Поз.
Артикул
Описание
12
BEARING BRACKET ,A 042213, Replaced By: A3412907119
12
BEARING BRACKET PEDAL ASSEMBLY, 775549 RANGE OF DELNERY INCLUDES 1 X 352 323 03 40, 1 X 351 990 32 01, 1 X 913002 02000, 1 X 352 990 35 01, 1 X 913004 016001, UP TO IDENT NO. 802164
25
BEARING TUBE , Replaced By: A3442907036
25
BEARING TUBE
36
BUSHING
36
BUSHING , Replaced By: A3442940150
48
GREASE NIPPLE PROTECTIVE TUBE
59
SCREW
70
REINFORCEMENT AT SIDE MEMBER, UP TO IDENT NO. 775548 EXCEPT FOR 500001-599999
85
PEDAL ,A 006846
85
87
87
PEDAL CLUTCH
89
BUSHING
91
SPACER RING PEDAL TO BEARING BRACKET
91
SPACER RING AS REQUIRED 3.25 MM
91
SPACER RING AS REQUIRED 3.50 MM
94
RING AS REQUIRED 3.0 MM
98
LEVER , Replaced By: A3452931310
110
YOKE PULL ROD TO LEVER
121
NUT BRACKET TO SUPPORT AND TO END PIECE
133
PULL ROD BELT TIGHTENER
145
TURNBUCKLE
156
PULL ROD CLUTCH ACTUATION M10X200/40, TO BE ADAPTED DURING ASSEMBLY
168
NUT L.H. THREAD
180
YOKE R.H. THREAD
191
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
205
WASHER VIBRATION ABSORBER TO BRACKET
205
WASHER , Replaced By: N000433010510
215
SPRING WASHER , Replaced By: N000137010205
215
SPRING WASHER SHIFTING ROD TO BRACKET
232
LEVER ,775548 NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IM REPAIR KIT, Replaced By: A3525860229
232
LEVER , Replaced By: A3522901728
232
232
232
LEVER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IM REPAIR KIT THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3525860029
233
REPAIR KIT , Replaced By: A3522905539
233
REPAIR KIT , Replaced By: A3522905639
233
REPAIR KIT CLUTCH ACTUATING PARTS, DELIVER ADDITIONALLY:1X 352 991 09 15,1X 000463 017001,1X 000934 016011,2X 006797 012151,1X 352 991 04 15
233
REPAIR KIT CLUTCH ACTUATING PARTS
244
SNAP RING DOUBLE LEVER TO BRACKET
257
BALL PIVOT RELEASE YOKE
257
BALL PIVOT RELEASE YOKE
257
BALL PIVOT ,FB001827
270
LOCK WASHER FITTING TO BRACKET
281
NUT
281
NUT , Replaced By: N304035012002
292
BALL PIVOT RELEASE YOKE
292
BALL PIVOT RELEASE YOKE
301
SEAL RING DOUBLE LEVER TO BRACKET
315
LOCK PLATE SHIFT CASE
328
SPACER
328
BALL PIVOT , Replaced By: A3529910915
340
NUT , Replaced By: N308673016001
340
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
347
BALL PIVOT DOUBLE LEVER TO TRANSMISSION CASE COVER
347
BALL PIVOT , Replaced By: A3529910515
352
BEARING BRACKET , Replaced By: A3522932536
352
BEARING BRACKET , Replaced By: A3522932536
352
BEARING BRACKET
352
BEARING BRACKET OUTSIDE
368
BALL SOCKET BELT TIGHTENER
377
NUT BRACKET TO EXHAUST PIPE BRACKET
389
PULL ROD CLUTCH ACTUATION M10X200/40, TO BE ADAPTED DURING ASSEMBLY
399
CIRCLIP POWER CYLINDER TO THROTTLE VALVE LEVER
412
RELEASE LEVER IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 352 293 03 11,302 991 00 15
424
BALL PIVOT ,FB001827
424
BALL PIVOT RELEASE YOKE
424
BALL PIVOT RELEASE YOKE
439
SPRING LOCK RELEASE LEVER TO RELEASE BEARING, UP TO CHASSIS 4 691315, FROM CHASSIS 4 691316 SEE STANDARD VERSION
453
BRACKET OUTSIDE,4 696330
465
BEARING ,763226, Replaced By: A3802540035, +001A3852540051, +001A3802540159
480
BRACKET INSIDE,4 696330
493
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
505
SCREW PIPE CLAMP
505
SCREW , Replaced By: N304017008021
518
RELEASE BEARING , Replaced By: A3402500215
518
RELEASE BEARING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 473926, Replaced By: A3402500215
518
RELEASE BEARING CLUTCH, UP TO IDENT NO. 4 473926,FROM IDENT NO. SEE MICROFICHE STANDARD
530
RELEASE BEARING
530
RELEASE BEARING , UP TO IDENT NO. 4 473926,FROM IDENT NO. SEE MICROFICHE STANDARD
541
STRIP RELEASE BEARING TO 340 250 02 15, UP TO IDENT NO. 4 473926,FROM IDENT NO. SEE MICROFICHE STANDARD
541
STRIP ,KB846165
553
BOOT , UP TO CHASSIS 4 691315, FROM CHASSIS 4 691316 SEE STANDARD VERSION, Replaced By: A3142540197
553
BOOT RELEASE LEVER, UP TO CHASSIS 4 691315, FROM CHASSIS 4 691316 SEE STANDARD VERSION
564
PIN , Replaced By: A3412917074
599
LEVER , Replaced By: A3412917032
610
SPRING (RELEASE SPRING)
610
SPRING , Replaced By: A3769930110
622
PEDAL BRAKE
622
PEDAL BRAKE
634
BUSHING
645
SPACER RING AS REQUIRED 3.25 MM
645
SPACER RING AS REQUIRED 3.50 MM
645
SPACER RING PEDAL TO BEARING BRACKET
657
RING AS REQUIRED 3.0 MM
669
PULL ROD BRAKE LINKAGE
680
NUT BRACKET TO SUPPORT AND TO END PIECE
691
YOKE PULL ROD TO LEVER
691
YOKE , Replaced By: A0009961501
702
YOKE , Replaced By: A3419967001
711
NUT L.H. THREAD
723
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
736
SPRING WASHER SHIFTING ROD TO BRACKET
736
SPRING WASHER , Replaced By: N000137010205
749
WASHER , Replaced By: N000433010510
749
WASHER VIBRATION ABSORBER TO BRACKET
760
PEDAL PLATE CLUTCH
772
PEDAL PLATE , Replaced By: A3452907224
772
PEDAL PLATE CLUTCH PEDAL
786
PAD BRAKE AND CLUTCH LEVERS
799
WASHER CLUTCH PEDAL AND BRAKE PEDAL
812
SEAL RING CLUTCH PEDAL AND BRAKE PEDAL
812
SEAL WASHER
822
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
COVERTO 352 250 01 15, UP TO IDENT NO. 145736 ALSO INSTALLED ON: 145741,145768,145770,145774,145786,145787,145795,145807,145808,145819,145825,145830,145837,145840, 145846,145860,145861,145888,145901,145907,145910,145911,145913-145917,146138. EXCEPT FOR 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660,145697,145701.
999
PEDAL PLATE CLUTCH AND BRAKE
999
RELEASE YOKE , Replaced By: A3522930311, +001A3029910015
999
BEARING OUTSIDE, INAPPLICABLE TO SUPERCHARGING SYSTEM609835
999
BEARING OUTSIDE, UP TO IDENT NO. 148036 EXCEPT FOR 140555,142078
999
BEARING BRACKET ,775548, Replaced By: A3522901819, +001A3522910732, +001A3529931310
999
BEARING BRACKET ,775548, Replaced By: A3522901919, +001A3522910732, +001A3529931310
999
ROD
999
ROD
999
999
ROD CLUTCH OPERATION
999
LEVER CLUTCH PEDAL RELEASE SPRING, 600777-601108
999
BRACKET INSIDE, INAPPLICABLE TO SUPERCHARGING SYSTEM609835
999
BRACKET RELEASE YOKE TO BELL HOUSING, UP TO IDENT NO. 148036 EXCEPT FOR 140555,142078
999
SEAL RING
999
RELEASE YOKE RELEASE LEVER
999
LEVER BRAKE
999
WASHER REAR AXLE TO TO REAR SPRINGS
999
BALL PIVOT ,FB001827
999
BALL PIVOT
999
BEARING RELEASE YOKE
999
SEAL RING RELEASE YOKE
999
BEARING RELEASE YOKE
999
SEAL RING RELEASE YOKE
999
SEAL RING RELEASE YOKE
999
SEAL RING RELEASE YOKE
999
COTTER PIN CYLINDER TO BRACKET
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER
999
LOCK PLATETO 000 261 04 01
999
SCREW MOUNTING AND RAIL TO LEAF SPRING
999
SCREW , Replaced By: N304017010030
999
SCREW , Replaced By: N304017008021
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
NUT STRAP TO SUPPORT,5 149419
999
SCREW REINFORCEMENT TO ROCKER PANEL
999
GREASE NIPPLE , Replaced By: N071412008102
999
GREASE NIPPLE
999
SCREW , Replaced By: N304017010053
999
NUT STRAP TO BRACKET
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
NUT , Replaced By: N910113010000
