Поз.
Артикул
Описание
1
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
2
UNION NUT BUTT SCREW CONNECTION
3
GLAND LINE CONNECTION
4
THRUST RING BUTT SCREW CONNECTION
5
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
5
SEAL RING , Replaced By: N007603012121
6
DISTRIBUTOR
9
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
10
VALVE CHECK
12
SHUT-OFF COCK
12
SHUT-OFF COCK
13
BRAKE LINE COUPLING
15
THRUST RING
18
PLATE SUPPLY
20
SEAL RING LINE CONNECTION
21
FITTING SHUTTLE VALVE,CONNECTION: "20"
21
FITTING , Replaced By: A0019972372
22
SEAL RING LINE CONNECTION
23
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
24
O-RING CHECK VALVE TO AIR RESERVOIR
25
THRUST RING CHECK VALVE TO AIR RESERVOIR
25
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
26
NUT CHECK VALVE TO AIR RESERVOIR
30
BRACKET
35
BRACKET
38
BRACKET LINE MOUNTING
38
BRACKET , Replaced By: A3184280240
40
CLAMP DELIVERY AND SUCTION LINES TO STEERING
40
CLAMP , Replaced By: A6739950001
999
PIN
999
SEAL RINGTO 000 429 75 30
999
LINE , Replaced By: A0005516256
999
VALVE CONEBOSCH
999
COVERTO 000 429 48 30
999
COVERWABCO
999
BRAKE LINE COUPLING , Replaced By: A0004297530
999
SEAL RING"WABCO"
999
SPRINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
SEAL RINGTO 000 429 16 31,4 940458
999
BRAKE LINE COUPLING AT REAR CROSS MENBER
999
BRAKE LINE COUPLING AT REAR CROSS MENBER
999
BRAKE LINE COUPLING AT REAR CROSS MENBER
999
REPAIR KITKNORR
999
GUIDE BUSHING
999
COVERTO 000 429 16 30,BOSCH
999
SPRING CAPSULETO 000 429 16 30
999
NUTTO 000 429 16 30
999
VALVE PARTTO 000 429 16 30
999
VALVE TAPPETTO 000 429 16 30
999
VALVE DISCTO 000 429 48 30
999
VALVE DISCTO 000 429 48 30
999
GASKETTO 000 429 16 30
999
REPAIR KITTO 000 429 14 31,5 116581
999
T-FITTING BETWEEN THE LINES
999
SPRINGTO 000 429 16 30
999
SPRINGTO 000 429 16 30
999
HANDLETO 000 429 16 31,4 940458
999
SPRING
999
SEAL RINGTO 000 429 16 30
999
SCREW PLUGTO 345 431 70 16, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
REPAIR KITWABCO
999
SEAL RINGTO 000 429 16 30
999
SEAL RINGTO 000 429 16 31,4 940458
999
BRACKET
999
T-FITTING PRESSURE REGULATOR,CONNECTION "21"
999
CLAMP LINE MOUNTING
999
SCREW BRACKET TO CAB CROSS MEMBER
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008045
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
NUT BALL PIVOT TO LEVER
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
SEAL RING OIL DRAIN 30X36 MM
999
SNAP RINGTO 000 429 16 30
999
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
999
T-FITTING , Replaced By: A0009902370
999
SCREW PIPE CLAMP
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW BRACKET TO BEARING BRACKET
999
NUT
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
