Поз.
Артикул
Описание
10
COMPRESSOR
16
STUD BOLT BRACKET TO TRANSMISSION
19
SEAL RING SWITCH TO CASE COVER
23
SCREW PLUG
26
FITTING
29
CRANKSHAFT
33
CONNECTING ROD
36
BUSHING
37
SPACER WASHER
39
LOCK RING SHACKLE TO BEARING BRACKET,965965
43
SEAL RING
45
GROOVED BALL BEARING BEARING BODY,6 900042
48
SEAL RING
53
GASKET
56
BEARING CAP
58
SEAL RINGTO 001 431 72 14
58
SEAL RING RELAY VALVE,CONNECTION: "41"
61
FITTING OVERFLOW VALVE,CONNECTION: "10"
64
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
66
NUT BALL PIVOT TO LEVER
69
SCREW
73
GASKET
76
PISTON
79
PISTON RING
83
PISTON RING
86
LOCK RING
93
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
95
NUT
98
GASKET , Replaced By: A0011314380
98
GASKET
102
CYLINDER HEAD
104
VALVE
126
VALVE
158
SPRING RETAINER
161
SPRING CYLINDER HEAD
164
SEAL RINGTO 345 430 72 01
169
SEAL RINGTO 376 131 74 01
176
WOODRUFF KEY POWER STEERING PUMP
179
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
183
NUT , Replaced By: N308675014000
183
NUT , Replaced By: N308675014002
183
NUT RELEASE BEARING LUBRICATION
192
INTAKE PIPE
196
NUT CHECK VALVE TO AIR RESERVOIR
199
HOSE , ORDER BY THE METER
201
CLAMP25-40X13 MM
201
LOOM TIE , Replaced By: N000000000668
201
CLAMP , Replaced By: A0069970490
203
PULLEY
206
V-BELT FROM ENGINE TO BELT TIGHTENER PULLEY 12.5X1450 MM
209
SUPPORT
209
SUPPORT
213
PIN AIR COMPRESSOR SUPPORT TO BEARING BODY
219
LOCK WASHER SUPPORT TO BEARING BODY
221
NUT ROD TO TORSION BAR
221
NUT , Replaced By: N308675020003
223
LOCK RING ,825817, 301,303,304,305, 868276, 311,313,314825818, 301,303,304,305, 868277, 311,313,314 SEE SPARE PARTS LIST 740.3
226
SCREW AIR COMPRESSOR SUPPORT TO BEARING HOUSING
229
LOCK WASHER FITTING TO BRACKET
233
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
233
WASHER , Replaced By: N007349013005
236
SCREW (CLAMPING BOLT)
239
LOCK RING
241
WASHER EXHAUST MUFFLER TO STRAP
241
WASHER , Replaced By: N000125008443
243
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
246
SCREW PROPELLER SHAFT TO COUPLING FLANGE
