Поз.
Артикул
Описание
4
CLUTCH DISC
8
STUD BOLT
13
WASHER RADIATOR TO RUBBER MOUNTING
18
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
23
NUT BRACKET TO SUPPORT AND TO END PIECE
28
END HOUSING
33
CLUTCH SHAFT
36
SEAL RING
41
SELF-ALGN. ROLLER BEARING
44
SPACER RING
48
LOCK AS REQUIRED 2.50 MM
48
LOCK RING , Replaced By: A3872626373
52
LOCK
55
SCREW
58
CYLINDRICAL PIN INTERMEDIATE FLANGE TO HOUSING, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
63
LOCK WASHERROCKINGER TYP 59 G140,59 G150
66
SCREW CONNECTING PIPE
72
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
75
SCREW REAR EXHAUST PIPE TO MUFFLER
78
GASKET
83
END COVER
86
SEAL RING
89
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
93
SCREW PIPE CLAMP
93
SCREW , Replaced By: N304017008021
96
KEY
99
SPACER WASHER
103
LOCK WASHER SPARE WHEEL TO BRACKET
107
SCREW CROSS MEMBER TO REINFORCEMENT M 20X1.5X45
110
CLAMPING SLEEVE ENGINE SUPPORT
114
COVER PLATE
117
LOCK WASHER LINE MOUNTING
120
SCREW
124
ELBOW
130
HOSE
135
BULKHEAD FITTING
139
LOCK WASHER
143
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
143
WASHER , Replaced By: N000125015019
147
GREASE NIPPLE , Replaced By: N071412008102
147
GREASE NIPPLE
150
DOUBLE TAPER RING RELEASE COLLAR LUBRICATION
154
UNION SCREW RELEASE COLLAR LUBRICATION
158
BRACKET
161
HEXAGON HEAD BOLT PROTECTIVE PLATE TO BRACKET
161
SCREW , Replaced By: N304017008008
166
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
SEAL RING , Replaced By: A0069976946
999
DOWEL PIN
