUNTING
64
WASHER , Replaced By: N000125010532
68
NUT STRAP TO BRACKET
68
NUT , Replaced By: N910113010000
75
RUBBER DAMPING PLATE. DAMPING PAD , Replaced By: A3095860049
79
CLAMPING PLATE. BASE PLATE FRONT EXHAUST PIPE,B 884219
83
SPACER TUBE FRONT EXHAUST PIPE,B 884219
87
SUSPENSION PROTECTIVE PLATE TO EXHAUST PIPE
87
REPAIR KIT , Replaced By: A3094900037
87
INSULATING WASHER. INSULATION , Replaced By: A3094900037
95
SCREWM 8X40
98
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
98
NUT , Replaced By: N913004008001
105
BRACKET AT MUFFLER,5 194472
110
SCREW VALVE TO BRACKET
114
NUT , Replaced By: A1201420072
114
HEXAGON NUT SCREENING PLATE,5 163561
120
BRACKET EXHAUST MUFFLER SUSPENSION
125
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
129
NUT EXHAUST PIPE TO SIDE MEMBER
140
REAR EXHAUST PIPE
160
SUPPORT RIGHT AIR RESERVOIR
180
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
180
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
195
CLAMP60.5 MM,4 613839
195
CLAMP , Replaced By: N000000001642
200
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
200
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
200
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
204
HEXAGON NUT SCREENING PLATE,5 163561
204
NUT , Replaced By: A1201420072
999
GUIDE BUSHING TWO-WAY VALVE TO FRAME
999
SUPPORT RIGHT AIR RESERVOIR
999
PROTECTIVE PLATE FRONT
999
REAR EXHAUST PIPE , Replaced By: A3184924304
999
SPACER TUBE , Replaced By: A3094310249
