Mercedes
CAR
E 300 DIESEL USA
124.131 FROM 09/89
35 REAR AXLE
001 REAR AXLE WITH A S D ON VEHICLES WITH, OR LESS, A B S (FOR TYPE 140, SEE STANDAR IL.2

Mercedes N304017008021 - АВТОЗАПЧАСТЬ

E 300 DIESEL USA 124.131 FROM 09/89

35 REAR AXLE - 001 REAR AXLE WITH A S D ON VEHICLES WITH, OR LESS, A B S (FOR TYPE 140, SEE STANDAR IL.2

Поз.
Артикул
Описание
5
A1243235565
TORSION BAR FRONT, INAPPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
11
A1243234985
RUBBER MOUNTING TORSION BAR TO CONTROL ARM, INAPPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
14
A2013232340
BRACKET TORSION BAR TO CONTROL ARM
20
N913023008003
NUT HORN TO BRACKET M8
35
A1243230426
CLAMP TORSION BAR TO FRAME,LEFT
35
A1243230526
CLAMP TORSION BAR TO FRAME,RIGHT
38
A1243230025
PLATE BRACKET TO SIDE MEMBER
41
N914125010319
SCREW BRACKET TO SIDE MEMBER
44
N000125010532
WASHER RADIATOR TO RUBBER MOUNTING
47
A1243235685
RUBBER MOUNTING TORSION BAR TO FRAME, INAPPLICABLE TO VEHICLES WITH SPORTS UNDERCARRIAGE
50
A1243231140
BRACKET
53
N304017008021
SCREW PIPE CLAMP
59
N913023008003
NUT HORN TO BRACKET M8
