Поз.
Артикул
Описание
1
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
1
LINE , Replaced By: A0005516256
3
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
4
O-RING CHECK VALVE TO AIR RESERVOIR
5
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
5
THRUST RING CHECK VALVE TO AIR RESERVOIR
6
NUT CHECK VALVE TO AIR RESERVOIR
7
VALVE ,4 390315
8
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
8
SEAL RING , Replaced By: A0079974245
9
SEAL RING ,4 390315
10
SEAL RING ,4 390315
11
VALVE SEATWABCO
12
PROTECTIVE CAP , Replaced By: A0014310487
12
PROTECTIVE CAP ,4 390315
13
VALVE SEAT ,4 390315
14
SEAL RING18.72X2.62 MM,WABCO,002 0,012 0
14
SEAL RING , Replaced By: A0059976545
15
SPRING ,4 390315
16
SEALING CORD38X8 MM
17
WASHER ,4 390315
18
WASHER ,4 390315
19
LOCK RING
20
SEAL RING ,4 390315
21
SEAL RING ,4 390315
22
SEAL RING ,4 390315
25
SEAL RING17X3.5,TO A 003 429 35 44, NOT USED
26
LOCKING CAP TRAILER BRAKE VALVE
27
LOCK RINGTO 000 431 94 14,000 431 96 14
28
AIR CLEANER ,4 390315
30
SEALING RING. SEAL RING
31
REPAIR KITWABCO
33
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
33
FITTING , Replaced By: A0009970171
34
T-FITTING COMPRESSED AIR VALVE CONNECTION
35
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
36
SEAL RING LINE CONNECTION
39
SHUT-OFF COCK , Replaced By: A0004291431
39
SHUT-OFF COCK
39
SHUT-OFF COCK
40
REPAIR KITTO 000 429 14 31,5 116581
40
REPAIR KITTO 000 429 10 31
41
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
42
FITTING SHUTTLE VALVE,CONNECTION: "20"
42
FITTING , Replaced By: A0019972372
43
SEAL RING LINE CONNECTION
44
PLATE BRAKE
44
PLATE SUPPLY
45
BRAKE LINE COUPLING
46
O-RING CHECK VALVE TO AIR RESERVOIR
47
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
47
THRUST RING CHECK VALVE TO AIR RESERVOIR
48
NUT CHECK VALVE TO AIR RESERVOIR
49
BRACKET , 674068-875476
50
FITTING , Replaced By: A0039978972
50
FITTING (PARTS KIT),LINE RUPTURE
50
FITTING , Replaced By: A0029905971
71
FITTING FROM BRAKE BOOSTER,"A" CONNECTION,TO VALVE,"V" CONNECTION, UP TO IDENT NO. 840080 EXCEPT FOR 500001-599999
71
ADAPTER FITTING , Replaced By: A0004291934
71
ADAPTER FITTING , Replaced By: A0009970271
72
SEAL RING LINE CONNECTION
73
THREADED UNION BRAKE CYLINDER
78
T-FITTING CONNECTION: 12, 10/20 FROM CHASSIS 4 270414,50/60 FROM CHASSIS 4 270290
80
VALVE TRAILER BRAKE
80
VALVE (OVERFLOW VALVE) KNORR
80
VALVE (OVERFLOW VALVE) GRAU
80
VALVE (OVERFLOW VALVE) BOSCH
81
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
82
SEAL RING LINE CONNECTION
84
CLAMP , Replaced By: N916016008200
84
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
84
CLAMP , Replaced By: A3604300143
84
CLAMP ,K 147121, Replaced By: N000000000319
85
BRACKET LINE MOUNTING
85
BRACKET , Replaced By: A3184280240
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
NUT
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW PIPE CLAMP
999
SCREW VALVE TO BRACKET
999
LOCK PLATE ,4 390315
999
CONNECTION FITTING ,880809
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT , Replaced By: N304032008006
999
NUT BALL PIVOT TO LEVER
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008034
999
SCREW SHUT-OFF COCK TO BRACKET
999
SCREW , Replaced By: N000933010192
999
SCREW VALVE TO BRACKET, Replaced By: N304014008002
999
SCREW PROTECTION PLATE TO BRACKET
999
SCREW SHIFT CASE TO SLOTTED GATE
999
CLAMP DELIVERY AND SUCTION LINES TO STEERING
999
CLAMP , Replaced By: A6739950001
999
CLAMP LINE MOUNTING
999
PART NAME MISSING
999
SPACER TUBE BRACKET TO REAR AXLE HOUSING
999
SEAL RINGTO 000 429 16 31,4 940458
999
SEAL RING ,4 390315
999
SCREW SHIFTING ROD TO SHIFT LEVER
999
REPAIR KITBOSCH
999
HANDLETO 000 429 16 31,4 940458
999
T-FITTING TWO-WAY VALVE,CONNECTION "1.2"
999
T-FITTING 3/2-WAY VALVE
999
SEAL RINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
SEAL RING"WABCO"
999
DIAPHRAGMTO 001 429 48 44
999
DIAPHRAGM
999
DIAPHRAGM
