Mercedes N304017008034 - Болт крепления

OM 355 355.963 TO MOTOR 533223

01 ENGINE HOUSING - 001 ONE-CYLINDER AIR COMPRESSOR,WATER-COOLED IL.2

Поз.
Артикул
Описание
640
A4039971172
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
650
A3552030582
HOSE FROM CYLINDER CRANKCASE TO AIR COMPRESSOR
660
A3552030482
HOSE FROM AIR COMPRESSOR TO OIL-TANK COOLING WATER LINE
670
A3049951720
CLAMP COMPRESSED AIR LINE TO FRAME
680
A3552030084
SHIM
690
A3469910040
SPACER SLEEVE. SPACER TUBE FAN SHROUD TO RADIATOR,4 1619994 428844
700
N304017008034
SCREW BRACKET TO CROSS CONNECTION STRUT
700
N000933008153
SCREW , Replaced By: N304017008034
710
N000125008418
WASHER , Replaced By: N000125008443
710
N000125008443
WASHER EXHAUST MUFFLER TO STRAP
999
A0001312408
SPRING TOP
999
A0001312508
SPRING BOTTOM
999
A0001315211
PISTON RING TOP
999
A0001315311
PISTON RING BOTTOM
999
A0001315411
PISTON RING
999
A0021313601
COMPRESSOR , Replaced By: A0041310301
999
A3350103508
CRANKCASE
999
N007603026104
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
