Поз.
Артикул
Описание
7
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY 28V/75A "WAPSA"
7
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY "BOSCH", 14V, 55A
7
ALTERNATOR , Replaced By: A3431507350
7
ALTERNATOR
7
ALTERNATOR , Replaced By: A3441507450
7
ALTERNATOR , Replaced By: A3441507850
7
ALTERNATOR , Replaced By: A3761507750
7
ALTERNATOR WITH PULLEY, LESS REGULATOR 12 V/55 A
7
ALTERNATOR , Replaced By: A3431507150
7
ALTERNATOR , Replaced By: A3441507350
7
ALTERNATOR28V 35A, WITH TERMIANL "W"
21
ALTERNATOR
21
ALTERNATOR28V/105A,"BOSCH", NOT USED
28
SCREW
28
SCREW , MODEL 343.919.000 FROM ENGINE 154150,MODEL 344.919.000 FROM ENGINE 822957
28
SCREW
28
SCREWTO 344 150 73 50
28
SCREW
28
SCREW , Replaced By: A0009907721
28
SCREW , Replaced By: A0019906420
29
LOCK WASHERTO 344 150 73 50
31
BEARING
31
BEARING COVER ,822957
31
CONNECTORTO 007 154 19 02, NOT USED
31
BEARING DRIVE END BEARING
31
BEARING , Replaced By: A0001513149
31
BEARING , Replaced By: A0001514149
35
BEARINGTO 344 154 71 02
35
BEARINGTO 345 154 71 01
38
BEARINGTO 376 150 80 50
38
BEARINGTO 476 154 77 01, 345 154 76 01
38
COVER
38
COVERTO 344 150 71 50,80 50,344 154 75 01
38
BEARING , Replaced By: A0001540949, +001A0001550250
38
BEARING , Replaced By: A0001542449
42
BRUSH HOLDERTO 345 150 70 50
42
BRUSH HOLDERTO 344 154 71 02
49
CARBON BRUSH SET
49
REPAIR KITTO 344 154 71 02
49
CARBON BRUSH SET , Replaced By: A0001548614
49
CARBON BRUSH SETTO 344 154 71 02
49
CARBON BRUSH SET , Replaced By: A0001547614
56
SPRING , Replaced By: A0001541393
56
SPRING
58
CARBON BRUSH SETTO 343 150 73 50
58
CARBON BRUSH SET , Replaced By: A0001549514
58
CARBON BRUSH SET , Replaced By: A0001549814
58
CARBON BRUSH SETTO 366 150 07 50, 376 150 83 50
60
SPRING
60
SPRINGTO 004 154 75 02
63
SPRINGTO 344 154 71 02
70
ROTOR
70
ROTOR ,822956
70
ROTOR
70
ROTOR
70
ROTORTO 345 150 70 50
70
ROTOR , Replaced By: A0001545015
70
ROTOR , Replaced By: A0001547815
70
ROTOR , Replaced By: A0001545715
70
ROTOR , Replaced By: A0001547815
77
REPAIR KIT , Replaced By: A0001500872
77
MOUNTING KIT ARMATURE MOUNTING
77
REPAIR KIT ARMATURE MOUNTING TO 343 150 73 50
77
REPAIR KIT TERMINALS: B+, B-, D+, W TO 007 154 19 02, NOT USED
77
REPAIR KIT ROTOR TO 007 154 28 02
77
REPAIR KIT ROTOR
79
INSULATOR TERMINALS: B+, B-, D+, W
84
BALL BEARINGTO 344 154 71 02
84
BALL BEARING FRONT AND REAR
84
BALL BEARING
84
BALL BEARING FRONT AND REAR
84
GROOVED BALL BEARING LEFT ALTERNATOR MOUNTING,061991
84
GROOVED BALL BEARING , Replaced By: N000625436303
84
TAPERED ROLLER BEARING , Replaced By: A0049812425
85
COVER
86
COVER
86
COVER , Replaced By: A0001540767
91
BALL BEARING REAR
91
BALL BEARINGTO 344 154 71 02
91
BALL BEARINGTO 005 154 34 02
94
SEAL RING , MODEL 343.919.000 FROM ENGINE 154150,MODEL 344.919.000 FROM ENGINE 822957
96
WOODRUFF KEY POWER STEERING PUMP
98
LOCK WASHER SUPPORT TO SIDE MEMBER
105
NUT TRAILER COUPLING TO FRAME
105
NUT PULLEY TO ALTERNATOR
105
NUT BRACKET TO SIDE MEMBER
105
NUT
112
SEAL RINGTO 005 154 34 02
119
SEAL RING , NOT USED
119
RINGTO 009 154 72 02, 345 154 76 01
133
SPACER RING
140
SEAL RING
147
CYLINDR. ROLLER BEARING
154
RECTIFIERTO 005 154 45 02,006 154 86 02
154
RECTIFIER
154
RECTIFIER , Replaced By: A0001545116
161
SCREW
163
LOCK WASHERTO 344 150 74 50,78 50
168
STUD
175
DIODE , Replaced By: A0015481018
175
DIODE , Replaced By: A0015481118
175
DIODE , Replaced By: A0005487818
175
DIODE , Replaced By: A0005489818
175
DIODE NEG. TO 344 154 71 01,344 154 72 01, MODEL 343.919.000 UP TO ENGINE 154149,MODEL 344.919.000 UP TO ENGINE 822956
182
DIODE POS.
182
DIODE POS., TO 003 154 26 02
182
DIODE , Replaced By: A0005487718
182
DIODE , Replaced By: A0005485018
182
DIODE POS.
189
DIODE CARRIER COMPLETE
189
DIODE , Replaced By: A0005486518
191
CONNECTOR , Replaced By: A0001541818
191
CONNECTOR , Replaced By: A0001541818
191
BEARING COVER ,822957
196
COILTO 007 154 19 02, NOT USED
196
COILTO 344 150 74 50,78 50
196
COILTO 345 154 71 01
196
COIL
196
COIL EXCITER TO 343 150 73 50
196
COIL , Replaced By: A0001545325
196
COIL , Replaced By: A0001547125
196
COIL , Replaced By: A0001546625
196
COIL , Replaced By: A0001546725
196
COIL , Replaced By: A0001548825
196
COIL EXCITER
203
GASKET
210
REGULATOR AND CUT-OUT
210
REGULATOR AND CUT-OUT , Replaced By: A0021546806
210
REGULATOR AND CUT-OUTTO 343 150 73 50
210
REGULATOR AND CUT-OUTTO 344 150 73 50
217
COMBINATION BOLT
224
CONDENSER
224
CONDENSER , Replaced By: A0011566701
226
SCREW CONDENSER TO ALTERNATOR
228
LOCK WASHERTO 376 150 74 50
231
FANTO 376 150 80 50,86 50
231
FAN FAN ONE-GROOVE V-BELT PULLEY
231
FAN WITH PULLEY
231
FAN , Replaced By: A0001557918
231
FAN , Replaced By: A0001557218
238
FAN
239
COVERTO 476 154 77 01, 345 154 76 01
245
PULLEY , Replaced By: A0001558415
245
PULLEY , MODEL 343.919.000 FROM ENGINE 154150,MODEL 344.919.000 FROM ENGINE 822957
252
PULLEY ALTERNATOR
259
MOUNTING KIT
259
REPAIR KIT
266
SCREW HOUSING
266
SCREWTO 344 154 71 02
266
SCREW , Replaced By: A0019900821
266
SCREW , Replaced By: A0001540471
266
SCREW , Replaced By: A0001540571
268
INSULATING PART PARTS KIT B+, MODEL 343.919.000 FROM ENGINE 154150,MODEL 344.919.000 FROM ENGINE 822957
270
INSULATING PART PARTS KIT
271
INSULATING PART , OM 352 FROM ENGINE 823237,OM 352 A FROM ENGINE 822957
273
FANTO 344 150 74 50
273
PULLEY ALTERNATOR
273
PULLEY , Replaced By: A3431507074
280
CYLINDRICAL PIN ,822957
287
SUPPORT ALTERNATOR
287
SUPPORT ALTERNATOR
294
BUSHING
294
BUSHING
301
SCREW ENGINE SUPPORT TO CYLINDER CRANKCASE
301
SCREW , Replaced By: N304017012020
302
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
308
SCREW , Replaced By: N308676012018
308
SCREW SPACER TUBE BETWEEN STABILIZER SHACKLES 12X1.5X75,D 228765
315
WASHER SUPPORT TO FRAME,D 127794
322
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
329
CLAMPING BOLT ALTERNATOR
329
CLAMPING BOLT ALTERNATOR
329
CLAMPING BOLT (CLAMPING BOLT)
336
SCREW BRACKET TO RETARDER
343
WASHER 10,5 DIN 433. WASHER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
350
SCREW , Replaced By: N308676012016
999
SPACER RING
999
SPACER WASHER
999
RING
999
BEARING
999
BEARING
999
REGULATOR
999
COIL
999
ROTOR
999
SUPPRESSOR CAP
999
SCREW
999
BOLT. SCREW
999
NUT PULLEY TO ALTERNATOR
999
SCREW CARBON BRUSHES TO 344 150 78 50
999
RECTIFIER
999
PULLEY
999
SCREW REGULATOR AND CUT-OUT
999
V-BELT12.5X1200
999
NUT
999
V-BELT
999
ALTERNATOR , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0091540602
999
SCREW
999
SCREW
999
PULLEY
999
ALTERNATOR , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE 128099, Replaced By: A3441547101
