Поз.
Артикул
Описание
5
EXPANSION PLUG OIL DIPSTICK BORE
10
OIL PAN
10
OIL PAN
10
OIL PAN
10
OIL PAN
28
OIL PAN
28
OIL PAN
55
GASKET FLANGE TO OIL PAN
55
GASKET , Replaced By: A3660180380
64
CYLINDRICAL HEAD SCREW. SCREW BALANCING PLATES TO FAN AND TO PULLEY M 6X15
64
SCREW BALANCING PLATE TO FAN
64
SCREW STEERING SHAFT BEARING TO CAB M 8X22
91
FLANGE
109
SCREW CLUTCH TO FLYWHEEL,760271
109
SCREW CLUTCH TO FLYWHEEL M 8X50,838705
145
GUIDE TUBE OIL DIPSTICK
154
PIPE OIL DIPSTICK
163
SEALING RING. SEAL RING GUIDE TUBE SEAL HOLDER
172
SEAL RING PREHEATER TO OIL PAN
172
SEAL RINGTO 376 131 74 01
190
SCREW PLUG
190
SCREW PLUG , Replaced By: N000908022011
388
SCREW OIL PAN TO CYLINDER CRANKCASE
388
SCREW
388
SCREW
406
SPRING WASHER LICENSE PLATE TO BRACKET
406
SPRING WASHER OIL PAN TO CYLINDER CRANKCASE
999
SCREW BEARING COVER TO TRANSMISSION CASE M 8X65
999
GUIDE TUBE OIL DIPSTICK
999
SCREW PLUG
999
FITTING , Replaced By: N915013008002
999
NUT
999
GASKET , Replaced By: A3140142322
999
GASKET
999
GASKET
999
GASKET
999
OIL PAN
999
OIL PAN , Replaced By: A3520108913
999
GUIDE TUBE , Replaced By: A3520184216
999
OIL DIPSTICK , Replaced By: A3520100074
999
GUIDE TUBE
999
OIL PAN
999
SCREW PLUG , Replaced By: N000908016000
999
COVER , Replaced By: A3520102535
999
OIL DIPSTICK
999
SCREW OIL PAN TO CYLINDER CRANKCASE
999
SCREW TRAILER CONTROL VALVE TO BRACKET,4 940459
