Поз.
Артикул
Описание
17
UNION NUT
21
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
30
VALVE"WABCO DO BRASIL"
30
VALVE , Replaced By: A0004342401
30
VALVE"WESTINGHOUSE"
35
HANDLETO 000 434 24 01
40
PROTECTIVE CAPTO 000 434 08 01,345 434 71 01
40
CUP 3/2-WAY VALVE WABCO
45
SEAL RINGTO 000 434 23 01
50
CLEANERTO 000 434 22 01
55
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
55
REPAIR KIT SMALL SCOPE TO 345 434 71 01
57
REPAIR KIT 3/2-WAY VALVE WABCO
60
ELBOW FITTING TEST CONNECTION TO BRACKET
60
ELBOW FITTING AT CYLINDER
65
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
65
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
70
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
75
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
80
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
85
SEAL RING LINE CONNECTION
90
GROMMET MAIN CABLE HARNESS THRU CAB
95
WASHER CLUTCH PEDAL AND BRAKE PEDAL
100
PROTECTIVE PLATE OPERATING VALVE TO SIDE MEMBER SHELL
105
NUT , Replaced By: N080705026003
110
SPRING WASHER OPERATING VALVE TO SIDE MEMBER SHELL
125
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
130
SEAL RING
175
UNION NUT
180
GLAND , Replaced By: A0019901667
270
VALVE (OVERFLOW VALVE)
270
VALVE
270
VALVE (OVERFLOW VALVE)
275
VALVE (OVERFLOW VALVE)
280
VALVE
285
VALVE SEAT RINGWABCO,5 433388
290
DIAPHRAGM
295
DIAPHRAGMTO 000 429 63 44
300
SPRINGTO 000 429 63 44,000 429 59 44
305
SPRING RETAINERTO 000 429 63 44,000 429 59 44
310
REPAIR KITTO 001 429 52 44
310
REPAIR KITBOSCH
315
REPAIR KITTO 000 429 63 44,000 429 59 44
320
T-FITTING
320
T-FITTING AT DISTRIBUTOR,4 481288
325
NUT CHECK VALVE TO AIR RESERVOIR
330
THRUST RING CHECK VALVE TO AIR RESERVOIR
330
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
335
O-RING CHECK VALVE TO AIR RESERVOIR
340
PIN AT PRESSURE REGULATOR
345
UNION NUT
350
GLAND , Replaced By: A0019901667
999
DIAPHRAGM , Replaced By: A0004290745
999
REPAIR KIT , Replaced By: A0034301281
999
LOCK NUT OVERFLOW VALVE
