Поз.
Артикул
Описание
3
RUBBER MOUNTING ENGINE FRONT SUSPENSION
9
ENGINE STAY RUBBER MOUNTING TO FRONT CROSS MEMBER
13
LOCK WASHER FITTING TO BRACKET
14
NUT STRAP TO SUPPORT
18
SCREW STEERING SUPPORT TO FRAME M 14X50
21
SPRING WASHER BEARING BRACKET TO SIDE MEMBER,4 207081
24
WASHER CONSOLE TO FRAME
29
RUBBER MOUNTING
33
ENGINE STAY RUBBER MOUNTING TO ENGINE REAR SUPPORT
37
LOCK
41
SCREW MOUNTING TO CONSOLE M 14X35
41
SCREW , Replaced By: N308676014008
41
SCREW , Replaced By: A9429901304
41
SCREW APPARATUS SUPPORT TO FRAME
44
BEARING BRACKET FRONT
44
BEARING BRACKET FRONT
47
ROD , Replaced By: A3452407125
49
ROD ENDTO 352 240 02 25
52
NUT , Replaced By: N308673016001
52
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
57
ROD ENDTO 352 240 02 25
59
NUT L.H. THREAD TO 352 240 02 25
62
BEARING BRACKET ENGINE ALONGSIDE FIXING,REAR
65
SCREW PULL ROD TO BEARING BRACKET
70
NUT SHOCK ABSORBER TO CROSS MEMBER
70
NUT , Replaced By: N000979016007
999
RUBBER MOUNTING , 695022, Replaced By: A3522400417, +002A3529902440, +002N000960016014
999
RODTO 352 240 02 25
999
WASHER RUBBER MOUNTING TO FRONT CROSS MEMBER, UP TO IDENT NO. 695022 EXCEPT FOR,500001-599999
999
COTTER PIN STRAP TO CONSOLE
999
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
999
SCREW BEARING BRACKET TO FRAME
999
SCREW , Replaced By: N000961012051
999
SCREW , Replaced By: N308676016005
999
SCREW SUPPORT TO TRANSMISSION M 16X1.5X60
999
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
