Поз.
Артикул
Описание
35
CRANKCASE
37
CYLINDER SIDE COVER
37
CYLINDER SIDE COVER , Replaced By: A3260100610
42
CRANKSHAFT BEARING CAPNOS. 1,2,3,5,6, NO LONGER AVAILABLE INDIVIDUALLY
50
CRANKSHAFT BEARING CAPNO. 4, NO LONGER AVAILABLE INDIVIDUALLY
58
CRANKSHAFT BEARING CAPNO. 7, NO LONGER AVAILABLE INDIVIDUALLY
70
CYLINDER PIN
70
CYLINDRICAL PIN
76
SCREW
82
CAMSHAFT BEARING NO.1
87
CAMSHAFT BEARING NO.2
92
CAMSHAFT BEARINGNO.3
98
CAMSHAFT BEARINGNO.4
103
CAMSHAFT BEARINGNO.5
108
CAMSHAFT BEARINGNO.6
113
CAMSHAFT BEARINGNO.7
118
CYLINDER LINER125.00 MM
118
CYLINDER LINER133.00 MM
125
PLUG
135
PIPE SOCKET
140
PLUG ,010629
146
EXPANSION PLUG
152
SCREW PLUG
158
DOWEL PIN
163
EXPANSION PLUG
168
SEAL RING TEMPERATURE GAUGE SENDER UNIT
172
SCREW PLUG OIL PASSAGE,REAR
178
SCREW PLUG BELL HOUSING
183
SCREW PLUG STABILIZER
188
SEAL RING BRAKE CYLINDER STROKE INDICATOR
195
SCREW ,044326
201
SEAL RING OIL LINE TO OIL COOLER
207
THREADED CHUCK
212
FITTED SLEEVE
216
CORE BAR
225
SEAL RINGTO 006 997 00 72
235
CORE PLUG , Replaced By: A3269970106
241
EXPANSION PLUG
241
EXPANSION PLUG CORE HOLE 40.30 MM
246
POINTER
252
STUD
258
STUD , UP TO ENGINE 028942 EXCEPT FOR 028931-028939
265
STUD , UP TO ENGINE 028942 EXCEPT FOR 028931-028939
588
COVER
593
GASKET TIMING CASE COVER
603
HEXAGON HEAD BOLT BELLOWS TO BRACKET M8X12
603
SCREW , Replaced By: N304017008057
606
SEAL RING , 057836, Replaced By: A0119976046, +001A3550350051
606
SEAL RING , Replaced By: A0119975647
606
SEAL RING , Replaced By: A0119977046
606
SEAL RING , Replaced By: A0119975747
606
SEAL RING , Replaced By: A0049973947
606
SEAL RING , 057837, Replaced By: A0059978247
606
SEAL RING
606
SEAL RING
606
SEAL RING CRANKSHAFT,FRONT
611
GASKET CYLINDER SIDE COVER
611
GASKET , Replaced By: A3150150221
616
CYLINDER SIDE COVER , Replaced By: A3260100610
616
CYLINDER SIDE COVER
624
SCREW , Replaced By: N304017008021
624
SCREW PIPE CLAMP
634
GASKET CYLINDER SIDE COVER
638
COVER , 910,913,914,916 005183 919,940-945,947 005183 912 004152 915 005033 917 005065
638
COVER
650
SEAL RING CYLINDER SIDE COVER
660
SCREW STRAP TO BRACKET
999
NOZZLE HOLDER , Replaced By: A0000174121
999
SHIM, 1.80 MM THICK. SPACER WASHER1.80 MM, Replaced By: A0040172452
999
GASKET OUTSIDE
999
GASKET INSIDE
999
SEAL , Replaced By: A0002019119
999
SEAL
999
GASKET MOUNTING FOR FILTER BODY
999
GASKET
999
GASKET FUEL FILTER
999
SEAL RING FUEL FILTER COVER
999
SEAL RING
999
SCREW PLUG , ON SPECIAL REQUEST
999
SEAL RING , TO 326 200 12 01
999
SEAL RING BEARING COVER TO HOUSING
999
SEAL RING , TO 326 200 12 01
999
SEAL RING
999
SPACER WASHER1.80 MM
999
GASKET OIL PUMP TO CRANKCASE
999
RUBBER SEALING RING. SEALING RING
999
GASKET GUIDE TUBE TO OIL PAN
999
CAP , Replaced By: A3520100168
999
DICHTRING. GASKET , Replaced By: A3520180180
999
GASKET , Replaced By: A3150150221
999
GASKET , Replaced By: A3460150222
999
SEAL RING PRECHAMBER TO CYLINDER HEAD
999
BRACKET , Replaced By: A3460181540, +001A3461880440, +001A1869901640, +001A3149900040, +002N000127008200, +001N000931010018, +001N000931012005, +001N000933008005, +001N000933008036, +002N000934008000, +001N006319013300
999
SEAL HOLDER
999
SEALING FLANGE , Replaced By: A3551420260
999
GASKET , Replaced By: A3551840580
999
GASKET , Replaced By: N915035000036
999
GASKET WATER PUMP COVER, TO 326 200 12 01
999
PIPE SOCKET , Replaced By: A3262030305
999
SCREW , Replaced By: N000933008048, +001A3469910040
999
SEAL RING
999
EXPANSION PLUG , Replaced By: A3269970720
999
SCREW PLUG , Replaced By: A3269970030
999
GASKET INJECTION PUMP
999
SEAL WASHER NOZZLE HOLDERS
999
COVER , Replaced By: A3460100017
999
OIL DIPSTICK , 000047
999
COVER , Replaced By: A3460100316, +001A3460100064
999
OIL PAN ,011274, Replaced By: A3550100213, +001A3550100466, +001A3550100172, +028N000931008057
999
OIL PAN , Replaced By: A3260101128
999
CYLINDER HEAD , Replaced By: A3260102820
999
CYLINDER LINER133.10 MM
999
GASKET , Replaced By: A3550140022
999
GASKET , Replaced By: A3550140122
999
COVER , UP TO ENGINE 9502936 EXCEPT FOR 9502849-9502873,9502878-9502911,9502913-9502933
999
GASKET , 910,912-918,971-977 013245 983,988 013245 911,977 011791, Replaced By: A3260160321, +001A3261410080
999
GASKET , Replaced By: A3660160421
999
CYLINDER HEAD GASKET , Replaced By: A3260161520
999
CYLINDER HEAD GASKET , Replaced By: A3260161520
999
CYLINDER HEAD GASKET
999
BRACKET , 003250, Replaced By: A3460181540, +001A3461880440, +001A1869901640, +001A3149900040, +001N000933008130, +001N000933008131, +001N000933010129, +001N000933012056, +001N000934008010, +001N006319013300, +002N912004008102
999
SPRING RETAINER , Replaced By: A3260530325
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260530029, +002A3220530125, +002A3260530160
999
VALVE SEAT RING , FOR 326 010 49 20, 326 010 50 20
999
VALVE SEAT RING , FOR 326 010 49 20, 326 010 50 20
999
VALVE GUIDE , UP TO ENGINE 027399,ALSO INSTALLED ON 027459,027464,027467, Replaced By: A3550530330, +001A3520530296
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260531129, +002A3220530125, +002A3260530160
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3460530730, +001A3520530296
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260531229, +002A3220530125, +002A3260530160
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260531329, +002A3220530125, +002A3260530160
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102 NO LONGER AVAILABLE INDIVIDUALLY, Replaced By: A3260531630, +002A3220530125, +002A3260530160
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260531730, +002A3220530125, +002A3260530160
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260531830, +002A3220530125, +002A3260530160
999
GASKET , Replaced By: A3660770080
999
GASKET INTAKE MANIFOLD
999
GASKET , Replaced By: A3551840680
999
GASKET , Replaced By: A3602030280
999
GASKET
999
GASKET KIT , Replaced By: A3265860190
999
GASKET KIT ENGINE GENERAL OVERHAUL
999
GASKET KIT ENGINE CHECK
999
SCREW PLUG ,017214 ONLY FOR REPAIRS ON 3260101028,3260101128,3260101228,3260101328,3260101428,3260101728 OIL PANS
999
EXPANSION PLUG , NO LONGER AVAILABLE INDIVIDUALLY
999
GASKET EXHAUST MANIFOLD TO CYLINDER HEAD
999
OIL PAN ,011275 910,914,915 UP TO ENGINE 043950 ALSO INSTALLED ON 043994,043999,SEE FOOTNOTE 59 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3550100213, +001A3550100466, +001A3550100172, +028N000931008057
999
GASKET OIL PAN
999
SEALING FLANGE , Replaced By: A3451420080
999
GASKET THREE-HOLE
999
PLUG , Replaced By: A3469970135
999
GASKETTO 352 010 01 68
999
GASKET OIL PAN,RIGHT
999
GASKET OIL PAN,LEFT
999
SEALING FLANGE EXHAUST MANIFOLD TO CYLINDER HEAD
999
GASKET OIL COOLER TO OIL FILTER
999
GASKET OIL FILTER TO CYLINDER CRANKCASE
999
GASKET CONNECTOR TO CYLINDER CRANKCASE
999
GASKET CYLINDER HEAD COVER
999
GASKET INJECTION PUMP
999
STUD
999
STUD , SEE GROUP 07
999
STUD BOLT , SEE GROUP 14, TABLE 10, FIG. NO. 20, Replaced By: A3269900019
999
RADIAL SEAL RING
999
SEAL RINGTO 000 429 24 30
999
SEAL RING OIL PAN TO TRANSMISSION
999
SEAL RING SCREW PLUG
999
SEAL RING BRACKET TO CYLINDER HEAD
999
SEAL RING VALVE,CONNECTION "10"
999
SEAL RING BOTTOM
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING SWITCH TO CASE COVER
999
SEAL RING LOCKING VALVE 20X24
999
SEAL RING FROM POWER STEERING PUMP AT ENGINE TO CUT-IN VALVE
999
SEAL RING LINE CONNECTION
999
SEAL RING 2/2-WAY VALVE,CONNECTION: "20"
999
SEAL RING OIL FILLING AND OIL DRAIN
999
SEAL RING OIL FILLING AND OIL DRAIN
999
SEAL RING OIL COOLER CONNECTION
999
SEAL RING , Replaced By: N007603038101
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING
999
SEAL RING TO 18-MM-DIA. COMPRESSED AIR LINES
999
GASKET , Replaced By: N917003026003
999
SEAL. GASKET , Replaced By: A3661880880
