Главная
Mercedes
BUS
O 140
341.251
26 TRANSMISSION
001 TRANSMISSION IL. 4

Mercedes N912004008102 - Кольцо стопорное

O 140 341.251

26 TRANSMISSION - 001 TRANSMISSION IL. 4

Поз.
Артикул
Описание
153
A3413200606
REAR SPRING 12-LEAF
156
A3213200293
SPRING LEAF NO.1
159
A3203210250
BUSHING
162
A3209900151
HEX.NUT. NUT
165
A3213240712
SPRING LEAF LEAF NO.2
168
A3213240713
SPRING LEAF LEAF NO. 3
171
A3213240714
SPRING LEAF LEAF NO.4
174
A3213240233
SPRING CLAMP LEAF NO.5
177
N000124010066
RIVET
180
A3213240033
SPRING CLAMP LEAF NO.9
183
N000124010066
RIVET
186
A3213240138
SLIDING BLOCK
189
N004626012120
SPRING BOLT
192
N000934012010
NUT SPRING BOLT
195
A3443240053
SPACER TUBE U-BOLT
198
N000601012003
SCREW U-BOLT
201
N000934012000
HEX. NUT M 12 DIN 934-5 S. NUT , Replaced By: N000934012021
204
A3213200063
SHACKLE REAR SPRING
207
A3203210250
BUSHING
210
A3209900151
HEX.NUT. NUT
213
A3213250601
REAR SPRING BRACKET FRONT
216
A3213250403
REAR SPRING BRACKET REAR
219
N000961012120
SCREW ENGINE SUPPORT TO SIDE MEMBERS M 12X40
222
N000936012013
NUT
228
A3213220030
SHACKLE PIN REAR SPRING
231
N071412010300
GREASE NIPPLE
234
A3123220173
LOCK
237
A3203220184
SHIM
240
N912004008102
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
243
N000933008025
SCREW
999
A0003212553
SPACER TUBE SPRING CLAMP TO SPRING LEAF NO.3, TO 682 320 74 02
999
A0003219433
SPRING CLAMP , Replaced By: A6173210333
999
A0013216533
999
A3213200543
BRACKET SPRING SEAT
999
A3213201808
999
A3219900255
NUT LEVER TO TORSION BAR
999
A3219900951
999
A3443260165
TORSION BAR
999
H990003230000
999
N000094004065
COTTER PINROCKINGER TYP 260 G140
999
N000094006311
COTTER PIN LEVER TO TORSION BAR
999
N000934012016
NUT , Replaced By: A0019900650
