Поз.
Артикул
Описание
336
LINE FROM OIL TANK TO PUMP
340
UNION NUT LINE CONNECTION, Replaced By: N000000006243
344
GLAND , Replaced By: A0019901267
348
HOSE , Replaced By: A3859971582
348
HOSE , Replaced By: A3849977482
352
CLAMP HOSE TO OIL TANK AND TO SUCTION LINE
352
CLAMP HOSE TO FITTING AND TO OIL TANK
352
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
356
LINE FROM HOSE TO PUMP
360
UNION NUT LINE CONNECTION, Replaced By: N000000006243
364
GLAND , Replaced By: A0019901267
372
LINE FROM OIL PUMP TO HIGH PRESSURE HOSE 15X1.5 MM, 345.200 FROM IDENT NO. 004796
376
UNION NUT LINE CONNECTION
380
GLAND LINE CONNECTION
384
SCREW CONNECTION POWER STEERING PUMP
388
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
392
FITTING POWER STEERING PUMP M16X1,5/M22X1,5,D 084765
396
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
400
HOSE ,12005921
400
HOSE FROM PUMP TO STEERING
400
HOSE FROM PUMP TO STEERING
400
HOSE FROM PUMP TO DELIVERY LINE
404
LINE FROM HOSE TO DOUBLE FITTING I 15X1.5 MM,793543 345.200 FROM IDENT NO. 004796
408
LINE FROM DOUBLE FITTING I TO DOUBLE FITTING II 15X1.5 MM
412
LINE FROM DOUBLE FITTING I TO DOUBLE FITTING II 15X1.5 MM
420
LINE FROM CONNECTOR III TO CONNECTOR IV
424
LINE FROM CONNECTION FITTING TO STEERING
428
UNION NUT LINE CONNECTION
432
GLAND LINE CONNECTION
436
CONNECTION FITTING HIGH PRESSURE LINE TO STEERING
440
FITTING POWER STEERING PUMP M16X1,5/M22X1,5,D 084765
444
SEAL RINGTO 006 997 00 72
448
FITTING STEERING, 345.200 FROM IDENT NO. 004796
452
SEAL RING VALVE TO VALVE,K 025179
456
LINE FROM STEERING TO DOUBLE FITTING I 22X1.5 MM, 345.200 FROM IDENT NO. 004796
460
LINE FROM DOUBLE FITTING I TO DOUBLE FITTING II 22X1.5 MM, 345.200 FROM IDENT NO. 004796
464
LINE FROM STEERING TO OIL TANK
468
LINE FROM DOUBLE FITTING III TO DOUBLE FITTING IV 22X1.5 MM
472
LINE FROM CONNECTOR IV TO CONNECTOR V 22X1.5 MM
484
LINE FROM CONNECTION FITTING V TO OIL TANK
492
UNION NUT LINE CONNECTION, Replaced By: N000000006243
496
GLAND , Replaced By: A0019901267
504
CONNECTION FITTING
508
CLAMP LINE MOUNTING
508
CLAMP DELIVERY AND SUCTION LINES TO FRAME
512
SHEET METAL SCREW OIL LINE MOUNTING
516
SCREW COMPRESSED AIR LINE TO SIDE MEMBER
516
SCREW COMPRESSED AIR LINE TO ENGINE MOUNTING SUPPORTING ARM
520
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
524
WASHER , Replaced By: N009021006208
524
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
528
NUT BALL PIVOT TO LEVER
532
SCREW , FROM CHASSIS 107.042 004151 107.043 013550 107.044 046789
536
SOCKET NUT FRONT SEATS TO BRACKETS, UP TO CHASSIS 021371 EXCEPT FOR 021350,021362-021364 UP TO CHASSIS 044444 EXCEPT FOR,SEE FOOTNOTE 91
540
BRACKET BRACKET TO CROSS MEMBER
548
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
552
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
556
NUT BRACKET TO FRAME
572
BRACKET
588
SCREW BRACKET TO BUMPER,LEFT M 10X25
592
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
596
NUT BRACKET TO FRAME
616
LINE12X1.5 MM, LENGTH AVAILABLE 3000 MM
620
LINE15X1.5 MM, LENGTH AVAILABLE 3000 MM
620
LINE15X1.5 MM, LENGTH AVAILABLE 3000 MM
624
LINE22X1.5 MM, LENGTH AVAILABLE:3000 MM
999
CLAMPING RING STRAIGHT END TO 345 460 91 05,680437, 344.012-344.015
